Image preview - the first page of the document



>> Download E5052-90223 E5052BU Option 028 Hard Disk Drive Kit User_2527s Guide c20141022 [2] documenatation <<

Text preview - extract from the document

Keysight Part No. E5052-90223                                                    Print Date: August 2014



                          Keysight E5052BU Option 028
                         Hard Disk Drive Kit User's Guide

E5052BU Option 028 is Spare HDD for the E5052B which serial-number prefix is MY472 or
above.

Installation requirement
 5188-4426 Key for Hard Disk Carrier
 USB Pen Drive (Over 512MB)
 E5052B which serial-number prefix is MY472 or above
 E5052BU-028 Spare-HDD with SATA interfaces.

Procedure
If you swap your Spare HDD (Hard Disk Drive) with the mounted HDD in the E5052B, you need to
update Syscal data and Limit files.

For details, follow the procedure in E5052B HELP.
(http://ssa.tm.keysight.com/e5052b/manuals/webhelp/eng)

Home > Product Information > Maintenance > Removing/Mounting Removable Hard Disk
Step 1. Saving system calibration data from removable hard disk to USB pen drive
Step 2. Removing Removable Hard Disk
Step 3. Mounting Removable Hard Disk
         Note: Since this is the first time boot up for Spare Removable Hard Disk, the Initial Registration
         is required. For details, follow the procedure in E5052B Installation Guide
        (http://www.keysight.com/find/e5052b-manual)
Step 4. Recalling System Calibration Data from USB Pen drive to Removable Hard Disk
Keysight Part No. E5052-90223                                              Print Date: August 2014


Note
There are two HDD interface types depending on the serial number, use the corresponding Spare HDD
kit. Different Interface type Spare HDD cannot be inserted into the E5052B.

 E5052B Serial Number           HDD Interface Type         Spare-HDD Kit
 MY471xxxxx                     Parallel ATA (PATA)        E5052BU-018 (PATA)
 MY472xxxxx                     Serial ATA (SATA)          E5052BU-028 (SATA)

Pictures of Spare-HDD computer bus interface
Spare-HDD E5052BU-018 (PATA)                          Spare-HDD E5052BU-028 (SATA)
