Image preview - the first page of the document
>> Download Brother HL-1030, 1240, 1250, 1270n Parts Manual documenatation <<
Text preview - extract from the document
R
Brother Laser Printer
PARTS REFERENCE LIST
MODEL: HL-1030/1240/1250/1270N
Read this list thoroughly before maintenance work.
Keep this list in a convenient place for quick and easy reference at all times.
September, 1999
PL-PRN001
NOTE FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q'ty
(3) Description
(4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.)
Note : No orders without Parts Code or Tool No. can be accepted.
< Example >
(1) (2) (3) (4)
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
Revision No.: marked on the main printed circuit board.
B48K056 - 201A
Design change indication
Specification No .
Pattern alteration No.
Circuit board No.
Revision No.: marked on the power supply printed circuit board.
Rev. A
Design change indication
(The first version has no sign.)
2. Design-changed parts :
If the parts are changed, any one of the following symbols is indicated in the REMARKS column.
#A : compatible between old and new
#B : replaceable from old to new
#D : incompatible
# : newly established
3. The original of this list was made based on the information available in September, 1999.
4. Parts are subject to change in design without prior notice.
CONTENTS
1. FRAME / DRIVE UNIT .......................................................................... 1
2. LASER UNIT......................................................................................... 1
3. PAPER FEEDER .................................................................................. 3
4. FIXING UNIT......................................................................................... 5
5. PAPER CASSETTE......................................................................... 7AB
6. COVERS............................................................................................... 9
7. MAIN PCB........................................................................................... 11
8. ENGINE PCB...................................................................................... 13
9. LOW-VOLTAGE POWER SUPPLY PCB............................................ 13
10. HIGH-VOLTAGE POWER SUPPLY PCB........................................... 15
11. AC CORDS ......................................................................................... 15
12. ACCESSORIES .................................................................................. 17
13. PACKING MATERIALS ...................................................................... 19
14. NETWORK BOARD ............................................................................ 19
15. ADJUSTING TOOL ............................................................................. 21
1. FRAME / DRIVE UNIT PR2002157
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 UL9311001 1 MAIN MOTOR ASSY
2 087320616 4 TAPTITE, CUP S M3X6
3 LJ4069001 1 SOLENOID ASSY
4 000300415 1 SCREW, BIND M3X4
5 LJ4432001 1 TAPE 32X12
6 UL8984001 1 LINK
7 LJ4745001 1 FAN MOTOR UNIT
8 UL9099001 1 TONER EMPTY PCB UNIT (LIGHT EMISSION) B512038
9 UK4405001 1 PANEL PCB ASSY B512048
10 087320616 3 TAPTITE, CUP S M3X6
11 LJ7403001 4 RUBBER FOOT
12 UL9104001 1 TONER EMPTY PCB UNIT (LIGHT RECEPTION) B512037
13 087320616 2 TAPTITE, CUP S M3X6
14 LJ8031001 1 LT RELAY PCB ASSY, HL-1250/1270N B512060
15 087320616 1 TAPTITE, CUP S M3X6
16 LE1169001 1 USB GROUND PLATE, HL-1270
17 UL8970001 1 SOLENOID RELEASE SPRING 30/99
18 LJ5591001 1 PLANET GEAR ASSY (SP)
18 LJ5838001 1 PLANET GEAR ASSY B (SP)
19 UL8985001 1 GEAR 59
20 LJ5705001 1 GEAR 21 PRESSURE PLATE
21 087320616 1 TAPTITE, CUP S M3X6
22 UL8972001 1 P/R CLUTCH LEVER
23 UL8971001 1 F/R CLUTCH LEVER
24 UL8982001 1 DEVELOP JOINT
25 UL8983001 1 JOINT SPRING
26 UL8959001 1 FRICTION SPRING DELETE
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-010
T/I NO. PR99165 / PR2000014 / PR2000073 / PR2000132 / PR2000152 / PR2001023 / PR2001049
PR2001061/ PR2001100 / PR2002013 / PR2002098 / PR2002139 / PR2002157
2. LASER UNIT
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ4157001 1 LASER UNIT (SP) (B512033)
2 087321615 3 TAPTITE, CUP S M3X16
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-020
-1-
1. FRAME / DRIVE UNIT PR2002098
16 19
14
13
7 15
12
11
10
24
11 25 8
6 11
9
2
1 2 4 10
18
22
20
23
21 5 17
26 11 3
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-010
T/I NO. PR99165 / PR2000014 / PR2000073 / PR2000152 / PR2001023 / PE2001049 / PR2001061
/ PR2001100 / PR2002013 / PR2002098
2. LASER UNIT
2
2
1
2
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-020
-2-
3. PAPER FEEDER
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 UL9060001 1 PAPER FEED ROLLER ASSY
2 UL9066001 1 PAPER PICK-UP ROLLER ASSY
3 UL9071001 1 TR ELECTRODE HELICAL SPRING A
3 LJ4499001 1 TR ELECTRODE HELICAL SPRING B
4 LJ4843001 1 OUTER CHUTE 1 (SP)
5 UL9070001 1 GEAR 21
6 UL9059001 1 JOINT 5
7 UL9062001 1 BEARING 5
8 UL9069001 1 CONDUCTOR BEARING 5
CAUTION:
1) The new version of the TR electrode helical spring, TR ELECTRODE HELICAL SPRING B
(LJ4499001) should be used for ALL HL-1030/1270N printers and the HL-1240/1250 printers
whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old version of the TR electrode helical spring, TR ELECTRODE HELICAL SPRING A
(UL9071001) should be used for HL-1240/1250 whose serial No. is before the number above
and the numbers in the range of J9J212235 - J9J217459 & J9J219423 - J9J219997.
3) The old and new versions of the TR electrode helical spring are incompatible with each
other.
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-040
T/I NO. PR2000051 / PR2000108 / PR2000130
-3-
3. PAPER FEEDER PR2000130
4
3
7
1
2
6
8
5
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-045/047
T/I NO. PR2000051 / PR2000108 / PR2000130
-4-
4. FIXING UNIT PR2002144
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ7759001 1 FIXING UNIT, 115V (SP) CHNG
1 LJ7760001 1 FIXING UNIT, 230V (SP) CHNG
1 LJ4718001 1 FIXING UNIT, 230V LEG (SP)
1-1 UL8902001 1 THERMISTOR ASSY
1-2 087311215 1 TAPTITE, CUP B M3X12
1-3 LJ4169001 1 HEAT ROLLER 25 (SP)
1-3 LJ4719001 1 HEAT ROLLER 25 LEG (SP)
1-4 UL8908001 2 HR BEARING 25
1-5 LJ4160001 1 HALOGEN LAMP, 115V (SP)
1-5 LJ4163001 1 HALOGEN LAMP, 230V (SP)
1-6 UL8929001 8 EJECT PINCH ROLLER
1-7 LJ4431001 8 PINCH SPRING
1-8 LJ4407001 2 CLEANER ROLLER ASSY
1-9 LJ4409001 2 CLEANER SPRING
1-10 087312015 2 TAPTITE, CUP B M3X20
1-11 Z07200001 1 TAPTITE, PAN B M3X10
1-12 LJ4845001 4 PICK OFF FINGER (SP)
1-13 LJ4853001 1 PRESSURE ROLLER 20 (SP)
1-13 LJ4852001 1 PRESSURE ROLLER 20 LE (SP)
1-14 UL8920001 1 PAPER EJECT ACTUATOR
1-15 UL8921001 1 EJECT ACTUATOR SPRING
1-16 UL8914001 2 IDLE GEAR 13
1-17 LJ5871001 1 IDLE GEAR HOLDER
1-18 UL8923001 1 FU DRIVE GEAR 20/38 ADD
1-19 LJ7256001 1 EJECT ROLLER SHAFT L ADD
1-20 LJ7257001 1 EJECT ROLLER ASSY R ADD
1-20-1 LJ7258001 1 EJECT ROLLER SHAFT R ADD
1-21 LJ7259001 1 EJECT ROLLER BUSHING L ADD
1-22 LJ7260001 1 EJECT ROLLER BUSHING R ADD
1-23 LJ7261001 1 FU FRAME LOWER 2 ADD
1-24 LJ7262001 1 EJECT ROLLER JAM REMOVE TOOL ADD
2 087320815 1 TAPTITE, CUP S M3X8
3 LJ4740001 2 SHOULDER SCREW
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-050/051
T/I NO. PR99179, PR99186, PR2000029, PR2000057, PR2000157,PR2001118 / PR2002091 /
PR2002144
-5-
4. FIXING UNIT PR2002091
1-9
1-6
1-10
1-11 1-7
1-8 1-6
1-6
3
1-7
1-7
1-10
1-6 1-12 3
1-12
1-7
1-12 1-14
1-12
1-15
2 1-18
1-17
1-4
1-1
1-2
1-9
1-16
1-8
1
1-13
1-5
1-3
1-4
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-045/047
T/I NO. PR2000029 / PR2000057 / PR2001118 / PR2002091
-6-
5-1. PAPER CASSETTE, LGL PR2002009
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LE1162001 1 PAPER TRAY ASSY, LGL (SP)
1-1 LJ4537001 1 PRESSURE PLATE ASSY, LGL
1-2 UL9077001 2 PRESSURE PLATE SPRING
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 UL9090001 1 SEPARATION PAD SPRING
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4534001 1 PRESSURE ROLLER HOLDER, LGL
1-16 LJ4892001 1 PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-23 LJ4865001 1 MYLAR LABEL 1240 TRAY
1-24 LJ4332001 1 TRAY FEED GUIDE ASSY ADD
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-045
T/I NO. PR2000066 / PR2000127 / PR2002009
5-2. PAPER CASSETTE, A4 PR2002009
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ4181001 1 PAPER TRAY ASSY, A4 (SP)
1-1 UL9074001 1 PRESSURE PLATE ASSY, A4
1-2 UL9077001 2 PRESSURE PLATE SPRING
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 UL9090001 1 SEPARATION PAD SPRING
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4196001 1 PRESSURE ROLLER HOLDER, A4
1-16 LJ4892001 1 PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-24 LJ4332001 1 TRAY FEED GUIDE ASSY ADD
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-047
T/I NO. PR2000127 / PR2002009
- 7A -
5-3. PAPER CASSETTE, PB PR2002009
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ4639001 1 PAPER TRAY ASSY 3 (SP)
1-1 UL9074001 1 PRESSURE PLATE ASSY, A4
1-2 LJ4621001 2 PRESSURE PLATE SPRING 340
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 LJ4705001 1 SEPARATION PAD SPRING 300
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4196001 1 PRESSURE ROLLER HOLDER
1-16 LJ4893001 1 PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-24 LJ4332001 1 TRAY FEED GUIDE ASSY ADD
MODEL HL-1240 84U-Z01-049
T/I NO. PR99179 / PR2000127 / PR2002009
5-4. PAPER CASSETTE, LEG PR2002009
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ4684001 1 PAPER TRAY ASSY, LEG (SP)
1-1 UL9074001 1 PRESSURE PLATE ASSY, A4
1-2 UL9077001 2 PRESSURE PLATE SPRING
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 LJ4622001 1 SEPARATION PAD SPRING 250
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4196001 1 PRESSURE ROLLER HOLDER, A4
1-16 LJ4892001 1 PRESSURE ROLLER COLLAR 2 ASSY CHNG
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-24 LJ4332001 1 TRAY FEED GUIDE ASSY ADD
MODEL HL-1240/1250/1270N 84U-Z06/Z07/08-043
T/I NO. PR99179 / PR2000127 /PR20002009
- 7B -
6. COVERS PR2002052
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ5753001 1 MAIN COVER ASSY
1-1 LJ7292001 1 HEAT PROTECTION FILM ADD
2 UL9122001 4 PINCH ROLLER ASSY
3 UL9125001 4 PINCH ROLLER SPRING
4 LJ5763001 1 REAR COVER
5 UL9127001 1 REAR COVER SPRING L
6 UL9128001 1 REAR COVER SPRING R
7 UL9129001 1 FRONT COVER ASSY
7 LJ4526001 1 FRONT COVER ASSY LE
8 UL9140001 1 TRAY EXTENSION FLAP
9 UL9088001 1 TOP COVER
10 UL9142001 1 SECOND EJECT ROLLER ASSY
11 087321015 2 TAPTITE, CUP S M3X10
12 085320816 6 TAPTITE, BIND S M3X8
13 LJ8166001 1 MODEL PLATE 1030
13 UL9143001 1 MODEL PLATE 1240
13 UL9315001 1 MODEL PLATE 1250
13 LJ4794001 1 MODEL PLATE 1270
13 LJ4135001 1 MODEL PLATE 1270N
13 LJ4452001 1 MODEL PLATE J624
13 LJ4460001 1 MODEL PLATE 2312P
13 LJ4496001 1 MODEL PLATE 2412P
13 LJ4724001 1 MODEL PLATE 8212N
13 LJ4772001 1 MODEL PLATE 1500 WIP
13 LJ4846001 1 MODEL PLATE 1700 WIP
13 LJ4848001 1 MODEL PLATE 1900 WIP
14 UL6740001 1 LASER CAUTION LABEL, EUR
14 UL7931001 1 LASER LABEL LEGEND
15 LJ8167001 1 MYLAR LABEL 1030, CAN
15 LJ8172001 1 MYLAR LABEL 1030, EUR
15 UL9146001 1 MYLAR LABEL 1240, US
15 UL9249001 1 MYLAR LABEL 1240, CAN
15 UL9250001 1 MYLAR LABEL 1240, EUR
15 UL9316001 1 MYLAR LABEL 1250, US
15 LJ4078001 1 MYLAR LABEL 1250, CAN
15 UL9317001 1 MYLAR LABEL 1250, EUR
15 LJ4136001 1 MYLAR LABEL 1270N, US
15 LJ4232001 1 MYLAR LABEL 1270N, CAN
15 LJ4137001 1 MYLAR LABEL 1270N, EUR
16 LJ4905001 1 FAN GUARD
17 UL9145001 1 PROCESS UNIT OP LABEL
18 LJ4855001 1 TRAY REAR COVER ASSY
19 LJ5834001 1 TRAY REAR COVER LGL ASSY
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-060
T/I NO. PR99165 / PR99179 / PR99204 / PR2000005 / PR2000055 / PR2000066 / PR2000075 /
PR2000108 / PR2000129 / PR2002017/ PR2002052
-9-
6. COVERS
13
9
10 8 11
11
18
6
4 2
2
3
12 1
5
3
12
12
17
16
12
14
15
7
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-060
T/I NO. PR2000066 / PR2000075 / PR2000108 / PR2000129
- 10 -
7. MAIN PCB PR2002121
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ8239001 1 MAIN PCB ASSY, HL-1030 US (SP) B512040-450F NAME CHNG
1 LJ8309001 1 MAIN PCB ASSY, HL-1030 EU (SP) B512040-477F
1 LJ8066001 1 MAIN PCB ASSY, HL-1240 US (SP) B512040-410H NAME CHNG
1 LJ8303001 1 MAIN PCB ASSY, HL-1240 EU (SP) B512040-447H
1 LJ8067001 1 MAIN PCB ASSY, HL-1240 HEB (SP) B512040-411B
1 LJ8251001 1 MAIN PCB ASSY, HL-1240 PB (SP) B512040-445H
1 LJ8160001 1 MAIN PCB ASSY, 2312P LEG (SP) B512040-413F
1 LJ8318001 1 MAIN PCB ASSY, HL-1250-2 US (SP) B512115-160C NAME CHNG
1 LJ8305001 1 MAIN PCB ASSY, HL-1250-2 EU (SP) B512115-177C
1 LJ8306001 1 MAIN PCB ASSY, HL-1250-2 DEN (SP) B512115-178C
1 LJ8326001 1 MAIN PCB ASSY, HL-1250-2 LEG (SP) B512115-163D
1 LJ8328001 1 MAIN PCB ASSY, HL-1270N-2 US (SP) B512115-180B NAME CHNG
1 LJ8307001 1 MAIN PCB ASSY, HL-1270N-2 EU (SP) B512115-197B
1 LJ8308001 1 MAIN PCB ASSY, HL-1270N-2 DEN (SP) B512115-198B
1 LJ8329001 1 MAIN PCB ASSY, HL-1270N-2 LEG (SP) B512115-163A
1-1 LJ8295001 1 MASK ROM, HL-1030/1240
1-1 LJ8047001 1 MASK ROM, HL-1240 HEB
1-1 LJ8797001 1 MASK ROM, HL-1250
1-1 LJ8310001 1 MASK ROM, HL-1270N
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-101/103
T/I NO. PR99165 / PR99179 / PR99194 / PR99198 / PR99203 / PR99207/ PR2000015 / PR2000074 /
PR2000109 / PR2000124 / PR2000134 / PR2001060 / PR2001067 / PR2001127 /PR2002121
- 11 -
7.MAIN PCB
1
HL-1030
1-1
1
HL-1240
1-1
1
1-1
HL-1250
1
HL-1270/1270N 1-1
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-101/103
T/I NO. PR99165 / PR2000124
- 12 -
8. ENGINE PCB PR2002097
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ4178001 1 ENGINE PCB ASSY A, 1240 (SP) B512059-101D VER.CHNG.
1 LJ8157001 1 ENGINE PCB ASSY B, 1030/1240 (SP) B512075-121D
1 LJ4222001 1 ENGINE PCB ASSY A, 1250 (SP) B512059-102D VER.CHNG.
1 LJ8158001 1 ENGINE PCB ASSY B, 1250/1270 (SP) B512059-122C VER.CHNG.
CAUTION:
1) The new versions of the engine PCB, ENGINE PCB ASSY B, 1240/1030 (LJ8157001) &
ENGINE PCB ASSY B, 1250/1270 (LJ8158001) should be used for ALL HL-1030/1270N
printers and the HL-1240/1250 printers whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old versions of the engine PCB, ENGINE PCB ASSY A, 1240 (LJ4178001) & ENGINE
PCB ASSY A, 1250 (LJ4222001) should be used for HL-1240/1250 whose serial No. is before
the number above and the numbers in the range of J9J212235 - J9J217459 & J9J219423 -
J9J219997.
3) The old and new versions of the engine PCB are incompatible with each other.
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-151
T/I NO. PR99165 / PR99197 / PR99202 / PR99213 / PR2000016 / PR2000121
9. LOW-VOLTAGE POWER SUPPLY PCB
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LG4015001 1 PS PCB ASSY ZLE-B,115V
1 LG4016001 1 PS PCB ASSY ZLE-B,230V
2 UK4426001 1 INLET UNIT, 115V
2 UK4430001 1 INLET UNIT, 230V
3 085320816 1 TAPTITE, BIND S M3X8
4 087320616 1 TAPTITE, CUP S M3X6
5 LJ4756001 1 AC INLET FILM
6 LJ8330001 1 PROTECTION TUBE
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-200/201
T/I NO. PR99188 / PR99189 / PR2000113 / PR2001064 / PR2002097
- 13 -
8. ENGINE PCB
1
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-151
9. LOW-VOLTAGE POWER SUPPLY PCB
6
1
2
4
5
3
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-200/201
T/I NO. PR99188 / PR2000113
- 14 -
10. HIGH-VOLTAGE POWER SUPPLY PCB PR2002011
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ4176001 1 HIGH-VOLTAGE PS ASSY A (SP)
1 LJ8156001 1 HIGH-VOLTAGE PS ASSY B (SP)
2 085411215 4 SCREW BIND B TITE M4X12
CAUTION:
1) The new version of the high-voltage power supply PCB, HIGH-VOLTAGE PS ASSY B
(LJ8156001) should be used for ALL HL-1030/1270N printers and the HL-1240/1250 printers
whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old version of the high-voltage power supply PCB, HIGH-VOLTAGE PS ASSY A
(LJ4176001) should be used for HL-1240/1250 whose serial No. is before the number above
and the numbers in the range of J9J212235 - J9J217459 & J9J219423 - J9J219997.
3) The old and new versions of the high-voltage power supply PCB are incompatible each
other.
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-220
T/I NO. PR99153, PR99165
11. AC CORDS
REF.NO. CODE Q'TY DESCRIPTION REMARK
1A LJ8875001 1 AC CORD, UL/CSA CODE CHNG
1B LJ8879001 1 AC CORD ASSY, SAA CODE CHNG
1C LJ8877001 1 AC CORD ASSY, SEV CODE CHNG
1D UK4099001 1 AC CORD, CHLI
1E UH1054001 1 AC CORD, BS
1F U34322001 1 AC CORD #6, ISRAEL
1G U34320001 1 AC CORD #4, BS
1H UK4094001 1 AC CORD, DEMKO
1I LJ8876001 1 AC CORD ASSY, VDE CODE CHNG
1J UK3610001 1 AC CORD ASSY, CHN96
1K LJ8288001 1 AC CORD ASSY, IND
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-230
T/I NO. PR99179, PR2000055,PR2002011
- 15 -
10. HIGH VOLTAGE POWER SUPPLY PCB
1
2
2
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-220
11. AC CORD
1A 1G
1B 1H
1C 1I
1D 1J
1E 1K
1F
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-23 0
T/I NO. PR99179 / PR2000055
- 16 -
12. ACCESSORIES PR2000055
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LJ8161001 1 PR DRIVER DISK ASSY 1, HL-1030
1 LJ8162001 1 PR DRIVER DISK ASSY 2, HL-1030
1 UK4387001 1 PR DRIVER DISK ASSY 1, HL-1240
1 UK4392001 1 PR DRIVER DISK ASSY 2, HL-1240
1 UK4390001 1 PR DRIVER DISK ASSY 1, HL-1250
1 UK4394001 1 PR DRIVER DISK ASSY 2, HL-1250
1 LJ8035001 1 PR DRIVER DISK ASSY 1, HL-1270N
1 LJ8036001 1 PR DRIVER DISK ASSY 2, HL-1270N
1 LJ8090001 1 PR DRIVER DISK ASSY LEG 2312P
1 LJ8244001 1 PR DRIVER DISK ASSY LEG 2412P
1 LJ4728001 1 PR DRIVER DISK ASSY LEG 8212N
1 LJ8285001 1 PR DRIVER DISK ASSY, WIP HL-1240 ADD
1 LJ8289001 1 PR DRIVER DISK ASSY, WIP HL-1250 ADD
1 LJ8291001 1 PR DRIVER DISK ASSY, WIP HL-1270N ADD
2 LJ8141001 1 CD ASSY
2 LJ8040001 1 CD ASSY, PB
2 LJ4727001 1 CD ASSY, LEG
2 LJ8261001 1 CD ASSY, KOR
2 LJ8287001 1 CD ASSY, WIP ADD
3 LJ4746001 1 SETUP GUIDE, US
3 LJ4748001 1 SETUP GUIDE, FRA
3 LJ4747001 1 SETUP GUIDE, GER
3 LJ4750001 1 SETUP GUIDE, NL
3 LJ4749001 1 SETUP GUIDE, NOR
3 LJ4754001 1 SETUP GUIDE, SWE
3 LJ4751001 1 SETUP GUIDE, DEN
3 LJ4752001 1 SETUP GUIDE, SPA
3 LJ4753001 1 SETUP GUIDE, ITA
3 LJ4650001 1 SETUP GUIDE, PB
4 LJ4585001 1 NETWORK SETUP GUIDE, US (HL-1270N)
4 LJ4586001 1 NETWORK SETUP GUIDE, FRA (HL-1270N)
4 LJ4587001 1 NETWORK SETUP GUIDE, GER (HL-1270N)
4 LJ4588001 1 NETWORK SETUP GUIDE, NL (HL-1270N)
4 LJ4590001 1 NETWORK SETUP GUIDE, SPA (HL-1270N)
4 LJ4589001 1 NETWORK SETUP GUIDE, ITA (HL-1270N)
5 LJ4802001 1 WIN2000 QUICK SETUP GUIDE, US
5 LJ4803001 1 WIN2000 QUICK SETUP GUIDE, FRA
5 LJ4804001 1 WIN2000 QUICK SETUP GUIDE, GER
5 LJ4805001 1 WIN2000 QUICK SETUP GUIDE, NL
5 LJ4806001 1 WIN2000 QUICK SETUP GUIDE, NOR
5 LJ4807001 1 WIN2000 QUICK SETUP GUIDE, SWE
5 LJ4808001 1 WIN2000 QUICK SETUP GUIDE, ITA
5 LJ4809001 1 WIN2000 QUICK SETUP GUIDE, DEN
5 LJ4810001 1 WIN2000 QUICK SETUP GUIDE, SPA
6 LJ4842001 1 QUICK SETUP GUIDE, WIP ADD
7 LJ4829001 1 USER'S MANUAL 8212N (LEG HL1270N)
8 UE2014001 1 BAG, 215X350H
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-920
T/I NO. PR99165, PR99179, PR99206, PR99211, PR99212, PR2000022, PR2000024, PR2000055
- 17 -
12. ACCESSORIES
1
7
2
3
4
5
6
8
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-920
T/I NO. PR99165 / PR2000022 / PR2000024 / PR2000055
- 18 -
13. PACKING MATERIALS
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 LL0125001 1 CARTON, HL-1030 EU
1 LL0124001 1 CARTON, HL-1030 CAN
1 UE0818001 1 CARTON, HL-1240 US
1 UE0822001 1 CARTON, HL-1240 CAN
1 UE0820001 1 CARTON, HL-1240 EU
1 LL0014001 1 CARTON, HL-1250 US
1 LL0015001 1 CARTON, HL-1250 CAN
1 LL0016001 1 CARTON, HL-1250 EU
1 LL0194001 1 CARTON, HL-1270 A4
1 LJ4186001 1 CARTON, HL-1270N US
1 LJ4538001 1 CARTON, HL-1270N CAN
1 LJ4188001 1 CARTON, HL-1270N EU
1 LL0046001 1 CARTON, OEM
1 LL0045001 1 CARTON, LEG 2312P
1 LL0047001 1 CARTON, LEG 2412P
1 LL0151001 1 CARTON, LEG 8212N
2 UE2280001 1 STYROFORM PAD ASSY, LGL
2 LJ4038001 1 STYROFORM PAD ASSY, A4
3 UE2283001 1 ACCESSORY CARTON
4 UE2126001 1 BAG, 700X800H
5 LJ5497001 1 WIN ME CARTON LABEL
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-930
T/I NO. PR99165, PR99179, PR99206, PR99211, PR2000005, PR2000153
14. NETWORK BOARD
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ8083001 1 BRNET PCB UNIT (SP) B512058-100A
1-1 087320616 2 TAPTITE, CUP S M3X6
MODEL HL-1270N 84U-Z03-150
T/I NO. PR99165
- 19 -
13. PACKING MATERIALS
2
3
4
2
1 5
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03-930
T/I NO.PR2000153
14. NETWORK BOARD
1
1-1
1-1
MODEL HL-1270N 84U-Z03-150
T/I NO. PR99165
- 20 -
15. ADJUSTING TOOL
PRT-402 PRT-001f
TOOL NO. TOOL NAME REMARK
PRT-402 TORX SCREW DRIVER
PRT-001f MOLYKOTE PG-662 ADD
MODEL HL-1030/1240/1250/1270N 84U-Z04/Z01/Z02/Z03
T/I NO. PR99165
- 21 -
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
