Image preview - the first page of the document



>> Download U1730 Series Handheld LCR Meters - Data Sheet 5990-7778EN c20140522 [11] documenatation <<

Text preview - extract from the document

Keysight Technologies
U1730C Series
Handheld LCR Meters
Take your expectations higher
with the latest LCR meters


                                Data Sheet
Introduction

     The Keysight Technologies, Inc. U1730C Series handheld LCR meters allow you to measure at
     frequencies as high as 100 kHz--a capability typically found only in benchtop meters. Get
     measurements done faster using the one-touch automatic identification function button which
     displays component type and more detailed component analysis such as Z, ESR, and DCR. Ideal for
     testing on the go, these LCR meters operate on a battery that lasts up to 16 hours. With the U1730C
     Series that is built for your convenience, you can perform quick and basic LCR measurements at an
     affordable price.
03 | Keysight | U1730C Series Handheld LCR Meters
