Image preview - the first page of the document



>> Download English _ 2012-10-01 _ PDF 355 KB 5991-1129EN c20121018 [4] documenatation <<

Text preview - extract from the document

                                             Agilent 33500 Series
                                             Waveform Generators
                                             Waveform Sequencing
                                             Technical Overview




The Agilent 33500 Series waveform generators include              A sequence is simply an ordered list of arbitrary waveforms
an embedded waveform editor that allows you to create a           that run one after another at a specified sample rate. You
wide range of arbitrary waveforms up to 1 million samples         can create a sequence in SCPI with the DATA:SEQuence
long, or up to 16 million samples with the extended               command, but for more complex sequences, it is usually
memory option. Agilent BenchLink Waveform Builder Pro             easiest to use Agilent BenchLink Waveform Builder Pro
software allows you to create an even greater variety of          software, a program you can purchase to run on your PC,
arbitrary waveforms that run on the 33500 Series and              to construct a sequence.
other Agilent waveform generators.
                                                                  To create a waveform sequence in Agilent BenchLink
However, some applications require extremely complex              Waveform Builder Pro, select New > Sequence from the
waveforms of more than 16 million points. Some applica-           main menu, as shown in Figure 1.
tions also require the repetition of relatively small arbitrary
waveforms over a large number of cycles, and still other
applications require the arbitrary waveform to interact
with the device under test (DUT) via the instrument's Sync
output. In these situations and many others, sequences of
arbitrary waveforms are the answer.




                                                                  Figure 1. Creating a new sequence with
                                                                  Agilent BenchLink Waveform
The software opens a dialog box that allows you to specify
the sequence's target instrument and sampling rate, as
shown in Figure 2.

After you enter the parameters and press OK, you use
a table to list each waveform in the sequence. For each
waveform you can specify the following attributes:
