Image preview - the first page of the document



>> Download 5991-2163EN U3020AS26 Switching Test Set_252C DC to 26.5 GHz - Data Sheet c20140701 [4] documenatation <<

Text preview - extract from the document

Keysight U3020AS26
Switching Test Set
DC to 26.5 GHz


                     Data Sheet
Description
The Keysight Technologies U3020AS26 is a switch matrix that consists of two
single-pole-six-throw (SP6T) switches. It allows switching of multiple signal
paths without physically changing the connections. This allows multiple tests to
be performed with the same setup, eliminating the need for frequent connects
and disconnects. An entire testing process can be automated, increasing the
throughput in high-volume production environments.
