Image preview - the first page of the document
>> Download BE3201 documenatation <<
Text preview - extract from the document
Spare Parts List Type:3201 Page:1 of 18
Pos. Part.-No. Denomination
1 1246909 HEAT SINK 3310 WGR11318
2 1246917 IC-HOLDER
3 1246992 SCREENING FRAME-FM- WITH ANT.SOCKET
4 1258842 COVER, SCREENING-FM/BS
5 1247034 COVER, SCREENING-FM/LS
6 1278916 CONNECTOR 21 POL D&R K37000300
7 1244744 TAPEDECK ASSY ALP GR71-S36B (MJ'98)
8 OPERATION ESCUTCHEON (NOT AVAILABLE CPL)
9 1321293 P.C. BOARD 9090 FRONT/LCD
10 1294369 OPERATION ESCUTCHEON MOBIL 3201
11 1294407 COVER,MOBIL AUDIO 10 EXP 3201
12 1295373 TRIMPLATE MOBIL KPL. LEFT
13 1334182 KEY SC
14 1334190 KEY AS
15 1334204 KEY TONE
16 1334220 KEY SPEAKER 3201
17 1322737 TRIMPLATE FIX KPL. RIGHT 3201
18 1334239 KEY 1 2
19 1334247 KEY EJECT
20 1334263 KEY SW
21 1334281 KEY LW
22 1279238 TORSIO SPRING 3200
23 1279246 CLOSING FLAP 3200
24 1284177 BUTTON 3300
25 1279033 RELEASE BUTTON 3200
26 1284241 PRESSURE SPRING 3300
27 1277065 CHASSIS 3300
28 1309765 COVER, CHASSIS 3200
29 1284622 HOLDING SPRING-RIGHT 3300
30 1284630 HOLDING SPRING-LEFT 3300
C101 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315
C103 1223909 CECA-CH 1P5 J NP0 0603 BAW SPE0030A315
C104 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C105 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C106 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C107 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C108 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C109 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C110 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C111 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C112 1288180 CECA-CH 1P8 J NPO 0603 BAW SPE0030A315
C113 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315
C114 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C115 1238787 CECA-CH 5P6 J NP0 0603 BAW SPE0030A315
C116 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315
C117 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C118 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315
C120 1238787 CECA-CH 5P6 J NP0 0603 BAW SPE0030A315
06.09.99
Spare Parts List Type:3201 Page:2 of 18
C121 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C122 1243012 CECA-CH 27P J NPO 0603 BAW SPE0030A315
C123 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315
C125 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C126 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C127 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C128 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C151 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C152 1223941 CECA-CH 18P J NP0 0603 BAW SPE0030A315
C153 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C154 1166409 CECA-CH 6N8 J X7R 0805 BAW SPE0014A315
C155 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C156 0356417 KS-FOCAP 6N8 K 100V G WIM FKS2-RM5
C157 1277790 CECA-CH 680P J COH 0603 25V G MUR GRM39
C158 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315
C159 1249169 ELCA 47U M 16V BAW SPE0068A312-RM2,5
C160 1223992 CECA-CH 150P J NP0 0603 BAW SPE0030A315
C161 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C162 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C165 1119222 CECA-CH 470P K X7R 0805 BAW SPE0015A315
C166 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C168 1249169 ELCA 47U M 16V BAW SPE0068A312-RM2,5
C169 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C1801 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C1802 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C1803 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C1804 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C1805 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C1806 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C1807 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C1809 1238647 TACA-CH 1U K B G 35V BAW SPE0005A313
C1810 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315
C1811 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C1836 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315
C1861 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C1900 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1901 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1902 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1903 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1904 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1905 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1906 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C1907 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C204 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C206 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315
C207 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C209 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C210 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315
C211 1073516 CECA-CH 150P J NP0 0805 BAW SPE0003A315
06.09.99
Spare Parts List Type:3201 Page:3 of 18
C212 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315
C213 1276220 CECA-CH 2N2 J X7R 0805 50V BAW SPE0014A
C214 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315
C215 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C217 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315
C218 1066110 CECA-CH 470P J NP0 0805 BAW SPE0003A315
C219 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C226 1234897 CECA-CH 150P J P2H 0603 MUR GRM39
C227 1270788 CECA-CH 1N2 J S2H 1206 50V MUR GRM42-6
C232 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C233 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C234 1119192 CECA-CH 33N K X7R 0805 BAW SPE0015A315
C235 1246321 CECA-CH 220N K X7R 1206 BAW SPE0036A315
C236 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C237 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C238 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C239 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C240 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C241 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C251 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315
C252 1272357 TACA-CH 6U8 K B G 16V SNPB SIE B45196-H
C253 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C301 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C303 1246321 CECA-CH 220N K X7R 1206 BAW SPE0036A315
C304 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C310 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C312 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C314 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315
C315 1223984 CECA-CH 68P J NP0 0603 BAW SPE0030A315
C317 1223941 CECA-CH 18P J NP0 0603 BAW SPE0030A315
C319 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C321 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C322 1119060 CECA-CH 1N K X7R 0805 BAW SPE0015A315
C323 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C324 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C325 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C327 1223968 CECA-CH 33P J NP0 0603 BAW SPE0030A315
C328 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C329 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C330 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C331 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C332 1246380 CECA-CH 3P9 C NP0 0603 BAW SPE0031A315
C333 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C334 1246208 CECA-CH 330N J X7R 1206 25V MUR GRM42-6
C335 1246208 CECA-CH 330N J X7R 1206 25V MUR GRM42-6
C336 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C337 1258796 CECA-CH 56P J S2H 0603 50V MUR GRM39
C338 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C339 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
06.09.99
Spare Parts List Type:3201 Page:4 of 18
C340 1244035 CECA-CH 560P J U2J 0603 MUR GRM39
C343 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C344 1225545 CECA-CH 120P J 0603 NP0 BAW SPE0030A315
C345 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C346 1162241 CECA-CH 470P G NP0 0805 BAW SPE0027A315
C347 1162284 CECA-CH 560P G NP0 0805 BAW SPE0027A315
C348 1162365 CECA-CH 2N G NP0 1206 BAW SPE0028A315
C349 1162322 CECA-CH 1N G NP0 1206 BAW SPE0028A315
C350 1270540 CECA-CH 560P J NPO 0603 50V MUR GRM39
C352 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C353 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C354 1283499 CECA-CH 1U K X7R 0805 10V MUR GRM 40
C355 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C356 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C357 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315
C365 1243012 CECA-CH 27P J NPO 0603 BAW SPE0030A315
C368 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C374 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C375 1259253 CECA-CH 220P J NPO 0603 BAW SPE0030A315
C380 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C423 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C424 1258907 CAP-CH 1U M 50V I G BAW SPE0161A312
C425 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C426 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C427 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C428 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C429 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315
C430 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315
C431 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315
C432 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315
C433 1083945 CECA-CH 2N7 J NP0 1206 BAW SPE0007A315
C434 1083945 CECA-CH 2N7 J NP0 1206 BAW SPE0007A315
C435 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C436 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C437 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C438 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315
C439 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C440 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C441 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C442 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C449 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C450 1119060 CECA-CH 1N K X7R 0805 BAW SPE0015A315
C451 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C452 1066102 CECA-CH 330P J NP0 0805 BAW SPE0003A315
C453 1119060 CECA-CH 1N K X7R 0805 BAW SPE0015A315
C454 1119060 CECA-CH 1N K X7R 0805 BAW SPE0015A315
C455 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C456 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315
C457 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315
06.09.99
Spare Parts List Type:3201 Page:5 of 18
C458 1119079 CECA-CH 2N7 K X7R 0805 BAW SPE0015A315
C459 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315
C460 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C471 1171984 ELCA 10U M 35V G BAW SPE0053A31 RM2,5
C472 1083899 CECA-CH 820P J NP0 1206 BAW SPE0006A315
C473 1171984 ELCA 10U M 35V G BAW SPE0053A31 RM2,5
C474 1083899 CECA-CH 820P J NP0 1206 BAW SPE0006A315
C475 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315
C483 1253441 FOCAP-CH 10N J 1206 50V G PAN ECHU
C484 1253441 FOCAP-CH 10N J 1206 50V G PAN ECHU
C485 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C486 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C487 1171984 ELCA 10U M 35V G BAW SPE0053A31 RM2,5
C488 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C501 1186973 ELCA 1M M 25V G BAW SPE0074A312-RM5
C502 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C506 1281641 FOCAP 470N J 50V G BAW SPE0018A314 RM5
C507 1281641 FOCAP 470N J 50V G BAW SPE0018A314 RM5
C508 1281641 FOCAP 470N J 50V G BAW SPE0018A314 RM5
C509 1281641 FOCAP 470N J 50V G BAW SPE0018A314 RM5
C521 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C522 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C523 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C524 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C525 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C526 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C527 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C528 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C601 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C602 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C603 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C604 1290282 ELCA 2M2 M 25V G BAW SPE0084A312RM7,5
C605 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C606 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C607 1253360 ELCA 56U M 2000/105 16V NCC SXE-VB F0
C609 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C610 1253360 ELCA 56U M 2000/105 16V NCC SXE-VB F0
C611 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C612 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C613 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C614 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C616 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C617 1073516 CECA-CH 150P J NP0 0805 BAW SPE0003A315
C618 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C619 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C620 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C621 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C622 1229974 ELCA 100U M 25V I G BAW SPE0108 RM2,5
C623 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
06.09.99
Spare Parts List Type:3201 Page:6 of 18
C626 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C627 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C628 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C629 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315
C702 1281437 FOCAP 100N J 63V G BAW SPE0015A314 RM5
C704 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C705 1281283 FOCAP 15N J 63V G BAW SPE0010A314 RM5
C706 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315
C707 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315
C712 1281437 FOCAP 100N J 63V G BAW SPE0015A314 RM5
C714 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C715 1281283 FOCAP 15N J 63V G BAW SPE0010A314 RM5
C716 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315
C717 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315
C720 1249150 ELCA 22U M 16V BAW SPE0067A312-RM2,5
C721 1252585 CECA-CH 470N J X5R 1206 16V MUR GRM42-6
C722 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315
C723 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C724 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C725 1172085 ELCA 100U M 16V G BAW SPE0063A3 RM2,5
C780 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C781 1258877 ELCA 4U7 M 50V G BAW SPE0049A31 RM2,5
C782 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C783 1171984 ELCA 10U M 35V G BAW SPE0053A31 RM2,5
C784 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C785 1223968 CECA-CH 33P J NP0 0603 BAW SPE0030A315
C786 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C788 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C789 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C790 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C791 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C792 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C793 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C794 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C795 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C796 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C797 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315
C798 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C799 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315
C801 1258907 CAP-CH 1U M 50V I G BAW SPE0161A312
C802 1171895 ELCA 2U2 M 50V G BAW SPE0044A3 RM2,5
C803 1258907 CAP-CH 1U M 50V I G BAW SPE0161A312
C805 1113259 CECA-CH 1N K X7R 1206 BAW SPE0017A315
C806 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C807 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C808 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C809 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C810 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C811 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
06.09.99
Spare Parts List Type:3201 Page:7 of 18
C812 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C813 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C814 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C815 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C816 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C817 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C818 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C819 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C820 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315
C821 1229974 ELCA 100U M 25V I G BAW SPE0108 RM2,5
C850 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315
C851 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C852 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315
C854 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C856 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C857 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C908 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C909 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315
C919 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C928 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C929 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C939 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C949 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C958 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C968 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C969 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C980 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
C981 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315
D101 1156128 INDUCTOR-CH G MUR BLM21B050S
D102 1178237 CHOKE-CH 2,2UH K G SIE B82422-A1222-K
D152 1246811 CHOKE-CH 47UH K G SIE B82432-A1473-K
D1801 1227221 INDUCTOR-CH G MUR BLM11A221S
D301 1178237 CHOKE-CH 2,2UH K G SIE B82422-A1222-K
D302 1148494 CHOKE-CH 0,47UH J G SIE B82422-A3471-J
D472 1237705 INDUCTOR-CH G MUR BLM21A601S
D601 1244922 CHOKE,BATT.- 200UH VOG 5730409900
D602 1237705 INDUCTOR-CH G MUR BLM21A601S
D603 1237705 INDUCTOR-CH G MUR BLM21A601S
D604 1237705 INDUCTOR-CH G MUR BLM21A601S
D780 1237705 INDUCTOR-CH G MUR BLM21A601S
D781 1000950 CHOKE-CH 47UH K G SIE B82422-A1473-K
D901 1237705 INDUCTOR-CH G MUR BLM21A601S
D909 1237705 INDUCTOR-CH G MUR BLM21A601S
D920 1237705 INDUCTOR-CH G MUR BLM21A601S
D930 1237705 INDUCTOR-CH G MUR BLM21A601S
D980 1237705 INDUCTOR-CH G MUR BLM21A601S
DI101 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30
DI102 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30
DI103 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30
06.09.99
Spare Parts List Type:3201 Page:8 of 18
DI104 1225529 DIODE-CH TEL S391D G
DI1801 1252143 DIODE-CH PHI BAS216 G
DI1803 1252143 DIODE-CH PHI BAS216 G
DI1804 1252143 DIODE-CH PHI BAS216 G
DI1805 1252143 DIODE-CH PHI BAS216 G
DI231 1252143 DIODE-CH PHI BAS216 G
DI251 1252143 DIODE-CH PHI BAS216 G
DI301 1229788 DIODE-CH BAW BA779-2/1SV234/DPA05 G SPE
DI302 1252143 DIODE-CH PHI BAS216 G
DI304 1252143 DIODE-CH PHI BAS216 G
DI305 1252143 DIODE-CH PHI BAS216 G
DI306 1073656 DIODE-CH BAW BAV99 SHIP-TO-ST.G SPE0030A
DI311 1252143 DIODE-CH PHI BAS216 G
DI321 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30
DI501 1252143 DIODE-CH PHI BAS216 G
DI601 1179683 DIODE-CH GIC S3B G
DI603 1118757 DIODE-CH BAW 6V8 5% SHIP-TO-STOCK G SPE0
DI604 1252143 DIODE-CH PHI BAS216 G
DI605 1252143 DIODE-CH PHI BAS216 G
DI606 1252143 DIODE-CH PHI BAS216 G
DI607 1252143 DIODE-CH PHI BAS216 G
DI784 1148842 DIODE-CH BAW 4V7 SHIP-TO-STOCK G SPE0022
DI785 0672475 DIODE-CH BAW BAV70 SHIP-TO-STOCK G SPE00
DI801 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A
DI850 1252143 DIODE-CH PHI BAS216 G
DI851 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A
DI852 1252143 DIODE-CH PHI BAS216 G
DI853 1252143 DIODE-CH PHI BAS216 G
DI854 1252143 DIODE-CH PHI BAS216 G
DI855 1252143 DIODE-CH PHI BAS216 G
DI856 1076353 DIODE-CH BAW 5V6 2% SHIP-TO-STOCK G SPE0
DI857 1252143 DIODE-CH PHI BAS216 G
F102 1270486 FILTER, FMV- 100MHZ TOK/P666SNS-286IB-BR
F104 1253395 FILTER, FMZ- 100MHZ TOK/P666SNS-256Z-RT
F105 1284827 FILTER,AMO/FMO-120MHZ TOK VAG,VWA,GEA
F201 1270291 FILTER,FM-ZF- 10,7MHZ TOK C805PN-0642UH
F204 1291637 FILTER,FM-PHASENKR.-10,7MHZ MSI RA7008-2
F321 1284827 FILTER,AMO/FMO-120MHZ TOK VAG,VWA,GEA
F341 1246003 FILTER,AM-ZF 450KHZ TOK C805LN-0586N-SW
F342 1258028 FILTER,AM-ZF1- 10,7MHZ TOK C805PN-0640-U
F343 1275984 FILTER,+B24AM-PH 450KHZ SGM5CG-960954187-SW
IC101 1223518 IC-CH TEL U4065B-MFL G
IC151 1223526 IC-CH TEL U4283BM-BFS G
IC1801 0901806 IC-CH PHI PCF8576T/F2 SHIP-TO-STOCK G
IC1802 1299662 IC-CH NEC UPD 754302-3200-04/98
IC201 1220357 IC-CH SIE TDA4320X G
IC231 1239139 IC-CH TEL U4275B
IC301 1254308 IC-CH SIE TDA4362-P-MQFP-44-2 G
IC421 1247921 IC-CH SGT TDA7340TR G
06.09.99
Spare Parts List Type:3201 Page:9 of 18
IC471 1250477 IC-CH CRY CS4331-BSR G
IC472 1250485 IC-CH CRY CS5331A-BSR G
IC501 1271180 IC PHI TDA8569Q /N1
IC601 1240481 IC-CH SIE BSP452 G
IC602 1258397 IC-CH SIE TLE4276GV P-TO220-5-122
IC603 1246674 IC-CH SIE TLE4269GL P-DSO20-6 G
IC604 1286242 IC-CH TOS TC7S14F G
IC701 1246607 IC-CH SOY CXA2510Q
IC702 1245996 IC-CH PHI 74HC03D,653 G
IC780 1239147 IC-CH AUM OCC8001-01
IC781 1249101 IC-CH TOS TC7S08F G
IC901 1245058 IC-CH SIE SAF-C515C-8R P-MQFP-80
IC902 1185616 IC-CH PHI PC74HC573D G
IC903 1230964 IC-SOCKET 32POL STANDARD BAW SPE000
IC903 1319965 IC-BAW 27C010-3201-42/98 3201
IC904 1305859 IC-CH SAY LC3564BM-10 TE-L
IC905 1185616 IC-CH PHI PC74HC573D G
IC906 1185616 IC-CH PHI PC74HC573D G
IC909 0588121 IC-CH PHI PC74HC02D G
IC980 1012071 IC-CH BAW 74HC4094 G SPE0005A308
IC981 1012071 IC-CH BAW 74HC4094 G SPE0005A308
KF201 1306987 K-FILT MUR SFE 10,7 MS3A10GJ24-A-S-TF21
KF202 1306987 K-FILT MUR SFE 10,7 MS3A10GJ24-A-S-TF21
KF203 1307010 K-FILT.MUR SFE 10,7MHZ MJA10J24-A-S-TF21
KF204 1306987 K-FILT MUR SFE 10,7 MS3A10GJ24-A-S-TF21
KF341 1237713 CERA-FILTER MUR CFWS 450 IT
KF343 1237721 CERA-FILTER MUR CFWS 450 HT
L101 1235915 AIR COIL 14WDG 4,0 0,4 1088
L312 1252615 CHOKE-CH 220UH K G SIE B82432-S1224-K
L313 1252615 CHOKE-CH 220UH K G SIE B82432-S1224-K
L315 1245368 CHOKE-CH 68UH K G SIE B82432-S1683-K
L317 1245368 CHOKE-CH 68UH K G SIE B82432-S1683-K
L320 1252615 CHOKE-CH 220UH K G SIE B82432-S1224-K
L322 1249398 CHOKE-CH 2,2MH K G MSI C6-R/3333
L380 1000942 CHOKE-CH 10UH K G SIE B82422-A1103-K
LD1801 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1802 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1803 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1804 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1805 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1806 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1807 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1808 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1809 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1810 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1811 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1812 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1813 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1814 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
06.09.99
Spare Parts List Type:3201 Page:10 of 18
LD1831 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1832 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1833 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1834 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1835 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1836 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1837 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1838 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1839 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1840 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1841 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1842 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1843 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1844 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1845 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1846 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1847 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1848 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1849 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1850 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1851 1285122 LED-CH SIE LYT670E9349 K2/U Q62703-Q4228
LD1861 1158767 LED-CH SIE LST670 G -RT
OT780 1248121 TRANSCEIVER AMP 966893 D2BOPTICAL-HEADER
P251 1245090 TRIRES-CH 5K LIN 0,10W MUR RVG3A08-
P701 1246615 TRIRES-CH 10K 0,10W MUR POZ3AN1-103N-T00
P702 1246615 TRIRES-CH 10K 0,10W MUR POZ3AN1-103N-T00
Q151 1280279 QUARTZ 10,250 MHZ G NDK AT-51 M.ISOPL.
Q1801 1171501 CERA-RESON-CH MUR CSAC 4,19 MGCA G
Q451 1245112 CERA-RESON-CH MUR CSBF456JF211 G
Q780 1283464 QUARTZ 16,9344 MHZ G NDK AT-51 M.ISOPL.
Q901 1295691 QUARTZ 10MHZ TQG TQX6674 MIT ISOPL.
QF342 1287796 QUARTZ-FILTER-CH 10,700 MHZ NDK 10U 7,5A
R101 1304402 RES-CH 470R F 0603 BAW SPE0027A323
R102 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R103 1304224 RES-CH 39R F 0603 BAW SPE0027A323
R104 1304895 RES-CH 100R F 0805 G BAW SPE0017A323
R105 1277588 RES-CH 330K F 0603 G BAW SPE 0028A323
R106 1271199 RES-CH 56K F 0603 G BAW SPE0028A323
R112 1304895 RES-CH 100R F 0805 G BAW SPE0017A323
R121 1305131 RES-CH 68K F 0603 BAW SPE0028A323
R122 1305131 RES-CH 68K F 0603 BAW SPE0028A323
R123 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R125 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R130 1291181 RES-CH 5K6 F 0603 G BAW SPE0028A323
R131 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R151 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R152 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R153 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R154 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:11 of 18
R155 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R156 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R157 1254421 RES-CH 12K F 0603 G BAW SPE0028A323
R158 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R159 1288415 RES-CH 6K8 F 0603 G BAW SPE 0028A323
R160 1254421 RES-CH 12K F 0603 G BAW SPE0028A323
R161 1254421 RES-CH 12K F 0603 G BAW SPE0028A323
R162 1254421 RES-CH 12K F 0603 G BAW SPE0028A323
R163 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R164 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R165 1304194 RES-CH 27R F 0603 BAW SPE0027A323
R166 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R167 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R168 1258486 RES-CH 39K F 0603 BAW SPE0028A323
R169 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R175 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R1801 1303511 RES-CH 560R F 1206 G BAW SPE0015A323
R1802 1293206 RES-CH 1K5 F 1206 BAW SPE0016A323
R1803 1293206 RES-CH 1K5 F 1206 BAW SPE0016A323
R1804 1293206 RES-CH 1K5 F 1206 BAW SPE0016A323
R1805 1293206 RES-CH 1K5 F 1206 BAW SPE0016A323
R1806 1303449 RES-CH 270R F 1206 G BAW SPE0015A323
R1807 1303449 RES-CH 270R F 1206 G BAW SPE0015A323
R1808 1303449 RES-CH 270R F 1206 G BAW SPE0015A323
R1809 1226630 RES-CH 390R F 1206 BAW SPE0015A323
R1810 1226630 RES-CH 390R F 1206 BAW SPE0015A323
R1811 1303511 RES-CH 560R F 1206 G BAW SPE0015A323
R1812 1303511 RES-CH 560R F 1206 G BAW SPE0015A323
R1813 1226657 RES-CH 1K F 1206 BAW SPE0016A323
R1814 1303491 RES-CH 470R F 1206 G BAW SPE0015A323
R1815 1226649 RES-CH 680R F 1206 BAW SPE0015A323
R1816 1304461 RES-CH 1K5 F 0603 G BAW SPE0028A323
R1817 1304437 RES-CH 820R F 0603 BAW SPE0027A323
R1818 1304437 RES-CH 820R F 0603 BAW SPE0027A323
R1819 1304437 RES-CH 820R F 0603 BAW SPE0027A323
R1825 1303538 RES-CH 820R F 1206 G BAW SPE0015A323
R1831 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R1832 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R1833 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R1834 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R1835 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R1836 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R1837 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R1839 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R1841 1304402 RES-CH 470R F 0603 BAW SPE0027A323
R1842 1285564 RES-CH 4K7 F 0603 G BAW SPE0028A323
R1844 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R1846 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R1847 1305158 RES-CH 100K F 0603 BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:12 of 18
R1848 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R1849 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R1850 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R1851 1304331 RES-CH 180R F 0603 BAW SPE0027A323
R1852 1304305 RES-CH 120R F 0603 G BAW SPE0027A323
R1854 1304402 RES-CH 470R F 0603 BAW SPE0027A323
R1861 1282662 RES-CH 180K F 0603 G BAW SPE0028A323
R1862 1288415 RES-CH 6K8 F 0603 G BAW SPE 0028A323
R1864 1288393 RES-CH 5K1 F 0603 G BAW SPE0028A323
R1865 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R201 1227661 RES-CH 0R 0603 BAW SPE0025A323
R202 1312928 RES-CH 7K5 F 0603 G BAW SPE 0028A323
R204 1271199 RES-CH 56K F 0603 G BAW SPE0028A323
R205 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R206 1250531 RES-CH 200K F 0603 G BAW SPE0028A323
R207 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R208 1304348 RES-CH 220R F 0603 BAW SPE0027A323
R209 1304380 RES-CH 330R F 0603 BAW SPE0027A323
R210 1304380 RES-CH 330R F 0603 BAW SPE0027A323
R211 1235389 RES-CH 2K4 F 0603 G BAW SPE0028A323
R212 1304232 RES-CH 47R F 0603 G BAW SPE0027A323
R213 1285564 RES-CH 4K7 F 0603 G BAW SPE0028A323
R214 1304781 RES-CH 10R F 0805 G BAW SPE0017A323
R216 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R217 1305085 RES-CH 820K F 0603 BAW SPE0028A323
R218 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R219 1305131 RES-CH 68K F 0603 BAW SPE0028A323
R220 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R226 1304313 RES-CH 130R F 0603 G BAW SPE0027A323
R228 1304348 RES-CH 220R F 0603 BAW SPE0027A323
R229 1304348 RES-CH 220R F 0603 BAW SPE0027A323
R231 1304186 RES-CH 22R F 0603 BAW SPE0027A323
R232 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R236 1304496 RES-CH 3K9 F 0603 G BAW SPE0028A323
R237 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R238 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R239 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R240 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R241 1305093 RES-CH 1M F 0603 BAW SPE0028A323
R242 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R243 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R245 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R246 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R247 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R251 1304453 RES-CH 1K2 F 0603 BAW SPE0028A323
R252 1304488 RES-CH 2K7 F 0603 BAW SPE0028A323
R253 1271202 RES-CH 220K F 0603 G BAW SPE0028A323
R254 1254456 RES-CH 82K F 0603 G BAW SPE0028A323
R255 1305158 RES-CH 100K F 0603 BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:13 of 18
R257 1227661 RES-CH 0R 0603 BAW SPE0025A323
R258 1291181 RES-CH 5K6 F 0603 G BAW SPE0028A323
R261 1285564 RES-CH 4K7 F 0603 G BAW SPE0028A323
R262 1227661 RES-CH 0R 0603 BAW SPE0025A323
R301 1305050 RES-CH 470K F 0603 BAW SPE0028A323
R302 1304852 RES-CH 47R F 0805 G BAW SPE0017A323
R303 1018302 RES-CH 0R 0805 G BAW SPE0009A323
R309 1304471 RES-CH 2K F 0603 G BAW SPE0028A323
R310 1304161 RES-CH 10R F 0603 BAW SPE0027A323
R311 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R313 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R314 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R319 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R320 1305018 RES-CH 150K F 0603 BAW SPE0028A323
R321 1271199 RES-CH 56K F 0603 G BAW SPE0028A323
R322 1291181 RES-CH 5K6 F 0603 G BAW SPE0028A323
R323 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R324 1304161 RES-CH 10R F 0603 BAW SPE0027A323
R326 1285564 RES-CH 4K7 F 0603 G BAW SPE0028A323
R330 1304161 RES-CH 10R F 0603 BAW SPE0027A323
R333 1255037 RES-CH 4K3 F 0603 G BAW SPE0028A323
R334 1281811 RES-CH 1K8 F 0603 G BAW SPE0028A323
R335 1304402 RES-CH 470R F 0603 BAW SPE0027A323
R340 1304161 RES-CH 10R F 0603 BAW SPE0027A323
R341 1304429 RES-CH 680R F 0603 BAW SPE0027A323
R343 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R344 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R345 1255037 RES-CH 4K3 F 0603 G BAW SPE0028A323
R347 1305131 RES-CH 68K F 0603 BAW SPE0028A323
R348 1282700 RES-CH 120K F 0603 G BAW SPE 0028A323
R349 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R350 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R351 1254340 RES-CH 270K F 0603 G BAW SPE0028A323
R352 1254324 RES-CH 24K F 0603 G BAW SPE0028A323
R353 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R355 1254421 RES-CH 12K F 0603 G BAW SPE0028A323
R360 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R361 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R362 1285564 RES-CH 4K7 F 0603 G BAW SPE0028A323
R378 1304259 RES-CH 68R F 0603 BAW SPE0027A323
R422 1291181 RES-CH 5K6 F 0603 G BAW SPE0028A323
R423 1291181 RES-CH 5K6 F 0603 G BAW SPE0028A323
R424 1305001 RES-CH 33K F 0603 BAW SPE0028A323
R425 1277588 RES-CH 330K F 0603 G BAW SPE 0028A323
R426 1304496 RES-CH 3K9 F 0603 G BAW SPE0028A323
R427 1253700 RES-CH 8K2 F 0603 G BAW SPE0028A323
R428 1304496 RES-CH 3K9 F 0603 G BAW SPE0028A323
R429 1253700 RES-CH 8K2 F 0603 G BAW SPE0028A323
R431 1304488 RES-CH 2K7 F 0603 BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:14 of 18
R432 1248197 RES-CH 18K F 0603 G BAW SPE0028A323
R433 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R451 1246623 RES-CH 430K F 0603 G BAW SPE0028A323
R452 1254448 RES-CH 27K F 0603 G BAW SPE0028A323
R453 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R454 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R455 1254456 RES-CH 82K F 0603 G BAW SPE0028A323
R461 1159496 RES-CH 22K F 0805 G BAW SPE0018A323
R471 1271199 RES-CH 56K F 0603 G BAW SPE0028A323
R472 1235389 RES-CH 2K4 F 0603 G BAW SPE0028A323
R473 1235389 RES-CH 2K4 F 0603 G BAW SPE0028A323
R474 1271199 RES-CH 56K F 0603 G BAW SPE0028A323
R483 1304321 RES-CH 150R F 0603 BAW SPE0027A323
R484 1304321 RES-CH 150R F 0603 BAW SPE0027A323
R501 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R601 1227831 RES-CH 10K F 0805 G BAW SPE0018A323
R602 1215647 RES-CH 220K F 0805 G BAW SPE0019A323
R603 1159569 RES-CH 47K F 0805 G BAW SPE0018A323
R604 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R605 1258486 RES-CH 39K F 0603 BAW SPE0028A323
R608 1233351 RES-CH 270R F 0805 G BAW SPE0017A323
R609 1304895 RES-CH 100R F 0805 G BAW SPE0017A323
R610 1240544 RES-CH 470R F 0805 BAW SPE0017A323
R612 1227831 RES-CH 10K F 0805 G BAW SPE0018A323
R613 1227831 RES-CH 10K F 0805 G BAW SPE0018A323
R614 1236271 RES-CH 68K F 0805 G BAW SPE0018A323
R615 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R616 1236271 RES-CH 68K F 0805 G BAW SPE0018A323
R617 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R618 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R619 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R620 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R621 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R623 1227661 RES-CH 0R 0603 BAW SPE0025A323
R624 1159496 RES-CH 22K F 0805 G BAW SPE0018A323
R625 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R626 1305131 RES-CH 68K F 0603 BAW SPE0028A323
R631 1303112 RES-CH 15R F 1206 G BAW SPE0015A323
R632 1303112 RES-CH 15R F 1206 G BAW SPE0015A323
R633 1303112 RES-CH 15R F 1206 G BAW SPE0015A323
R701 1304526 RES-CH 11K F 0603 G TK100 BAW SPE0028A
R702 1304518 RES-CH 16K F 0603 G BAW SPE0028A323
R703 1282662 RES-CH 180K F 0603 G BAW SPE0028A323
R704 1304283 RES-CH 100R F 0603 BAW SPE0027A323
R711 1304526 RES-CH 11K F 0603 G TK100 BAW SPE0028A
R712 1304518 RES-CH 16K F 0603 G BAW SPE0028A323
R713 1282662 RES-CH 180K F 0603 G BAW SPE0028A323
R714 1304283 RES-CH 100R F 0603 BAW SPE0027A323
R720 1248197 RES-CH 18K F 0603 G BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:15 of 18
R721 1304496 RES-CH 3K9 F 0603 G BAW SPE0028A323
R722 1305131 RES-CH 68K F 0603 BAW SPE0028A323
R723 1305050 RES-CH 470K F 0603 BAW SPE0028A323
R725 1305001 RES-CH 33K F 0603 BAW SPE0028A323
R726 1305001 RES-CH 33K F 0603 BAW SPE0028A323
R727 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R728 1304161 RES-CH 10R F 0603 BAW SPE0027A323
R729 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R730 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R731 1227661 RES-CH 0R 0603 BAW SPE0025A323
R780 1304755 RES-CH 1R5 F 0805 G BAW SPE0017A323
R781 1277588 RES-CH 330K F 0603 G BAW SPE 0028A323
R782 1271202 RES-CH 220K F 0603 G BAW SPE0028A323
R786 1304471 RES-CH 2K F 0603 G BAW SPE0028A323
R787 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R788 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R789 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R790 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R791 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R792 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R793 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R794 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R795 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R801 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R802 1254421 RES-CH 12K F 0603 G BAW SPE0028A323
R803 1235397 RES-CH 3K3 F 0603 G BAW SPE0028A323
R804 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R805 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R809 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R810 1226657 RES-CH 1K F 1206 BAW SPE0016A323
R811 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R813 1227661 RES-CH 0R 0603 BAW SPE0025A323
R820 1283367 RES-CH 10R F 1206 G TK100 BAW0015A323
R821 1283367 RES-CH 10R F 1206 G TK100 BAW0015A323
R822 1283367 RES-CH 10R F 1206 G TK100 BAW0015A323
R850 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R851 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R852 1254022 RES-CH 2K2 F 0603 G BAW SPE0028A323
R853 1304429 RES-CH 680R F 0603 BAW SPE0027A323
R854 1304781 RES-CH 10R F 0805 G BAW SPE0017A323
R855 1227831 RES-CH 10K F 0805 G BAW SPE0018A323
R856 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R857 1223437 RES-CH 470K F 0805 G BAW SPE0019A323
R858 1271199 RES-CH 56K F 0603 G BAW SPE0028A323
R859 1304895 RES-CH 100R F 0805 G BAW SPE0017A323
R860 1258478 RES-CH 15K F 0603 BAW SPE0028A323
R861 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R862 1304348 RES-CH 220R F 0603 BAW SPE0027A323
R863 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:16 of 18
R864 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R865 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R866 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R868 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R869 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R900 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R901 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R902 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R903 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R904 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R905 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R906 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R907 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R908 1304283 RES-CH 100R F 0603 BAW SPE0027A323
R910 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R911 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R912 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R913 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R915 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R916 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R920 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R921 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R922 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R923 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R924 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R925 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R926 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R927 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R930 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R931 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R932 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R933 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R934 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R935 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R940 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R941 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R942 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R943 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R944 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R945 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R946 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R947 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R950 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R952 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R953 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R954 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R955 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R957 1304410 RES-CH 560R F 0603 BAW SPE0027A323
R960 1304445 RES-CH 1K F 0603 BAW SPE0028A323
06.09.99
Spare Parts List Type:3201 Page:17 of 18
R962 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R963 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R965 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R966 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R967 1304445 RES-CH 1K F 0603 BAW SPE0028A323
R978 1227661 RES-CH 0R 0603 BAW SPE0025A323
R980 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R982 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R983 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R984 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R985 1297041 RES-CH 10K F 0603 G BAW SPE0028A323
R986 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R987 1305158 RES-CH 100K F 0603 BAW SPE0028A323
R988 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R989 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R992 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R993 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R994 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R995 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R996 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R997 1297058 RES-CH 22K F 0603 G BAW SPE0028A323
R998 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
R999 1254332 RES-CH 47K F 0603 G BAW SPE0028A323
S1831 1309714 ENCODER MAT EVQ B5D 60915B
S1832 1309757 ENCODER MAT EVQ B5D 70009B (9/18)
SP101 1031112 ARRESTER MMC DSP-201M-A21R
ST1804 1284703 CONTACT SPRING SET 13POL TO MOBIL FRONT
ST801 1252641 PRESSURE SPRING AMP 969600-1
T101 1028049 TRANSISTOR-CH BAW BC858C G SPE0002A302
T102 1225537 TRANSISTOR-CH BAW BFR93A SHIP-TO-STOCK G
T151 1018280 TRANSISTOR-CH BAW BC808-40 G SPE002
T152 1018280 TRANSISTOR-CH BAW BC808-40 G SPE002
T1801 0659614 TRANSISTOR-CH BAW BC848B G SPE0003A
T1802 0675318 TRANSISTOR-CH BAW BC818-16 SHIP-TO-STOCK
T1803 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T1805 1239066 TRANS.-CH BAW KRC104S/BCR148/DTC144
T1806 1182821 TRANSISTOR-CH BAW KRC102S/DTC114 NP
T204 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T205 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T206 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T252 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T301 1180576 TRANSISTOR BAW J109/110 SELEKT.G SP
T302 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T304 0659673 TRANSISTOR-CH BAW BC858B G SPE0005A302
T323 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T341 0659622 TRANSISTOR-CH BAW BC848C G SPE0004A302
T360 1329057 TRANSISTOR-CH SIE BCR562 PNP G
T361 1329057 TRANSISTOR-CH SIE BCR562 PNP G
T364 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
06.09.99
Spare Parts List Type:3201 Page:18 of 18
T501 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T502 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T601 1280260 TRANSISTOR BAW 2SD2394F/2SD1913S SPE0062
T602 1028049 TRANSISTOR-CH BAW BC858C G SPE0002A302
T604 0659614 TRANSISTOR-CH BAW BC848B G SPE0003A
T605 0659614 TRANSISTOR-CH BAW BC848B G SPE0003A
T606 0672521 TRANSISTOR-CH BAW BC856B G SPE0013A
T607 1258079 TRANSISTOR-CH BAW BC846B G SPE0035A302
T702 1253611 TRANSISTOR-CH BAW BCR158/DTA123JC SPE006
T801 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T805 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T806 1182821 TRANSISTOR-CH BAW KRC102S/DTC114 NP
T807 1248499 TRANSISTOR-CH BAW BCX52-16 G SPE0060A302
T808 1214594 TRANSISTOR-CH BAW KRA102S/BCR183 SP
T852 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T853 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T854 1028006 TRANSISTOR-CH BAW BC817-40 SHIP-TO-STOCK
T855 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T856 1172654 TRANSISTOR-CH BAW KRA103S/DTA124 PN
T857 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
T858 0659614 TRANSISTOR-CH BAW BC848B G SPE0003A
T859 1172646 TRANSISTOR-CH BAW KRC103S/DTC124 NP
06.09.99
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
