Image preview - the first page of the document



>> Download N6465A eMMC Compliance Test Application for Infiniium 9000 Series Oscilloscopes 5991-1397EN c20140512 [8] documenatation <<

Text preview - extract from the document

                                                            N6465A and N6465B eMMC
                                                            Compliance Test Application for
                                                            Infiniium Series Oscilloscopes


                                                            Data Sheet




Introduction

The Agilent Technologies eMMC compliance test
application provides a fast and easy way to test, debug
and characterize your eMMC designs. The tests performed
by the eMMC compliance test software are based on the
JEDEC1 JESD84-B451 specification. The test application
offers a user-friendly setup wizard and comprehensive
report that includes margin analysis.

The eMMC standard is designed for mobile devices for
storing code and data. The eMMC offers the performance
and features required by mobile devices while maintaining                              Features
low power consumption. The eMMC device contains
features that support high throughput for large data                                   The eMMC compliance test application offers several
transfers and performance for small random data in code                                features to simplify the validation of your eMMC designs:
usage.
