Image preview - the first page of the document



>> Download InfiniiVision 6000 Series Oscilloscopes - Product Fact Sheet 5989-6907EN c20141201 [2] documenatation <<

Text preview - extract from the document

Product Fact Sheet
Keysight IniniiVision 6000 Series Oscilloscopes
                                                                                                                                                 Key speciications
  Engineered for the best signal                                        Keysight Technologies, Inc. IniniiVision                                 Bandwidth         100 MHz, 300 MHz, 500 MHz and 1 GHz models
  visibility                                                            6000 Series scopes will help you identify                                Channels          2-ch, 4-ch, 2 analog +16 digital,
                                                                        your most elusive problems                                                                 4 analog +16 digital
                                                                                                                                                 Sample rate       2 GSa/s (100 MHz to 300 MHz),
                                                                         Attractive Traditional form with a longer depth that is                                   4 GSa/s (500 MHz to 1 GHz)
                                                                                    stackable, with a optional battery operation                 Memory            8 Mpts standard
                                                                                    hardware coniguration for an advanced debug                  Display           High-deinition display with XGA resolution,
                                                                                    oscilloscope on the go where AC power is not                                   256 levels of intensity and 100,000 waveform/sec
                                                                                    readily available.                                                             update rate
                                                                         Fast       Fastest uncompromised update rate shows you                  Triggering        Edge, pulse width, pattern, V, duration, sequence,
                                                                                    critical signal details and infrequent events that                             serial bus (I2C, SPI, CAN, LIN, RS-232/UART, and
                                                                                    other scopes miss, while remaining responsive                                  I2S)
                                                                                    to input controls.                                           Warranty          Standard 3-year warranty
                                                                         Smart      Insightful applications with the industry's only
                                                                                    hardware accelerated decode to give you faster
                                                                                    insight.




See even the most elusive events with up to 100,000 Wfm/s   Capture a mix of analog and digital signals, compare multiple cycles of      Real-time hardware-based serial decode for I2C, SPI, CAN, LIN,
update rate.                                                digital signals with slower analog phenomena.                                RS-232/UART, and I2S.
