Image preview - the first page of the document



>> Download It_2527s Time To Migrate to the X-Series Signal Analyzer and Signal Generator - Product Fact Sheet 5991-4288EN c20140804 [2] documenatation <<

Text preview - extract from the document

   Keysight Technologies
   It's Time To Migrate
   to the X-Series Signal Analyzer and Signal Generator




Your challenge: To test new technologies to the latest measurement        Newer connectivity interfaces
standards you need higher levels of performance, greater certainty
with respect to support services and the latest instrument connectivity
interfaces.                                                               The X-series signal analyzers and signal generators come with
                                                                          the latest connectivity standards, including GPIB, USB 2.0, and
Your solution: Migrate to the X-series signal analyzers and signal
                                                                          LAN. Ethernet users in particular will appreciate the 1000 BaseT
generators.
                                                                          LAN interface.


Higher levels of performance                                              Greater support service certainty
Boost every aspect of your test system                                    Maximize uptime
performance
                                                                          The N5171B EXG and N5181B MXG X-series analog signal
The N9000A CXA signal analyzer offer better sensitivity, lower            generators have an exceptional three-year calibration cycle and
phase noise, wider analysis bandwidth, and Max. 90 times faster           include only five major sub-assemblies to enable you enjoy the
sweep than the ESA series spectrum analyzer.                              benefits of high reliability and self-maintainability.

The N5171B EXG and N5181B MXG X-series analog signal                      Expedite equipment upgrades
generators offer wider frequency coverage, greater output power,
and improved signal purity compared with ESG series signal                Achieve seamless migration and reduce transition risks.
generators.                                                               Extensive backward compatibility enables minimum rewriting
                                                                          code or integrating new drivers.
Address advanced measurement needs
With more than 25 X-series measurement applications, the
N9000A CXA signal analyzer has increased their measurement
coverage substantially beyond the legacy products to meet
increasingly advanced measurement needs. 75  input
impedance and tracking generator are also available in the
3/7.5 GHz N9000A CXA.


                                                                          EMI measurement application and 89600 VSA software
Don't know what to migrate? Check out the                      N9000A CXA X-series signal analyzer
migration table below.
