Image preview - the first page of the document
![N9340B Handheld Spectrum Analyzer (HSA) - Technical Overview 5989-7847EN c20140618 [25]](/pics/5c4d6f516f41e.gif)
>> Download N9340B Handheld Spectrum Analyzer (HSA) - Technical Overview 5989-7847EN c20140618 [25] documenatation <<
Text preview - extract from the document
Keysight N9340B
Handheld Spectrum Analyzer (HSA)
3 GHz
Technical Overview
Front panel
1 2 3 4 5
6 7 8
Top panel
9 10 11
12 13 14 15
Front panel Top panel
1. 6.5 TFT display 9. RF INPUT (50 )
2. Light sensor 10. EXT TRIG IN/EXT REF IN
3. Speaker 11. RF OUT (50 )
4. Soft keys 12. Power input (55 W Max)
5. Back-lit keys 13. USB connectors
6. Power on/off 14. Headphone connector
7. Function keys 15. LAN connector
8. Preset
2
Know your spectrum
N9340B superior
performance ensures Regardless of whether you are handling military communications, a Wireless
the field test confidence Service Provider (WSP), or involved with spectrum management you need to
avoid impaired communication. The N9340B provides you with a reliable, accu-
