Keysight U5309A
PCIe High-Speed Digitizer with On-Board
Processing
2 or 8 channels, 8-bit, up to 2 GS/s, DC to 500 MHz bandwidth
With custom irmware support, suited for embedded OEM
applications


                                            Data Sheet
  Overview

Introduction                                                         Product Features
The Keysight Technologies, Inc. U5309A is a fast 8-bit
