Keysight Technologies
N6461A SD UHS-II Compliance
Test Application for Infiniium
90000 Series Oscilloscope




                    Data Sheet
Introduction

     The Keysight Technologies, Inc. SD UHS-II compliance test application provides a fast and easy way to
     test, debug and characterize your SD UHS-II designs. The tests performed by the SD UHS-II compliance
     test software are based on the SD1 version 4.0 specifications. The test application offers a user-
     friendly setup wizard and a comprehensive report that includes margin analysis.

     The next-generation SDXC memory card specification with increased bus interface of UHS-II speeds
     up to 1.56 GB per second or higher, dramatically improves consumers' digital lifestyles by increasing
     storage capacity to 2 TB. The compliance test offers reference clock tests and host and device
     transmitter tests. The compliance test covers signal quality and common mode voltage tests for both
     host and device transmitter tests. The SD UHS-II compliance test application is compatible
     with Keysight 90000 Series Infiniium oscilloscopes.

     Features
     The SD UHS-II compliance test application offers several features to simplify the validation of your
     SD UHS-II designs:
