Image preview - the first page of the document



>> Download 5991-0039EN EXG X-Series Signal Generators N5171B Analog & N5172B Vector - Data Sheet c20140621 [32] documenatation <<

Text preview - extract from the document

Keysight Technologies
EXG X-Series Signal Generators
N5171B Analog & N5172B Vector

9 kHz to 1, 3, or 6 GHz




                          Data Sheet
Table of Contents

Definitions and conditions .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 3
Frequency specifications  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 4
Amplitude specifications  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 6
Spectral purity specifications  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 11
Analog modulation specifications .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 13
Vector modulation specifications - N5172B only  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 17
General specifications  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 28
Inputs and outputs  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 30
Related literature  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  .  . 32




    Optimized for
    manufacturing
    On the path to faster throughput
    and greater uptime, the cost-
    effective EXG X-Series signal
    generators are optimized for
    manufacturing test . With analog
    and vector models, the EXG
    provides the signals you'll need
    for basic parametric testing
    of components and functional
    verification of receivers . Get "just
    enough" test at the right price
    with the EXG .




                                        2
Definitions and Conditions

Specifications represent warranted performance of a calibrated instrument that
has been stored for a minimum of 2 hours within the operating temperature range
of 0 to 55
