Image preview - the first page of the document
>> Download SB-1 documenatation <<
Text preview - extract from the document
SB1
Synth Bass Processor
MODEL DEEP IMPACT SB1
SPECIFICATIONS
Functions: ......................... Programs: 9 memorized preset sounds: DARK BUBBLE, HARDCORE, KITAROH BASS, BRIGHT
SYNTH, BRATS, FAT BOTTOM, MAJESTY, HOT SPACE, HICCUPS.
Program Up
Effect on/off
Connectors: ...................... INPUT (Input impedance: 500k ohms or more)
OUTPUT (Output impedance: 1k ohms or less)
DC IN (9 Volts)
PROGRAM DOWN for optional footswitch connection.
Controls: ............................ INPUT LEVEL
PARAMETER
DATA
OUTPUT LEVEL
FOOTSWITCH x 2 (unlatch type) ON/OFF and PROGRAM UP.
Indicators: ......................... Input Level (LED x 3), Effect on/off (LED x 1), PROGRAM NO
(7 segment LED x 1), DATA (7 segment LED x 1)
Power requirements: ........ 9V DC/180mA, AC adaptor MP-9
Accessories: ..................... Operator's Manual, AC adaptor MP-9
Dimensions: ...................... 140 (W) x 175 (D) x 61 (H)mm
Weight: ............................... 750g
