Image preview - the first page of the document
>> Download HP Supported printers documenatation <<
Text preview - extract from the document
Supported Printers
1-Dec-04
4294A 4395A E5100A E4991A E5070B E5061A E5052A
G=GPIB 4396B E5071B E5062A
U=USB
P=Parallel
Interface P P P P/U P/U P/U P/U
HP New 6840 U - - - YES(8)(9) YES(4)(6)(8)(10) YES(4)(8)(9) YES(4)(8)(9)
New 5740 U - - - YES(8)(9) YES(4)(6)(8)(10) YES(4)(8)(9) YES(4)(8)(9)
5650 P/U Yes(3) Yes(3) Yes Yes(7)(11) Yes(3)(11) YES(4)(9) Yes(4)(9)
1200C P Yes Yes Yes(1) - - - -
3820 P/U Yes Yes(3) Yes(1)(5) Yes(7)(11) Yes(11) - -
5550 P/U Yes Yes(3) Yes(1)(5) Yes(7)(11) Yes(11) - -
672C P Yes Yes Yes (1) - - - -
690C P Yes Yes - - - - -
694C P Yes Yes Yes (1) - - - -
850C P Yes Yes - - - - -
870C P Yes Yes - - - - -
880C P Yes Yes Yes(1)(5) - - - -
895Cxi P Yes Yes Yes(1)(5) Yes(7)(11) - - -
930C P/U Yes Yes(3) Yes(1)(5) Yes(7)(11) - - -
940C P/U Yes Yes(3) Yes(1)(5) Yes(7)(11) - - -
948C P/U Yes Yes(3) Yes(1)(5) Yes(7)(11) - - -
970Cxi P Yes Yes(3) Yes (1) Yes(7)(11) - - -
EPSON PM720C P - - - Yes(7)(16) - - -
CANON BJ F210 P - - - Yes(7)(17) - - -
(1) - Works in black and white mode only.
(2) - For Instruments not equipped with a parallel interface, the GPIB to parallel converter (Micro Print 45CH) of Intelligent Interfaces Inc.
is REQUIRED to operate printers with a parallel interface. For more detail information about Micro Print 45CH,
please visit Intelligent Interfaces, Inc web site at: http://www.intelligentinterfaces.com
(3) - When the power-on switch of the printer flickers, you will be able to print the screen image of instrument using the following procedure.
1) Press the "COPY ABORT" key of instruments. 2) Press "Print Standard" key of instrument.
(4) - When the power-on switch of the printer flickers, wait until it ends and the light becomes on for the next print out.
(5) - Applies only to the E5100A/B with F/W rev.3.20 or later.
(6) - Applies only to instruments with Serial Number above JP1KK00156 or MY42100139 for E5070B, with Serial Number above JP1KK00395 or MY42100226 for E5071B.
(7) - Works in Windows 98 OS and Parallel Port Only
(8) - Works in Windows 2000 OS and USB Port Only
(9) - Use HP DJ5600 Printer Driver of Windows 98/2000 operating system
(10) - Use HP DJ5550 Printer Driver of Windows 98/2000 operating system
(11) - Use HP DJ550C Printer Driver of Windows 98/2000 operating system
(12) - Use HP DJ970C Printer Driver
(13) - Use HP DJ930C Printer Driver that is installed in the E5070/71A
(14) - Use HP DJ940C Printer Driver that is installed in the E5070/71A
(15) - Use HP DJ948C Printer Driver that is installed in the E5070/71A
(16) - Use EPSON `Stylus Color ESC/P2' Printer Driver of Windows 98 operating system
(17) - Use CANON BJC600 Printer Driver of Windows 98 operating system
Products with No Graphics Display (LCR Meter)
4263B 4349B 4284A 4268A 4288A 4279A 4287A
G=GPIB 4338B 4285A
U=USB 4339B
P=Parallel
Interface G (2) G (2) G (2) No support No support No support P/U(7)
HP New 6840 U - - - - - - -
New 5740 U - - - - - - -
5650 P/U - - - - - - -
1200C P Yes (1) Yes (1) Yes (1) - - - -
3820 P/U Yes (1) - Yes (1) - - - Yes(11)
5550 P/U Yes (1) - Yes (1) - - - Yes(11)
672C P Yes (1) Yes (1) Yes (1) - - - -
690C P - - - - - - -
694C P Yes (1) Yes (1) Yes (1) - - - -
850C P Yes (1) Yes (1) Yes (1) - - - -
870C P Yes (1) Yes (1) Yes (1) - - - -
880C P Yes (1) Yes (1) Yes (1) - - - -
895Cxi P Yes (1) Yes (1) Yes (1) - - - Yes(12)
930C P/U Yes (1) - Yes (1) - - - Yes(12)
940C P/U Yes (1) - Yes (1) - - - Yes(12)
948C P/U Yes (1) - Yes (1) - - - Yes(12)
970Cxi P - - - - - - Yes(12)
EPSON PM720C P - - - - - - -
CANON BJ F210 P - - - - - - -
Discontinued Products
4194A 4278A 4286A 4291B 4352B E5070A
G=GPIB E5071A
U=USB
P=Parallel
Interface G (2) G (2) G (2) P P P (7)
HP New 6840 U - - - - - -
New 5740 U - - - - - -
5650 P/U - - - Yes(3) Yes Yes(11)
1200C P Yes (1) Yes (1) - Yes Yes -
3820 P/U - - - Yes(3) Yes(3) Yes(11)
5550 P/U - - - Yes(3) Yes(3) Yes(11)
660C P Yes (1) Yes(1) - - Yes -
672C P Yes (1) Yes (1) - Yes Yes -
690C P - - - Yes Yes -
694C P Yes (1) Yes (1) - Yes Yes -
850C P Yes (1) Yes (1) - Yes Yes -
870C P Yes (1) Yes (1) - Yes Yes -
880C P Yes(1) Yes (1) Yes Yes Yes -
895Cxi P Yes(1) Yes (1) Yes Yes Yes -
930C P Yes(1) Yes (1) - Yes(3) Yes(3) Yes(13)
940C P/U - Yes (1) - Yes(3) Yes(3) Yes(14)
948C P/U - Yes (1) - Yes(3) Yes(3) Yes(15)
970CXI P Yes(1) - Yes Yes(3) Yes -
Windows is U.S. registered trademarks of Microsoft Corporation.
