Image preview - the first page of the document



>> Download N6460A MHL Source Compliance Test Software for Infiniium 90000A Series Oscilloscopes - Data Sheet 5990-9323EN c20141013 [12] documenatation <<

Text preview - extract from the document

Keysight N6460B
MHL Source Compliance Test Software
for Infiniium Oscilloscopes


                              Data Sheet
Introduction

     Keysight Technologies, Inc. MHL source compliance test software for Infiniium oscilloscopes provides
     you with a fast and easy way to verify and characterize your Mobile High Definition-Link (MHL)
     designs for mobile devices such as cell phones and tablets. The MHL source compliance test software
     is used in the MHL Authorized Test Centers (ATCs) and has been tested thoroughly and validated for
     device compliance testing so you can confidently use it to execute MHL electrical checklist tests as
     well as employ it as a development tool.

     The MHL source compliance test software performs the full physical layer compliance suite for MHL
     data transport as identified in the MHL Compliance Test Specification 1.3 and 2.1 (CTS 1.3/2.1). These
     tests, in conjunction with protocol tests, represent the full compliance regimen to qualify an MHL
     design at an MHL authorized test center.

     As an MHL adopter, your product must successfully pass compliance testing based on the MHL CTS
     specification so you can get a jump on the process by testing with the same instrumentation and
     software as the authorized test center- in this consumer market where weeks can determine success,
     this confidence will enable you to attend to higher risk areas in your product's market delivery.


     Features
     The MHL electrical test software offers several features to simplify the validation of MHL designs:
