Image preview - the first page of the document



>> Download N9344C N9343C N9342C Handheld Spectrum Analyzer (HSA) - Configuration Guide 5990-5588EN c20140707 [8] documenatation <<

Text preview - extract from the document

Keysight Technologies
N9344C/N9343C/N9342C
Handheld Spectrum Analyzer (HSA)



                          Configuration Guide
Configure your Keysight N934xC* Handheld Spectrum Analyzer (HSA)

This configuration guide will help you determine which performance options, measurement application software, acces-
sories, and services to include with your new Keysight Technologies, Inc. N9344C, N9343C and N9342C HSAs, or to add
as upgrades to an existing HSA. This step-by-step process will help you configure your N9344C/N9343C/N9342C HSAs.
Capabilities that are listed as standard come with the instrument at no additional charge. Tailor the performance, and
service packages to meet your requirements. Ordering optional capabilities at the time of purchase provides the lowest
overall cost.

For performance information, refer to the N9344C/N9343C/N9342C Handheld Spectrum Analyzer Data Sheets.

 Description                             Option number        Additional information
 Step 1. Select maximum frequency range (frequency range not upgradable)
 Frequency range, 1 MHz to 20 GHz        N9344C               Tunable to 9 kHz
 Frequency range, 1 MHz to 13.6 GHz      N9343C               Tunable to 9 kHz
 Frequency range, 100 kHz to 7 GHz       N9342C               Tunable to 9 kHz
 Step 2. Add a preamplifier
 Preamplifier, 1 MHz to 20 GHz           N9344C-P20           For N9344C
 Preamplifier, 1 MHz to 13.6 GHz         N9343C-P13           For N9343C
 Preamplifier, 100 kHz to 7 GHz           N9342C-PA7           For N9342C
 Step 3. Add a tracking generator
 Tracking generator, 5 MHz to 7 GHz       N934xC-TG7           Output level
