Image preview - the first page of the document



>> Download N9079A & W9079A TD-SCDMA X-Series Measurement Application - Technical Overview 5989-6534EN c20140603 [12] documenatation <<

Text preview - extract from the document

TD-SCDMA
X-Series Measurement Application
N9079A & W9079A
Technical Overview
 TD-SCDMA RF transmitter measurements
 HSDPA/HSUPA/8PSK modulation and code domain analysis
 support
 Demodulation availability of code channel with phase shift or
 rotation for multi-carrier TD-SCDMA signals
 One-button tests with pass/fail limits per 3GPP standard
 Hardkey/softkey manual user interface and SCPI remote
 user interface
 Built-in, context-sensitive help
 Transportable license between X-Series signal analyzers
TD-SCDMA Measurement Application
The TD-SCDMA measurement
application transforms the X-Series
signal analyzers into standard-based
TD-SCDMA transmitter testers by
adding fast, one-button RF confor-
mance measurements to help you
design, evaluate, and manufacture
your TD-SCDMA devices. Software
capability is further enhanced by add-
ing support to phase shift or rotation
for multi-carrier TD-SCDMA signals,
allowing you to stay on the leading
edge of design and manufacturing
challenges.

The TD-SCDMA measurement
application is just one in a common
library of more than 25 measurement
applications for the Agilent X-Series
signal analyzers, an evolutionary
approach to signal analysis that          Figure 1. TD-SCDMA composite EVM
spans instrumentation, measure-
ments and software. The X-Series
analyzers, with upgradeable CPU,
memory, disk drives, and I/O ports,
enable you to keep your test assets
current and extend instrument               Try Before You Buy!
longevity. Proven algorithms, 100%
code-compatibility, and a common            Free 30-day trials of X-Series measurement applications provide
UI across the X-Series create a
                                            unrestricted use of each application's features and functionality on your
consistent measurement framework
                                            X-Series analyzer. Redeem a trial license online today:
for signal analysis that ensures
repeatable results and measurement                         www.agilent.com/find/X-Series_trial
integrity so you can leverage your test
system software through all phases
of product development. In addition
to fixed, perpetual licenses for our
X-Series measurement applications,
we also offer transportable licenses
which can increase the value of
your investment by allowing to you
transport the application to multiple
X-Series analyzers.




                                                              2
TD-SCDMA Technology Overview
Time Division-Synchronous Code                and downlink. There are 7 time slots              Since the adoption of TD-SCDMA by
Division Multiple Access (TD-SCDMA)           (numbered 0 through 6) in a single                the 3GPP body, the standard has con-
combines FDMA, CDMA and TDMA                  5 ms long frame, and within each                  tinued to evolve. As with W-CDMA,
technologies. Unlike W-CDMA and               time slot there are up to 16 code                 the high-speed downlink packed
cdma2000
