Application Brief


Keysight Technologies
Low Noise Filter Improves B2961A/62A Power Source Noise Performance
 Accessory for the Keysight B2961A/62A 6.5 Digit Low Noise Power Sources


The Keysight Technologies, Inc. N1294A-022 Low Noise Filter (LNF) provides          Supplemental Characteristics                            Values
noise levels comparable to those of linear power supplies and also supports the                                    Voltage   DC             210 V
B2961A/62A's wide bipolar voltage and current ranges (up to 210 V/3 A). In
                                                                                    Max. output
addition, the LNF enables the B2961A/62A to drive capacitive loads of up to 1 mF.                                  Current   DC             3A

                                                                                                                   Voltage   0.1 to 10 Hz   5
