Image preview - the first page of the document



>> Download 5992-0061EN DDR4 Compliance Test Bench - Data Sheet c20140819 [4] documenatation <<

Text preview - extract from the document

Keysight W2351EP
DDR4 Compliance Test Bench




                                       Data Sheet




                    Introduction
                    The W2351EP DDR4 Compliance Test Bench helps solve the
                    problem of simulation-measurement correlation. In the past, the
                    pre-manufacture design could be simulated and tested using
                    compliance tools from an EDA vendor. And the post-manufacture
                    prototype could be bench tested using compliance tools from
                    test and measurement instrument vendors. However, because
                    of subtle differences between the two vendors independent ap-
                    proaches to compliance, it was almost impossible to correlate the
                    two. This opened the possibility of the pre-manufacture design
                    passing and the post-manufacture prototype failing, necessitat-
                    ing a time-consuming and expensive design spin.

                    In contrast, the DDR4 Compliance Test Bench leverages the exact
                    same industry-leading Compliance App used on Agilent Infiniium
                    oscilloscopes. It mimics a real hardware test bench, and, using a
                    scripting technology called "Waveform Bridge," emits the same
                    waveforms that the Infiniium app receives when you are testing in
                    your lab. Thus, the exact same tests - no ifs, ands, or buts - are
                    applied to both the pre-manufacture simulated design and the
                    actual post-manufacture prototype.
02 | Keysight | W2351EP DDR4 Compliance Test Bench - Data Sheet



Benefits Across The Development Process
Run a sign-off compliance test on the simulated test bench waveforms before commit-
ting to fabrication. Run the exact same tests on the simulated testbench that will be run
on the oscilloscope in the test lab when prototypes come back from fab.
