Keysight Technologies
E4980AL Precision LCR Meter
20 Hz to 300 kHz/500 kHz/1 MHz

Providing the best combination of accuracy, speed and versatility
02 | Keysight | E4980AL Precision LCR Metert - Brochure



A Standard LCR Meter
Keysight's E4980AL precision LCR                          Fast measurement speed                              DC bias
meter provides the best combination
of accuracy, speed, and versatility for a                 The E4980AL offers excellent speed:                 Built-in DC-voltage-bias source provides
wide range of component measurements.                                                                         accurate bias dependency evaluation for
