Service Manuals, User Guides, Schematic Diagrams or docs for : Akai CFT CFT-D2052 CFT-D2052

<< Back | Home

Most service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.



Image preview - the first page of the document



>> Download CFT-D2052 documenatation <<

Text preview - extract from the document

                 CFTD2052

                 SERVICE MANUAL
                 LCD COLOR TELEVISION/DVD VIDEO PLAYER




                                                                     ORIGINAL
                                                                   MFR'S VERSION A




                                                     Design and specifications are subject to change without notice.




Downloaded from www.Manualslib.com manuals search engine
                        CAUTION
                        THIS LCD COLOR TELEVISION EMPLOYS A LASER SYSTEM.

                        TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE-
                        FULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE,
                        CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.

                        USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN
                        THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

                        TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
                        VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
                        STARE INTO BEAM.


                                Location of the required Marking
                                The rating sheet and the safety caution are on the rear of the unit.




                                CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE
                                STANDARDS, 21 CFR SUBCHAPTER J.




                        PREPARATION OF SERVICING


                        The laser diode used for a pickup head may be destroyed with external static electricity.
                        Moreover, even if it is operating normally after repair when static electricity discharge is received at the
                        time of repair, the life of the product may be shortened.
                        Please perform the following measure against static electricity, be careful of destruction of a laser diode
                        at the time of repair.
