Image preview - the first page of the document



>> Download N1913A and N1914A EPM Series Power Meters - Product Fact Sheet 5990-3906EN c20140612 [2] documenatation <<

Text preview - extract from the document

Product Fact Sheet
Keysight N1913A and N1914A EPM Series Power Meters
Replacing the Keysight E4418B/19B EPM Series with useful enhancements at a similar price
                                                                                          Improved measurement speed: Up to 400 readings/s
  The N1913A/14A EPM Series power meters are versatile, user-friendly solutions
  for average power measurements on one, two or four channels. They deliver fast,
  repeatable, reliable results for applications in aerospace/defense, wireless, general
  electronics, and more.




   1




                                                                                          Get up to four 1 channels to speed and simplify RF average power measurements

   4

   3
                                                                                 2




    1.   View test results more easily with the industry's first high-resolution color
         LCD in an average power meter.                                                   Confirm battery power with a single-button push       Easily replace existing 436A, 437B and 438A with
    2.   Go beyond GPIB with USB and LAN/LXI-C interface.                                 2
                                                                                            -- and get extra operation time with the optional   optional 43x code compatibility 3.
    3.   Automate frequency/power sweep measurements with the optional external           spare battery
         trigger IN/OUT feature.                                                          1. The N1913A and N1914A comes with one and two channels respectively. Two optional USB channels are
    4.   Enhance manufacturing test by connecting a large external monitor with the          available (see Ordering Information)
                                                                                          2. Only available on meters with battery option
         unique VGA output option.                                                        3. N1913A is backward compatible with the 436A and 437B while N1914A is compatible with 438A
Keysight | N1913A and N1914A EPM Series Power Meters
