Image preview - the first page of the document



>> Download Ultimate speed and stability for high-volume RF component tests - E5071C ENA - Flyer 5991-2046EN c20130307 [2] documenatation <<

Text preview - extract from the document

                                                        Ultimate Speed and Stability for High-Volume
                                                        RF Component Test - Agilent E5071C ENA
                                                        Series Network Analyzer

                        Measurement speed with same IFBW (in msec)                                     The E5071C with enhanced digital hardware offers the best-in-class
                                                                                                       measurement speed and stability performance. This enables you
                                                                                                       to significantly reduce cost-of-test and improve yield when testing
                                    E5071C                                                             low-loss devices such as RF filters and front-end-modules for mobile
                                                                                                       handsets.
                                    Other company's VNA
                                                                                                        2x faster measurement speed
                                0          2   4    6     8     10    12     14     16     18    20     3x better trace noise
                                Start 1 GHz ,Stop 1.2 GHz, IFBW 100 kHz, 201 points, full 4-port cal    7x better temperature stability
                                                                                                                                   Temperature stability (long-term stability)
                                                                                                                       0.045
                                     Trace noise (short-term stability, IFBW 100 kHz)
                                                                                                                        0.04
                                0.015
                                                                                                                       0.035
Transmission trace noise (dB)




                                                                                                                                                                         23
