Keysight Technologies
U1810B USB Coaxial Switch SPDT
DC to 18 GHz




                           Technical Overview
Introduction

     Description
     The Keysight Technologies, Inc. U1810B is a USB-powered SPDT coaxial switch, operating from
     DC to 18 GHz, and supports the standard plug-and-play functionality of typical USB devices. The
     unique combination of excellent RF performance with the convenience of USB connectivity presents
     an invaluable alternative for users to increase the efficiency of their test systems. No additional
     power supply is required and the Type-N common input connector provides a rugged and robust
     connection with the instrument ports. A push-button on the switch casing allows for direct toggling
     of the two output ports without the need for any software interface. In addition, the bundled soft
     front panel provides an alternative virtual interface to control the U1810B. Users also have the
     option to control the switch through commonly used software programming platforms such as C#,
     C++, LabVIEW, VEE, etc.

     Inheriting Keysight's unique switch technology, the U1810B is designed to operate for more than
     10 million cycles. The exceptional 0.03 dB insertion loss repeatability is warranted for 5 million
     cycles. This excellent RF characteristic significantly reduces downtime for recalibration, improves
     testing efficiency and ultimately maximizes test throughput.


     Key features and benefits
