Keysight Technologies
J-BERT M8020A
High-Performance BERT



                                                                     Configuration Guide




                    The following steps will guide you through configuring a turn key
                                J-BERT M8020A High-Perhformance BERT

Master Your
                                        Jitter            BER/SER/FER
Next Designs                            interference
                                        de-emphasis
                                                          link training
                                                          equalization



                   Data rates up to                                        Channel count

                 8.5 / 16 / 32 Gb/s                                        1-4




                                              Pattern generator

                                              or BERT with CDR
Available Configurations

M8020A 16 Gb/s BERT
1
