Image preview - the first page of the document
BELSON BS-13011


>> Download BELSON BS-13011 documenatation <<

Text preview - extract from the document
        EXPLODED VIEW
PANEL




             16
                                EXPLODED VIEW PARTS LIST
DISPLAY
Ref. No.                       Description         RS Part No.   Mfr's Part No.
   1       TV Top (S. DG0201) W/TV BRAND                         51-20524-81D
   2       TV Bottom (S. DG0201)                                 51-20525-81D
   3       TFT LCD PW70XS2 OR PW070XS4 (COG) PVI                 27-01850-02
   4       Display Board                                         11-10700-927
   5       Speaker 0.5W 80HM
