Image preview - the first page of the document



>> Download Waveguide Harmonic Mixers_252C M1970E V W 50 GHz to 110 GHz 5990-7718EN c20141117 [7] documenatation <<

Text preview - extract from the document

Keysight Technologies
Waveguide Harmonic Mixers
M1970E 60 to 90 GHz
M1970V 50 to 75/80 GHz
M1970W 75 to 110 GHz



                         Technical Overview
Introduction

     The Keysight Technologies, Inc. M1970E/V/W waveguide harmonic mixers are
     un-preselected mixers designed to extend the frequency range of Keysight's high-
                                                                                                 Go smart with
     performance signal analyzers (N9040B UXA, N9030A PXA, N9020A MXA, and                       harmonic mixing
     N9010A EXA) for millimeter-wave applications up to 110 GHz.
                                                                                                 Most efficient test setup with
     Embedded with smart features, the smart mixers provide the most efficient test              excellent performance when
     setup and measurement accuracy that's needed in demanding mixer application test
     environment. These smart mixers use a simple USB plug-and-play connection that
                                                                                                 combined with Keysight's
     can automatically configure the UXA, PXA, MXA and EXA to detect the specific mixer          N9040B UXA, N9030A PXA,
     connected, then download conversion loss data and automatically compensate for              N9020A MXA and N9010A EXA
     local oscillator path loss. Therefore, it greatly shortens the overall start up operation   signal analyzers
     and technically improves the overall DANL and TOI of your test systems with excellent
     conversion loss and amplitude accuracy.                                                     Smart Features:
