Image preview - the first page of the document
>> Download BE3100 documenatation <<
Text preview - extract from the document
Ersatzteile Typ:3100 Seite:1 von 17
Pos. Best.-Nr. Benennung
1 1284614 CHASSIS VMT 3300
2 1309765 DECKEL, CHASSIS 3200
3 1284622 HALTEFEDER, RECHTS 3300
4 1284630 HALTEFEDER, LINKS 3300
5 1246909 KUEHLKOERPER 3310 WGR11318
6 1271997 SCHUTZKAPPE -D2B HEADER- AMP
7 1246917 IC-HALTER 3310
8 1248316 ZB RAHMEN, ABSCHIRM-FM- M.ANT.BUCHSE3130
9 1278916 ZB CONNECTOR 21 POL D&R K37000300 3300
10 1271210 TAPEDECK ASSY ALP GR71S31B GR-S
11 BEDIENAUFSATZ (NICHT KPL. LIEFERBAR)
12 1313266 ZIERBLENDE KPL. MIT CASSETTENKLAPPE 3100
13 1342282 SCHALTUNGSPLATTE 9090 FRONT/LCD
14 1342312 TASTE AUSSCHUB
15 1342320 TASTE SC
16 1342339 TASTE STUMM
17 1342355 TASTE KLANG
18 1342363 TASTE CC
19 1342371 TASTE FM
20 1342381 TASTE AM
21 1342398 TASTE CD
22 1342401 TASTENKREUZ SUCHLAUF
23 1342411 TASTENKREUZ STATIONSTASTEN
24 1342428 TASTE RDS
25 1313428 KONTAKTMATTE, LINKS 3100
26 1313436 KONTAKTMATTE, RECHTS 3100
27 1313369 DREHFEDER-VKL-
28 1313355 VERSCHLUSSKLAPPE BDR
29 1313339 STEUERUNGSHEBEL -VKL- 3100
30 1313347 VERSCHLUSSKLAPPE -STEUERUNG- 3100
31 1284177 DREHKNOPF MRT 3300
32 1313411 LICHTLEITER, CC 3100
C101 1237683 KEKO-CH 4P7 J NP0 0603 BAW SPE0030A315
C103 1237683 KEKO-CH 4P7 J NP0 0603 BAW SPE0030A315
C104 1223968 KEKO-CH 33P J NP0 0603 BAW SPE0030A315
C105 1223976 KEKO-CH 47P J NP0 0603 BAW SPE0030A315
C107 1243012 KEKO-CH 27P J NPO 0603 BAW SPE0030A315
C108 1223941 KEKO-CH 18P J NP0 0603 BAW SPE0030A315
C109 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C110 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C111 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C114 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C115 1246321 KEKO-CH 220N K X7R 1206 BAW SPE0036A315
C116 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C117 1119222 KEKO-CH 470P K X7R 0805 BAW SPE0015A315
C118 1306170 AL-ELKO 100U M 1000/85G NCC SRM-VB RM2,5
C119 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C121 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C122 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
20.06.2000
Ersatzteile Typ:3100 Seite:2 von 17
C123 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C131 1238787 KEKO-CH 5P6 J NP0 0603 BAW SPE0030A315
C132 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C133 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C134 1226991 KEKO-CH 2P2 J NP0 0603 BAW SPE0030A315
C1401 1283235 KEKO-CH 4U7 K X5R 1206 10V MUR GMR42-6
C1402 1275992 KEKO-CH 330P J NP0 0603 BAW SPE0030A315
C1403 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1404 1156561 KEKO-CH 560P J NP0 0805 BAW SPE0003A315
C1405 1223976 KEKO-CH 47P J NP0 0603 BAW SPE0030A315
C1406 1234463 KEKO-CH 82P J NP0 0603 BAW SPE0030A315
C1407 1243934 AL-ELKO 10U M 16V G BAW SPE0069A31 RM2,5
C1500 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1501 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C1502 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C1503 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C1504 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C1505 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C1506 1243012 KEKO-CH 27P J NPO 0603 BAW SPE0030A315
C1507 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C1508 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1509 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C151 1257821 KEKO-CH 6N8 K B 0805 50V PDAG MUR GRM425
C1510 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C1511 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C1512 1173324 KEKO-CH 1N J NP0 0805 BAW SPE0003A315
C1513 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C1514 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C1515 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C1516 1083899 KEKO-CH 820P J NP0 1206 BAW SPE0006A315
C1517 1083899 KEKO-CH 820P J NP0 1206 BAW SPE0006A315
C1518 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C1519 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C152 1223992 KEKO-CH 150P J NP0 0603 BAW SPE0030A315
C1520 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C1521 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C1522 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C1523 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C1524 1253441 FOKO-CH 10N J 1206 50V G PAN ECHU
C1525 1253441 FOKO-CH 10N J 1206 50V G PAN ECHU
C1526 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1527 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1528 1223968 KEKO-CH 33P J NP0 0603 BAW SPE0030A315
C153 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1530 1119117 KEKO-CH 10N J X7R 0805 BAW SPE0014A315
C1550 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1551 1119117 KEKO-CH 10N J X7R 0805 BAW SPE0014A315
C1552 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1553 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C1554 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
20.06.2000
Ersatzteile Typ:3100 Seite:3 von 17
C1555 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C1556 1119117 KEKO-CH 10N J X7R 0805 BAW SPE0014A315
C1557 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C156 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C157 1119176 KEKO-CH 22N J X7R 0805 BAW SPE0014A315
C159 1119222 KEKO-CH 470P K X7R 0805 BAW SPE0015A315
C160 1252690 KEKO-CH 470P J NP0 0603 BAW SPE0030A315
C161 1223933 KEKO-CH 15P J NP0 0603 BAW SPE0030A315
C162 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C163 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C164 1172050 AL-ELKO 47U M 16V G BAW SPE0060A31 RM2,5
C165 1243934 AL-ELKO 10U M 16V G BAW SPE0069A31 RM2,5
C166 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C168 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C169 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C170 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C1801 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C1802 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C1803 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C1804 1173324 KEKO-CH 1N J NP0 0805 BAW SPE0003A315
C1805 1173324 KEKO-CH 1N J NP0 0805 BAW SPE0003A315
C1809 1238647 TAKO-CH 1U K B G 35V BAW SPE0005A313
C1810 1166751 KEKO-CH 4N7 K X7R 0805 BAW SPE0015A315
C1811 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C1836 1166751 KEKO-CH 4N7 K X7R 0805 BAW SPE0015A315
C1861 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C2001 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C2002 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C2003 1119192 KEKO-CH 33N K X7R 0805 BAW SPE0015A315
C2004 1296116 KEKO-CH 3N9 K X7R 0603 50V BAW SPE0032A3
C2005 1296116 KEKO-CH 3N9 K X7R 0603 50V BAW SPE0032A3
C2006 1119176 KEKO-CH 22N J X7R 0805 BAW SPE0014A315
C2007 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C2008 1255711 KEKO-CH 220N J X7R 1206 BAW SPE0037A315
C2009 1255711 KEKO-CH 220N J X7R 1206 BAW SPE0037A315
C201 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C2010 1307797 ALKO-CH 4U7 M 25V I G BAW SPE0164A312
C2011 1307797 ALKO-CH 4U7 M 25V I G BAW SPE0164A312
C2012 1083945 KEKO-CH 2N7 J NP0 1206 BAW SPE0007A315
C2013 1307797 ALKO-CH 4U7 M 25V I G BAW SPE0164A312
C2014 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C2015 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C2016 1275879 ALKO-CH 10U M 16V I G BAW SPE0162A312
C2017 1307797 ALKO-CH 4U7 M 25V I G BAW SPE0164A312
C2018 1083945 KEKO-CH 2N7 J NP0 1206 BAW SPE0007A315
C2019 1223976 KEKO-CH 47P J NP0 0603 BAW SPE0030A315
C202 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C2020 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C2021 1255711 KEKO-CH 220N J X7R 1206 BAW SPE0037A315
C2022 1288962 KEKO-CH 150N K X7R 0805 25V MUR GRM40
20.06.2000
Ersatzteile Typ:3100 Seite:4 von 17
C2023 1255711 KEKO-CH 220N J X7R 1206 BAW SPE0037A315
C2024 1288962 KEKO-CH 150N K X7R 0805 25V MUR GRM40
C2025 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C203 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C204 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C205 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C206 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C207 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C209 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C210 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C212 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C213 1119192 KEKO-CH 33N K X7R 0805 BAW SPE0015A315
C216 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C217 1290681 KEKO-CH 330P J P2H 0805 50V MUR GRM40
C218 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C219 1283235 KEKO-CH 4U7 K X5R 1206 10V MUR GMR42-6
C220 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C221 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C226 1275992 KEKO-CH 330P J NP0 0603 BAW SPE0030A315
C227 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C251 1320513 KEKO-CH 75P J NPO 0603 BAW SPE0030A315
C252 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C253 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C254 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C255 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C257 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C258 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C259 1166409 KEKO-CH 6N8 J X7R 0805 BAW SPE0014A315
C260 1166409 KEKO-CH 6N8 J X7R 0805 BAW SPE0014A315
C261 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C264 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C271 1277790 KEKO-CH 680P J COH 0603 25V G MUR GRM39
C276 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C277 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C278 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C279 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C282 1301497 KEKO-CH 47P J P2H 0603 MUR GRM39
C283 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C285 1243934 AL-ELKO 10U M 16V G BAW SPE0069A31 RM2,5
C301 1230077 KEKO-CH 1N J NPO 0603 50V AVX CM105
C302 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C303 1246321 KEKO-CH 220N K X7R 1206 BAW SPE0036A315
C304 1246321 KEKO-CH 220N K X7R 1206 BAW SPE0036A315
C305 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C309 1233971 KEKO-CH 10P J NP0 0603 BAW SPE0030A315
C310 1243012 KEKO-CH 27P J NPO 0603 BAW SPE0030A315
C312 1223933 KEKO-CH 15P J NP0 0603 BAW SPE0030A315
C314 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C317 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C318 1283235 KEKO-CH 4U7 K X5R 1206 10V MUR GMR42-6
20.06.2000
Ersatzteile Typ:3100 Seite:5 von 17
C319 1283235 KEKO-CH 4U7 K X5R 1206 10V MUR GMR42-6
C320 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C321 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C322 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C323 1173278 AL-ELKO 4U7 M 25V G BAW SPE0071A31 RM2,5
C324 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C325 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C326 1218506 KEKO-CH 1N J U2J 0805 MUR GRM40
C328 1259253 KEKO-CH 220P J NPO 0603 BAW SPE0030A315
C346 1162241 KEKO-CH 470P G NP0 0805 BAW SPE0027A315
C347 1162284 KEKO-CH 560P G NP0 0805 BAW SPE0027A315
C348 1254782 KEKO-CH 2N G NPO 0805 50V MUR GRM40
C349 1239961 KEKO-CH 1N F NP0 0805 BAW SPE0029A315
C351 1243934 AL-ELKO 10U M 16V G BAW SPE0069A31 RM2,5
C360 1283235 KEKO-CH 4U7 K X5R 1206 10V MUR GMR42-6
C361 1119192 KEKO-CH 33N K X7R 0805 BAW SPE0015A315
C362 1283499 KEKO-CH 1U K X7R 0805 10V MUR GRM 40
C363 1270648 KEKO-CH 68N J X7R 0805 25V MUR GRM40
C364 1119192 KEKO-CH 33N K X7R 0805 BAW SPE0015A315
C365 1119192 KEKO-CH 33N K X7R 0805 BAW SPE0015A315
C366 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C367 1119192 KEKO-CH 33N K X7R 0805 BAW SPE0015A315
C368 1276220 KEKO-CH 2N2 J X7R 0805 50V BAW SPE0014A
C369 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C370 1246321 KEKO-CH 220N K X7R 1206 BAW SPE0036A315
C371 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C50 1229974 AL-ELKO 100U M 25V I G BAW SPE0108 RM2,5
C501 1186973 AL-ELKO 1M M 25V G BAW SPE0074A312-RM5
C502 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C506 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5
C507 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5
C508 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5
C509 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5
C51 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C52 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C53 1290282 AL-ELKO 2M2 M 25V G BAW SPE0084A312RM7,5
C54 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C55 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C56 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C57 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C58 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C59 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C603 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C606 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C607 1253360 AL-ELKO 56U M 2000/105 16V NCC SXE-VB F0
C609 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C610 1253360 AL-ELKO 56U M 2000/105 16V NCC SXE-VB F0
C611 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C612 1249150 AL-ELKO 22U M 16V BAW SPE0067A312-RM2,5
C613 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
20.06.2000
Ersatzteile Typ:3100 Seite:6 von 17
C62 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C63 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C64 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C65 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C70 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C702 1281437 FOKO 100N J 63V G BAW SPE0015A314 RM5
C704 1307797 ALKO-CH 4U7 M 25V I G BAW SPE0164A312
C705 1281283 FOKO 15N J 63V G BAW SPE0010A314 RM5
C706 1275992 KEKO-CH 330P J NP0 0603 BAW SPE0030A315
C707 1275992 KEKO-CH 330P J NP0 0603 BAW SPE0030A315
C71 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C712 1281437 FOKO 100N J 63V G BAW SPE0015A314 RM5
C714 1307797 ALKO-CH 4U7 M 25V I G BAW SPE0164A312
C715 1281283 FOKO 15N J 63V G BAW SPE0010A314 RM5
C716 1275992 KEKO-CH 330P J NP0 0603 BAW SPE0030A315
C717 1275992 KEKO-CH 330P J NP0 0603 BAW SPE0030A315
C72 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C720 1249150 AL-ELKO 22U M 16V BAW SPE0067A312-RM2,5
C721 1252585 KEKO-CH 470N J X5R 1206 16V MUR GRM42-6
C722 1166751 KEKO-CH 4N7 K X7R 0805 BAW SPE0015A315
C723 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C724 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C725 1172085 AL-ELKO 100U M 16V G BAW SPE0063A3 RM2,5
C73 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C74 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C75 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C76 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C77 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C805 1119060 KEKO-CH 1N K X7R 0805 BAW SPE0015A315
C806 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C807 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C808 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C811 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C812 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C813 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C814 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C815 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C816 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C817 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C818 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C819 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C820 1234536 KEKO-CH 100P J NP0 0603 BAW SPE0030A315
C821 1229974 AL-ELKO 100U M 25V I G BAW SPE0108 RM2,5
C830 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C831 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C832 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C833 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C834 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C835 1182943 KEKO-CH 47N K X7R 0805 BAW SPE0015A315
C836 1119117 KEKO-CH 10N J X7R 0805 BAW SPE0014A315
20.06.2000
Ersatzteile Typ:3100 Seite:7 von 17
C837 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C840 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C852 1119125 KEKO-CH 10N K X7R 0805 BAW SPE0015A315
C861 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C862 1258877 AL-ELKO 4U7 M 50V G BAW SPE0049A31 RM2,5
C863 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C870 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C871 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C881 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C882 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C897 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C898 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312
C901 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C902 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C908 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C909 1223951 KEKO-CH 22P J NP0 0603 BAW SPE0030A315
C919 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C928 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C929 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C939 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C949 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C958 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C968 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
C969 1246348 KEKO-CH 100N K X7R 0805 BAW SPE0035A315
D101 1149326 DROSSEL-CH 0,68UH K G SIE B82422-A3681-K
D103 1289950 DROSSEL-CH 10UH K G SIE B82432-A1103-K
D104 1242164 INDUCTOR-CH G MUR BLM11B141D
D1500 1237705 INDUCTOR-CH G MUR BLM21A601S
D1501 1305591 INDUCTOR-CH G MUR BLM11A601S
D1502 1237705 INDUCTOR-CH G MUR BLM21A601S
D1503 1227221 INDUCTOR-CH G MUR BLM11A221S
D1504 1000950 DROSSEL-CH 47UH K G SIE B82422-A1473-K
D1505 1305591 INDUCTOR-CH G MUR BLM11A601S
D1550 1237705 INDUCTOR-CH G MUR BLM21A601S
D1801 1227221 INDUCTOR-CH G MUR BLM11A221S
D301 1178237 DROSSEL-CH 2,2UH K G SIE B82422-A1222-K
D302 1249398 DROSSEL-CH 2,2MH K G MSI C6-R/3333
D304 1245368 DROSSEL-CH 68UH K G SIE B82432-S1683-K
D305 1245368 DROSSEL-CH 68UH K G SIE B82432-S1683-K
D306 1148494 DROSSEL-CH 0,47UH J G SIE B82422-A3471-J
D50 1237705 INDUCTOR-CH G MUR BLM21A601S
D51 1237705 INDUCTOR-CH G MUR BLM21A601S
D52 1237705 INDUCTOR-CH G MUR BLM21A601S
D53 1244922 DROSSEL,BATT.- 200UH VOG 5730409900
D870 1227221 INDUCTOR-CH G MUR BLM11A221S
D871 1227221 INDUCTOR-CH G MUR BLM11A221S
D873 1245104 DROSSEL-CH 51UH N 0,5A G SIE B82790
D909 1237705 INDUCTOR-CH G MUR BLM21A601S
D930 1237705 INDUCTOR-CH G MUR BLM21A601S
D931 1237705 INDUCTOR-CH G MUR BLM21A601S
20.06.2000
Ersatzteile Typ:3100 Seite:8 von 17
DI101 1217186 DIODE-CH SIE BB914 G
DI102 1217186 DIODE-CH SIE BB914 G
DI104 1225529 DIODE-CH TEL S391D G
DI131 1217186 DIODE-CH SIE BB914 G
DI1801 1252143 DIODE-CH PHI BAS216 G
DI1803 1252143 DIODE-CH PHI BAS216 G
DI1804 1252143 DIODE-CH PHI BAS216 G
DI1805 1252143 DIODE-CH PHI BAS216 G
DI203 1252143 DIODE-CH PHI BAS216 G
DI301 1229788 DIODE-CH BAW BA779-2/1SV234/DPA05 G SPE
DI302 1252143 DIODE-CH PHI BAS216 G
DI50 1179683 DIODE-CH GIC S3B G
DI501 1252143 DIODE-CH PHI BAS216 G
DI603 1118757 DIODE-CH BAW 6V8 5% SHIP-TO-STOCK G SPE0
DI830 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A
DI831 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A
DI832 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A
DI833 1252143 DIODE-CH PHI BAS216 G
DI834 1252143 DIODE-CH PHI BAS216 G
DI840 1076353 DIODE-CH BAW 5V6 2% SHIP-TO-STOCK G SPE0
DI853 1252143 DIODE-CH PHI BAS216 G
DI854 1252143 DIODE-CH PHI BAS216 G
DI861 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A
DI885 1252143 DIODE-CH PHI BAS216 G
DI890 1252143 DIODE-CH PHI BAS216 G
F101 1295004 FILTER, FMZ- 100MHZ TOK MC122 E528ENAS-1
F102 1253395 FILTER, FMZ- 100MHZ TOK/P666SNS-256Z-RT
F131 1284827 FILTER,AMO/FMO-120MHZ TOK VAG,VWA,GEA
F201 1290568 FILTER, FM-ZF- 10,7MHZ TOK 5PAG-C805PN-
F204 1291637 FILTER,FM-PHASENKR.-10,7MHZ MSI RA7008-2
F321 1247115 FILTER, AM-ZF- 450KHZ TOK 5PAG (C805LN-0
IC101 1309404 IC-CH SIE TUA 4306 B3 MQFP64/1 G
IC1401 1155431 IC-CH PHI SAA6579T/V1 SHIP-TO-STOCK
IC1500 1239147 IC-CH AUM OCC8001-01
IC1501 1249101 IC-CH TOS TC7S08F G
IC1502 1311050 IC-CH AKM AK4520B-E2
IC151 1283510 IC-CH SGT TDA 7427 AD (TSSOP28) G
IC1801 0901806 IC-CH PHI PCF8576T/F2 SHIP-TO-STOCK G
IC1802 1299662 IC-CH NEC UPD 754302-3200-04/98
IC2001 1246178 IC-CH SGT TDA7342TR G
IC361 1283669 IC-CH HIT HA12181FP FP-16DA
IC501 1271180 IC PHI TDA8569Q /N1
IC601 1258397 IC-CH SIE TLE4276GV P-TO220-5-122
IC602 1246674 IC-CH SIE TLE4269GL P-DSO20-6 G
IC701 1246607 IC-CH SOY CXA2510Q
IC702 1245996 IC-CH PHI 74HC03D,653 G
IC831 1286242 IC-CH TOS TC7S14F G
IC870 1279432 IC-CH PHI TJA 1053 G
IC881 1240481 IC-CH SIE BSP452 G
IC901 1245058 IC-CH SIE SAF-C515C-8R P-MQFP-80
20.06.2000
Ersatzteile Typ:3100 Seite:9 von 17
IC902 1294490 IC-CH PHI 74HC573 PW,118-TSSOP20
IC903 1312170 IC-SOCKEL 32POL CAB 540-99-032-07-400-0
IC903 1338196 IC-CH BAW 27C010-90-3100-26/99 3100
IC904 1294334 IC-CH SAY LC35256DT-70-TLM
IC905 1294490 IC-CH PHI 74HC573 PW,118-TSSOP20
IC906 1294490 IC-CH PHI 74HC573 PW,118-TSSOP20
IC909 1294601 IC-CH PHI 74HC02PW-TSSOP14 G
IC910 1012071 IC-CH BAW 74HC4094 G SPE0005A308
IC911 1012071 IC-CH BAW 74HC4094 G SPE0005A308
KF201 1306987 K-FILT MUR SFE 10,7 MS3A10GJ24-A-S-TF21
KF202 1331590 KERA-FILTER MUR SFE 10,7MHZ MTE-TF22
KF204 1307010 K-FILT.MUR SFE 10,7MHZ MJA10J24-A-S-TF21
KF205 1306987 K-FILT MUR SFE 10,7 MS3A10GJ24-A-S-TF21
KF321 1237713 KERA-FILTER MUR CFWS 450 IT
LD1801 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1802 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1803 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1804 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1805 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1806 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1807 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1808 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1809 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1810 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1811 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1812 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1813 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1814 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1831 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1832 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1833 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1834 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1835 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1836 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1837 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1838 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1839 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1840 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1841 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1842 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1843 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1844 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1846 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1847 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1848 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1849 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1850 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1851 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1861 1158767 LED-CH SIE LST670 G -RT
OT1500 1248121 TRANSCEIVER AMP 966893 D2BOPTICAL-HEADER
20.06.2000
Ersatzteile Typ:3100 Seite:10 von 17
P701 1246615 TRIWID-CH 10K 0,10W MUR POZ3AN1-103N-T00
P702 1246615 TRIWID-CH 10K 0,10W MUR POZ3AN1-103N-T00
Q1401 1277898 QUARZ 4,332MHZ G NDK AT-51
Q1500 1305492 QUARZ-CH 16,9344 MHZ NDK AT-41CD2
Q151 1280279 QUARZ 10,250 MHZ G NDK AT-51 M.ISOPL.
Q1801 1171501 KERA-RESON-CH MUR CSAC 4,19 MGCA G
Q251 1295268 KERA-RESON-CH MUR CSBF456 JF 239
Q901 1295691 QUARZ 10MHZ TQG TQX6674 MIT ISOPL.
R1000 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R1002 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R1004 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R1005 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1006 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1007 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1008 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1009 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1010 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1011 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1012 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R102 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R103 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R105 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R106 1271199 MEGWI-CH 56K F 0603 G BAW SPE0028A323
R107 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R112 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R1160 1305085 MEGWI-CH 820K F 0603 BAW SPE0028A323
R1161 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R121 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R122 1271199 MEGWI-CH 56K F 0603 G BAW SPE0028A323
R123 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R124 1271199 MEGWI-CH 56K F 0603 G BAW SPE0028A323
R125 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R126 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R127 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R131 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R132 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R1401 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R1402 1304437 MEGWI-CH 820R F 0603 BAW SPE0027A323
R1500 1304471 MEGWI-CH 2K F 0603 G BAW SPE0028A323
R1501 1271202 MEGWI-CH 220K F 0603 G BAW SPE0028A323
R1502 1277588 MEGWI-CH 330K F 0603 G BAW SPE 0028A323
R1503 1304755 MEGWI-CH 1R5 F 0805 G BAW SPE0017A323
R1506 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1507 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1508 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1509 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R151 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R1511 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R1512 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R1513 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
20.06.2000
Ersatzteile Typ:3100 Seite:11 von 17
R1514 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R1515 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R1516 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R1517 1271199 MEGWI-CH 56K F 0603 G BAW SPE0028A323
R1518 1235389 MEGWI-CH 2K4 F 0603 G BAW SPE0028A323
R1519 1235389 MEGWI-CH 2K4 F 0603 G BAW SPE0028A323
R152 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R1520 1271199 MEGWI-CH 56K F 0603 G BAW SPE0028A323
R1521 1304321 MEGWI-CH 150R F 0603 BAW SPE0027A323
R1522 1304321 MEGWI-CH 150R F 0603 BAW SPE0027A323
R1523 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1524 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1525 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1526 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1527 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R1528 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R153 1253700 MEGWI-CH 8K2 F 0603 G BAW SPE0028A323
R154 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R1550 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R1551 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R156 1305001 MEGWI-CH 33K F 0603 BAW SPE0028A323
R157 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R159 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R161 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R163 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R165 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R166 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R168 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R169 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R1801 1226649 MEGWI-CH 680R F 1206 BAW SPE0015A323
R1802 1293206 MEGWI-CH 1K5 F 1206 BAW SPE0016A323
R1803 1293206 MEGWI-CH 1K5 F 1206 BAW SPE0016A323
R1804 1293206 MEGWI-CH 1K5 F 1206 BAW SPE0016A323
R1805 1293206 MEGWI-CH 1K5 F 1206 BAW SPE0016A323
R1809 1303511 MEGWI-CH 560R F 1206 G BAW SPE0015A323
R1810 1303511 MEGWI-CH 560R F 1206 G BAW SPE0015A323
R1811 1303511 MEGWI-CH 560R F 1206 G BAW SPE0015A323
R1812 1303511 MEGWI-CH 560R F 1206 G BAW SPE0015A323
R1813 1303538 MEGWI-CH 820R F 1206 G BAW SPE0015A323
R1814 1303491 MEGWI-CH 470R F 1206 G BAW SPE0015A323
R1815 1226649 MEGWI-CH 680R F 1206 BAW SPE0015A323
R1816 1304437 MEGWI-CH 820R F 0603 BAW SPE0027A323
R1817 1304437 MEGWI-CH 820R F 0603 BAW SPE0027A323
R1818 1304437 MEGWI-CH 820R F 0603 BAW SPE0027A323
R1819 1304437 MEGWI-CH 820R F 0603 BAW SPE0027A323
R1831 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R1832 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1833 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1836 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R1837 1305093 MEGWI-CH 1M F 0603 BAW SPE0028A323
20.06.2000
Ersatzteile Typ:3100 Seite:12 von 17
R1841 1304402 MEGWI-CH 470R F 0603 BAW SPE0027A323
R1842 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R1844 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R1846 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R1847 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R1848 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1849 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R1851 1304331 MEGWI-CH 180R F 0603 BAW SPE0027A323
R1852 1304305 MEGWI-CH 120R F 0603 G BAW SPE0027A323
R1854 1304402 MEGWI-CH 470R F 0603 BAW SPE0027A323
R1861 1282662 MEGWI-CH 180K F 0603 G BAW SPE0028A323
R1862 1288415 MEGWI-CH 6K8 F 0603 G BAW SPE 0028A323
R1864 1288393 MEGWI-CH 5K1 F 0603 G BAW SPE0028A323
R1865 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R2001 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R2002 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R2003 1254022 MEGWI-CH 2K2 F 0603 G BAW SPE0028A323
R2004 1304496 MEGWI-CH 3K9 F 0603 G BAW SPE0028A323
R2005 1304496 MEGWI-CH 3K9 F 0603 G BAW SPE0028A323
R2006 1304496 MEGWI-CH 3K9 F 0603 G BAW SPE0028A323
R2007 1304496 MEGWI-CH 3K9 F 0603 G BAW SPE0028A323
R2008 1253700 MEGWI-CH 8K2 F 0603 G BAW SPE0028A323
R2009 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R201 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R2010 1253700 MEGWI-CH 8K2 F 0603 G BAW SPE0028A323
R2011 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R2012 1291181 MEGWI-CH 5K6 F 0603 G BAW SPE0028A323
R2013 1291181 MEGWI-CH 5K6 F 0603 G BAW SPE0028A323
R202 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R203 1254448 MEGWI-CH 27K F 0603 G BAW SPE0028A323
R204 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R205 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R206 1304232 MEGWI-CH 47R F 0603 G BAW SPE0027A323
R207 1254431 MEGWI-CH 20K F 0603 G BAW SPE0028A323
R208 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R209 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R210 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R211 1304399 MEGWI-CH 390R F 0603 BAW SPE0027A323
R212 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R213 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R214 1246623 MEGWI-CH 430K F 0603 G BAW SPE0028A323
R215 1304496 MEGWI-CH 3K9 F 0603 G BAW SPE0028A323
R221 1258478 MEGWI-CH 15K F 0603 BAW SPE0028A323
R222 1258486 MEGWI-CH 39K F 0603 BAW SPE0028A323
R223 1257838 NTCWI-CH 220R J 0805 SIE B57620-C221-J62
R224 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R225 1304380 MEGWI-CH 330R F 0603 BAW SPE0027A323
R227 1282700 MEGWI-CH 120K F 0603 G BAW SPE 0028A323
R228 1282662 MEGWI-CH 180K F 0603 G BAW SPE0028A323
R229 1304488 MEGWI-CH 2K7 F 0603 BAW SPE0028A323
20.06.2000
Ersatzteile Typ:3100 Seite:13 von 17
R230 1313185 MEGWI-CH 51K F 0603 G BAW SPE 0028 A 323
R231 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R232 1305131 MEGWI-CH 68K F 0603 BAW SPE0028A323
R235 1254340 MEGWI-CH 270K F 0603 G BAW SPE0028A323
R236 1305018 MEGWI-CH 150K F 0603 BAW SPE0028A323
R240 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R241 1271202 MEGWI-CH 220K F 0603 G BAW SPE0028A323
R242 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R243 1305069 MEGWI-CH 560K F 0603 BAW SPE0028A323
R244 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R245 1304402 MEGWI-CH 470R F 0603 BAW SPE0027A323
R246 1305131 MEGWI-CH 68K F 0603 BAW SPE0028A323
R247 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R248 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R249 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R251 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R252 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R253 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R254 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R255 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R256 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R257 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R269 1304348 MEGWI-CH 220R F 0603 BAW SPE0027A323
R270 1304313 MEGWI-CH 130R F 0603 G BAW SPE0027A323
R271 1304348 MEGWI-CH 220R F 0603 BAW SPE0027A323
R274 1277588 MEGWI-CH 330K F 0603 G BAW SPE 0028A323
R275 1302965 MEGWI-CH 130K F 0603 G BAW SPE0028A323
R276 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R277 1304348 MEGWI-CH 220R F 0603 BAW SPE0027A323
R279 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R285 1304402 MEGWI-CH 470R F 0603 BAW SPE0027A323
R287 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R288 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R290 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R296 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R297 1304291 MEGWI-CH 110R F 0603 G BAW SPE0027A323
R301 1305050 MEGWI-CH 470K F 0603 BAW SPE0028A323
R302 1304852 MEGWI-CH 47R F 0805 G BAW SPE0017A323
R306 1254022 MEGWI-CH 2K2 F 0603 G BAW SPE0028A323
R307 1304178 MEGWI-CH 18R F 0603 BAW SPE0027A323
R312 1304402 MEGWI-CH 470R F 0603 BAW SPE0027A323
R313 1288415 MEGWI-CH 6K8 F 0603 G BAW SPE 0028A323
R316 1304259 MEGWI-CH 68R F 0603 BAW SPE0027A323
R317 1304380 MEGWI-CH 330R F 0603 BAW SPE0027A323
R318 1305093 MEGWI-CH 1M F 0603 BAW SPE0028A323
R321 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R323 1304399 MEGWI-CH 390R F 0603 BAW SPE0027A323
R324 1304380 MEGWI-CH 330R F 0603 BAW SPE0027A323
R327 1258478 MEGWI-CH 15K F 0603 BAW SPE0028A323
R328 1304461 MEGWI-CH 1K5 F 0603 G BAW SPE0028A323
20.06.2000
Ersatzteile Typ:3100 Seite:14 von 17
R329 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R331 1281811 MEGWI-CH 1K8 F 0603 G BAW SPE0028A323
R347 1305131 MEGWI-CH 68K F 0603 BAW SPE0028A323
R348 1282700 MEGWI-CH 120K F 0603 G BAW SPE 0028A323
R349 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R350 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R351 1254340 MEGWI-CH 270K F 0603 G BAW SPE0028A323
R352 1254324 MEGWI-CH 24K F 0603 G BAW SPE0028A323
R353 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R360 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R361 1254421 MEGWI-CH 12K F 0603 G BAW SPE0028A323
R362 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R363 1282662 MEGWI-CH 180K F 0603 G BAW SPE0028A323
R364 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R365 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R370 1018302 MEGWI-CH 0R 0805 G BAW SPE0009A323
R50 1303112 MEGWI-CH 15R F 1206 G BAW SPE0015A323
R501 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R506 1281811 MEGWI-CH 1K8 F 0603 G BAW SPE0028A323
R507 1281811 MEGWI-CH 1K8 F 0603 G BAW SPE0028A323
R508 1281811 MEGWI-CH 1K8 F 0603 G BAW SPE0028A323
R509 1281811 MEGWI-CH 1K8 F 0603 G BAW SPE0028A323
R51 1303112 MEGWI-CH 15R F 1206 G BAW SPE0015A323
R52 1303112 MEGWI-CH 15R F 1206 G BAW SPE0015A323
R602 1159496 MEGWI-CH 22K F 0805 G BAW SPE0018A323
R603 1285564 MEGWI-CH 4K7 F 0603 G BAW SPE0028A323
R604 1258478 MEGWI-CH 15K F 0603 BAW SPE0028A323
R605 1258486 MEGWI-CH 39K F 0603 BAW SPE0028A323
R608 1304364 MEGWI-CH 270R F 0603 BAW SPE0027A323
R609 1304283 MEGWI-CH 100R F 0603 BAW SPE0027A323
R614 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R615 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R618 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R619 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R620 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R621 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R623 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R701 1304526 MEGWI-CH 11K F 0603 G TK100 BAW SPE0028A
R702 1304518 MEGWI-CH 16K F 0603 G BAW SPE0028A323
R703 1282662 MEGWI-CH 180K F 0603 G BAW SPE0028A323
R704 1304283 MEGWI-CH 100R F 0603 BAW SPE0027A323
R711 1304526 MEGWI-CH 11K F 0603 G TK100 BAW SPE0028A
R712 1304518 MEGWI-CH 16K F 0603 G BAW SPE0028A323
R713 1282662 MEGWI-CH 180K F 0603 G BAW SPE0028A323
R714 1304283 MEGWI-CH 100R F 0603 BAW SPE0027A323
R720 1248197 MEGWI-CH 18K F 0603 G BAW SPE0028A323
R721 1304496 MEGWI-CH 3K9 F 0603 G BAW SPE0028A323
R722 1305131 MEGWI-CH 68K F 0603 BAW SPE0028A323
R723 1305050 MEGWI-CH 470K F 0603 BAW SPE0028A323
R725 1305001 MEGWI-CH 33K F 0603 BAW SPE0028A323
20.06.2000
Ersatzteile Typ:3100 Seite:15 von 17
R726 1305001 MEGWI-CH 33K F 0603 BAW SPE0028A323
R727 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R728 1304161 MEGWI-CH 10R F 0603 BAW SPE0027A323
R729 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R730 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R732 1227661 MEGWI-CH 0R 0603 BAW SPE0025A323
R735 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R736 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R809 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R810 1226657 MEGWI-CH 1K F 1206 BAW SPE0016A323
R811 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R820 1283367 MEGWI-CH 10R F 1206 G TK100 BAW0015A323
R821 1283367 MEGWI-CH 10R F 1206 G TK100 BAW0015A323
R822 1283367 MEGWI-CH 10R F 1206 G TK100 BAW0015A323
R830 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R831 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R832 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R833 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R834 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R835 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R836 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R837 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R838 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R839 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R841 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R842 1305050 MEGWI-CH 470K F 0603 BAW SPE0028A323
R843 1271199 MEGWI-CH 56K F 0603 G BAW SPE0028A323
R844 1226592 MEGWI-CH 100R F 1206 BAW SPE0015A323
R845 1304348 MEGWI-CH 220R F 0603 BAW SPE0027A323
R846 1159496 MEGWI-CH 22K F 0805 G BAW SPE0018A323
R847 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R848 1305131 MEGWI-CH 68K F 0603 BAW SPE0028A323
R850 1258478 MEGWI-CH 15K F 0603 BAW SPE0028A323
R851 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R852 1254022 MEGWI-CH 2K2 F 0603 G BAW SPE0028A323
R853 1304429 MEGWI-CH 680R F 0603 BAW SPE0027A323
R854 1304186 MEGWI-CH 22R F 0603 BAW SPE0027A323
R855 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R857 1304186 MEGWI-CH 22R F 0603 BAW SPE0027A323
R859 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R860 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R861 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R862 1254421 MEGWI-CH 12K F 0603 G BAW SPE0028A323
R863 1235397 MEGWI-CH 3K3 F 0603 G BAW SPE0028A323
R864 1305158 MEGWI-CH 100K F 0603 BAW SPE0028A323
R865 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R872 1328417 MEGWI-CH 1K6 F 0603 G BAW SPE0028A323
R873 1328417 MEGWI-CH 1K6 F 0603 G BAW SPE0028A323
R881 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R882 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
20.06.2000
Ersatzteile Typ:3100 Seite:16 von 17
R883 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R885 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R886 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R887 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R888 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R890 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R891 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R892 1297058 MEGWI-CH 22K F 0603 G BAW SPE0028A323
R893 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R897 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R898 1297041 MEGWI-CH 10K F 0603 G BAW SPE0028A323
R908 1304283 MEGWI-CH 100R F 0603 BAW SPE0027A323
R914 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R915 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R916 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R920 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R934 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R935 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R942 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R947 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R956 1304445 MEGWI-CH 1K F 0603 BAW SPE0028A323
R957 1304410 MEGWI-CH 560R F 0603 BAW SPE0027A323
R988 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R989 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R998 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
R999 1254332 MEGWI-CH 47K F 0603 G BAW SPE0028A323
RN900 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN901 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN9010 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN902 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN903 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN904 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN905 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN906 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN907 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN908 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
RN909 1298720 WID-NETZ 4X1K J ROH MNR14 E0ABJ102
S1831 1319167 ENCODER ALP EC11E 15244
SP101 1031112 UEBERSPG-ABLEITER MMC DSP-201M-A21R
ST701 1158041 STIFTLEISTE 19POL D&R 3 302 02 01 1490
ST801 1252641 DRUCKFEDER-STECKVERB. AMP 969600-1
T101 1258680 TRANSISTOR-CH TEL S949TR G
T1151 1303317 TRANSISTOR-CH SAY 2SC2814 F4+F5 NPN G
T151 1289772 TRANSISTOR-CH SIE BCR 198S PNP G
T1801 0659614 TRANSISTOR-CH BAW BC848B G SPE0003A
T1802 0675318 TRANSISTOR-CH BAW BC818-16 SHIP-TO-STOCK
T1803 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T1805 1239066 TRANS.-CH BAW KRC104S/BCR148/DTC144
T1806 1182821 TRANSISTOR-CH BAW KRC102S/DTC114 NP
T201 1303317 TRANSISTOR-CH SAY 2SC2814 F4+F5 NPN G
20.06.2000
Ersatzteile Typ:3100 Seite:17 von 17
T202 1303317 TRANSISTOR-CH SAY 2SC2814 F4+F5 NPN G
T203 1290924 TRANSISTOR-CH SIE BC847PN G
T204 1307541 TRANSISTOR-CH SIE BC847S NPN G
T205 1307541 TRANSISTOR-CH SIE BC847S NPN G
T206 1289799 TRANSISTOR-CH SIE BCR 108S NPN G
T211 1307551 TRANSISTOR-CH SIE BC857S PNP G
T301 1180576 TRANSISTOR BAW J109/110 SELEKT.G SP
T302 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T304 1028049 TRANSISTOR-CH BAW BC858C G SPE0002A302
T341 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T501 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T502 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T601 1280260 TRANSISTOR BAW 2SD2394F/2SD1913S SPE0062
T602 1028049 TRANSISTOR-CH BAW BC858C G SPE0002A302
T606 0672521 TRANSISTOR-CH BAW BC856B G SPE0013A
T607 1258079 TRANSISTOR-CH BAW BC846B G SPE0035A302
T702 1253611 TRANSISTOR-CH BAW BCR158/DTA123JC SPE006
T805 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T806 1182821 TRANSISTOR-CH BAW KRC102S/DTC114 NP
T807 1248499 TRANSISTOR-CH BAW BCX52-16 G SPE0060A302
T808 1214594 TRANSISTOR-CH BAW KRA102S/BCR183 SP
T840 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T841 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T842 0659614 TRANSISTOR-CH BAW BC848B G SPE0003A
T843 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T852 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T853 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T854 1028006 TRANSISTOR-CH BAW BC817-40 SHIP-TO-STOCK
T855 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T861 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T870 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T885 1028049 TRANSISTOR-CH BAW BC858C G SPE0002A302
T890 1028049 TRANSISTOR-CH BAW BC858C G SPE0002A302
20.06.2000
Ersatzteile Typ:3100 Seite:18 von 18
2
3
4
24
5
9 8 7 6
12
14 15 18 19
24
17 22 16 21 23 20
13
25 26
28
30
29 27
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
