Keysight 87606B
Coaxial Matrix Switch
DC to 20 GHz



                        Technical Overview
High Performance                            The switch exhibits exceptional inser-       mounting holes, while the rest of the
                                            tion loss repeatability. This reduces        21/2 inch long by 21/4 inch diameter
Matrix Switch for RF                        sources of random errors in the              body will easily fit into most systems.
and Microwave Test                          measurement path and improves                Ribbon cable or optional solder ter-
                                            measurement uncertainty. Switch              minal connections accommodate the
Systems                                     life is a critical consideration in          need for secure and efficient control
                                            production test systems, satellite and       cable attachment.
