Image preview - the first page of the document

>> Download English _ 2014-03-14 _ PDF 2.49 MB 5991-4247EN c20141006 [10] documenatation <<

Text preview - extract from the document

Keysight Technologies
Detailed Demonstration Guide:
Making Resistance Measurement Using SMU
Keysight B2901A/02A/11A/12A Precision Source/Measure Unit

Demonstration Guide
Introduction

The Keysight Technologies, Inc.
B2901A/02A/11A/12A Precision Required Instrument and Accessories
Source/Measure Units are compact
and cost-effective bench-top Source/ Keysight 11059A Kelvin Probe Set and Resistors are equipped as a demo kit
Measure Units (SMUs) with the with a demo unit of the Keysight B2900A Series of SMU.
capability to output and measure
both voltage and current. The
B2901A/02A/11A/12A enables you
to make a wide range of current
versus voltage (IV) measurements
more accurately and quickly
than ever before. In addition, the
B2901A/02A/11A/12A comes with
an intuitive graphical user interface
(GUI) and free PC-based application
software that make it easy for you to
begin making productive measure-
ments immediately.
Keysight B2901A/02A/11A/12A
This demonstration guide shows how Precision Source/Measure Unit
easily basic resistance measurement
can be made using the Keysight
B2901A/02A/11A/12A.

The demonstration includes not only
a simple resistance measurement 1 Resistor
using 2-wire connection, but also a
low resistance measurement using
4-wire connection.

Keysight 11059A Kelvin Probe Set 1 k Resistor
LAB 1: Make a Resistance Measurement

Objective Setup
This lab shows how a single-point 1. Connect the yellow banana plug to Ch 1 Low Force terminal.
measurement can be done with 2. Connect the red banana plug to Ch 1 High Force terminal.
an intuitive GUI and shallow menu 3. Clip the one lead of 1 k Resistor with the black gold-plated tweezers.
tree on the B2900A Series of SMUs
4. Clip the other lead of 1 k Resistor with the red gold-plated tweezers.
through the resistance measurement

Procedure overview 1 k Resistor
1. Change View mode to Single View
2. Use AUTO measurement operation Red (11059A)
Red (11059A)
3. Turn off the channel output 4 Brown
2 Brown
Black
Yellow (11059A) Black (11059A) Brown
1 Brown
3

Demonstration
1. Change View mode to Single View

a. Press repeatedly until Single View for
Channel 1 is shown in the display.

2. Use AUTO measurement operation
a. Rotate to select Resistance measurement operation, and then press

to edit it. Then select to set Resistance measurement operation to AUTO.

(1) Rotate and press to select (2) Press AUTO
Resistance Measurement Operation

b. Press Ch1 to turn on Channel 1 Output relay.

c. Press to perform a single point measurement.

Measurement parameters are updated whenever
Trigger Button is pressed

3
LAB 1: Make a Resistance Measurement (continued)

d. Press to repeat single point measurements periodically.

Measurement parameters
are updated periodically

"Auto" indicator is turned on

e. Press to stop making measurements periodically.
"Auto" indicator is
turned off

3. Turn off the channel output

a. Press Ch1 to turn off Channel 1 Output relay.

4
LAB 2: Make an Accurate Low Resistance Measurement

Objective Setup
This demonstration shows how accu- 1. Connect the yellow banana plug to Ch 1 Low Force terminal.
rately a low resistance measurement 2. Connect the orange banana plug to Ch 1 Low Sense terminal.
can be done with 4-wire connection 3. Connect the red banana plug to Ch 1 High Force terminal.
by comparing the result with 4-wire
4. Connect the brown banana plug to Ch 1 High Sense terminal.
connection to the one with 2-wire
connection. 5. Clip the one lead of 1 Resistor with red gold-plated flat tweezers.
6. Clip the other lead of 1 Resistor with black gold-plated tweezers.

Procedure overview
1. Reset the instrument 1 Resistor
2. Perform the measurement via
4-wire connection Brown (11059A) Red (11059A)
3. Perform the measurement via 4 5
Brown
2-wire connection Red (11059A) Black
3 Black
4. Compare two results Orange (11059A) Black (11059A) Silver
2 Brown
6
1
Yellow (11059A)

Why is 4-wire connection required?
For very low resistance measurements where the residual lead resistance is
comparable to the DUT resistance, the 2-wire measurement will give erroneous
measurement results. In this case a 4-wire connection scheme (remote sensing)
can be used to eliminate this error. A 4-wire measurement uses one pair of leads
to force current and the other pair of leads to monitor voltage. This eliminates
cable resistance effects so that only the voltage drop across the DUT is measured.

RLead High Force
High Force High Sense ISource
ISource A
VMeas RDUT VMeas RLead RDUT
B
Low Force Low Sense
B2901/02/11/12A RLead B2901/02/11/12A Low Force
VMeas VMeas
RMeas = = RDUT + 2
