Image preview - the first page of the document



>> Download InfiniiVision 7000B Series vs. Danaher-Tektronix MDO4000 Series - Competitive Comparison 5990-9421EN c20130618 [2] documenatation <<

Text preview - extract from the document

                                                                                         Competitive Comparison:
                                                                                         Agilent InfiniiVision 7000B Series vs.
                                                                                         Danaher-Tektronix MDO4000 Series Oscilloscopes
                                                                                         Agilent's InfiniiVision Series oscilloscopes are engineered for the best signal visibility. The InfiniiVision 7000B
                                                                                         offers: the industry's largest display (12.1 inch), fastest uncompromised update rate (100,000 waveforms per
                                                                                         second), the only integrated and upgradable mixed signal oscilloscope option - all in a small, portable form
                                                                                         factor. With best-in-class application support, the InfiniiVision 7000B will speed your time to market.




    InfiniiVision scopes incorporate acquisition memory,
    waveform processing, and display memory in an
    advanced 0.13 ASIC.

    This patented 3rd generation technology, known as
    MegaZoom III, delivers up to 100,000 waveforms
    (acquisitions) per second with responsive deep memory
    always available.*
                                                                                                                                Agilent 7000B Series                      Danaher-Tektronix
    This means the InfiniiVision scopes have a higher                                                                                                                     MDO4000 Series
    probability of capturing infrequent/random glitches than                             Bandwidth                              100 MHz, 350 MHz, 500 MHz, 1 GHz          500 MHz, 1 GHz                       x
    the Tektronix MDO4000 Series.                                                        Memory depth                           Up to 8 M                            x    Up to 20 M*
                                                                                         Sample rate - 1 GHz model              Up to 4 GSa/s                        x    Up to 5 GSa/s
                                                                                         Sample rate
