                                           N6467A BroadR-Reach Automotive
                                           Ethernet Electrical Compliance
                                           Application
                                           For Infiniium Oscilloscopes


                                           Data Sheet




Easy and accurate                          software, you may also need the          Features
BroadR-Reach design validation             Agilent N5395C Ethernet electrical
                                           conformance test fixture. The optional   The N6467A BroadR-Reach electri-
and debug
                                           fixture is only needed when con-         cal performance validation and
The Agilent Technologies N6467A            necting with an RJ-45 cable from the     conformance software offers several
BroadR-Reach automotive electri-           customer's device, otherwise SMA         features to simplify the validation of
cal performance validation and             cables are used to connect directly to   automotive Ethernet designs:
conformance software for Infiniium         the oscilloscope.
