Keysight Technologies
Fast Measurement of High-Rejection Filter Devices
- Keysight E5072A ENA Series Network Analyzer
The measurement of high-rejection devices is a challenging task for vector network analyzers. For
example, the BTS duplexers for 4G wireless communication systems need to guarantee extremely
high rejections of around 110 dB. And it is desired that the VNAs make fast measurements while
providing a dynamic range of more than 120 dB in the tuning and final test stages. The E5072A
offers an unparalleled wide dynamic range with its unique configurable test set and segment sweep
capabilities. Compared to the competition, the E5072A provides::
