Image preview - the first page of the document
>> Download DADF-B1pc documenatation <<
Text preview - extract from the document
PARTS
CATALOG
REVISION 0
AB SIZE F25 - 1601 ZSB00001 -
A/INCH SIZE F25 - 1611 ZSC00001 -
A SIZE F25 - 1621 ZSD00001 -
AB/INCH SIZE F25 - 1631 ZSE00001 -
MAR. 1999 FY8-31E5-000
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] I-1
PREFACE
This Parts Catalog contains listings of parts used in the Canon DADF-B1. Diagrams
are provided with the listings to aid the service technician in identifying clearly, the
item to be orderd.
Whenever ordering parts, consult this Parts Catalog for all of the information per-
taining to each item. Be sure to include, in the Parts Request, the full item
description, the item part number, and the quantity.
Canon Inc.
Office Imaging Products Technical Support Dept.3
Office Imaging Products Technical Support Div.
5-1, Hakusan 7-chome,
Toride-shi, Ibaraki 302-8501, Japan
COPYRIGHT C 1999 CANON INC.
Use of this manual should be
strictly supervised to avoid dis-
closure of confidential infor-
mation.
I-2 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
CONTENTS
-DADF-B1-
PA. ASSEMBLY LOCATION DIAGRAM
P01. MOUNTING HARDWARE
P10. MAIN COVER ASSEMBLY
P11. DOCUMENT TRAY ASSEMBLY
P20. FEEDER DRIVE ASSEMBLY
P21. SEPARATION DRIVE ASSEMBLY
P30. DOCUMENT PICK-UP ASSEMBLY
P31. DOCUMENT PICK-UP COVER ASSEMBLY
P32. SEPARATION LOWER GUIDE ASSEMBLY
P33. SEPARATION UPPER GUIDE ASSEMBLY
P35. FEEDER ASSEMBLY
P40. REVERSE DELIVERY ASSEMBLY
P41. REVERSE COVER ASSEMBLY
P42. DOCUMENT DELIVERY ASSEMBLY
P90. ADF CONTROLLER PCB ASSEMBLY
PB. LIST OF CONNECTORS
C. LIST OF STANDARD FASTENERS
PD. NUMERICAL INDEX
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] I-3
ASSEMBLY LOCATION DIAGRAM
FIGURE PA
REVERSE COVER ASSEMBLY
P41
DOCUMENT DELIVERY ASSEMBLY
P42
ADF CONTROLLER PCB ASSEMBLY
P90
REVERSE DELIVERY ASSEMBLY
P40
DOCUMENT PICK-UP ASSEMBLY
P30
FEEDER ASSEMBLY
P35
SEPARATION DRIVE ASSEMBLY
P21
SEPARATION UPPER GUIDE ASSEMBLY
FEEDER DRIVE ASSEMBLY P33
P20
SEPARATION LOWER GUIDE ASSEMBLY
DOCUMENT PICK-UP COVER ASSEMBLY
P32
P31
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] PA-1
MOUNTING HARDWARE
FIGURE P01
3
6 7
4
2
1
5A
1A
5
P01-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P01 - NPN RF MOUNTING HARDWARE
1 FF5-9144-000 1 PLATE, JUMP, RIGHT
1A FB5-0423-000 1 RETAINER, GLASS, RIGHT
2 FF5-9171-000 1 PANEL, UPPER, REAR
3 FS5-9589-000 2 SCREW,M4
4 FS5-9590-000 1 SCREW,STEPPED,M4
5 FF5-9152-000 1 PLATE, JUMP, LEFT AB SIZE
FF5-9486-000 1 PLATE, JUMP, LEFT A/INCH SIZE
FF5-9487-000 1 PLATE, JUMP, LEFT A SIZE
FF5-9488-000 1 PLATE, JUMP, LEFT AB/INCH SIZE
5A FB5-0381-000 1 PLATE, INDEX, LEFT AB SIZE
FB5-2204-000 1 PLATE, INDEX, LEFT A/INCH SIZE
FB5-2205-000 1 PLATE, INDEX, LEFT A SIZE
FB5-2206-000 1 PLATE, INDEX, LEFT AB/INCH SIZE
6 FS5-9591-000 1 SCREW,STEPPED,M4
7 XA9-0633-000 2 SCREW,W/WASHER,M4X8
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P01-2
MAIN COVER ASSEMBLY
FIGURE P10
12 SEE FIGURE P40
(J501) 19 17
14
21
505
509
(J1)
510
(J2)
501
508
9
SEE FIGURE P30
4 509
7
16 15
8 (SR6) 504
(J109)
13 6
504
501
504
504
504 22
502
507
18 1
5 20 2
18 10
503
501 11
SEE FIGURE P90
503
SEE FIGURE P35 3
P10-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P10 - NPN MAIN COVER ASSEMBLY
1 FA3-4725-000 1 CATCH, MAGNET
2 FB3-5699-000 1 PLATE, GROUNDING
3 FB4-6890-000 4 CLIP
4 FB5-0420-000 1 COVER, FRONT
5 FB5-0426-000 1 HINGE, LEFT
6 FB5-0427-000 1 HINGE, RIGHT
7 FB5-0524-000 1 COVER, PCB
8 FB5-0525-000 1 COVER, LOWER, LEFT
9 FB5-0526-000 1 COVER, LOWER, RIGHT
10 FS7-2012-000 1 SPRING, COMPRESSION
11 FS7-2237-000 1 SPRING, COMPRESSION
12 FS6-8957-000 1 LABEL, CAUTION
13 FB5-0512-000 1 ARM, SENSOR, OPEN/CLOSE
14 FB4-6952-000 1 COVER, LED
15 FS7-2236-000 1 SPRING, COMPRESSION
16 WG8-5362-000 1 IC, TLP1241, PHOTO-INTERRUPTER SR6 J109
17 FB5-2207-000 1 SHEET
18 FS5-9587-000 2 SHAFT, BELT MOUNT, 2
19 FG3-0487-000 1 INTERFACE CABLE J1,2,501
20 FS5-9588-000 2 SHAFT, BELT MOUNT, 1
21 FB5-0461-000 1 GROMMET
22 FB5-2203-000 1 PLATE, ADJUST
501 XB1-2400-609 AR SCREW,MACH.,TRUSS HEAD,M4X6
502 XB1-2300-609 1 SCREW,MACH.,TRUSS HEAD,M3X6
503 XB6-7300-606 5 SCREW,TP,M3X6
504 XB1-2400-806 7 SCREW,MACH.,TRUSS HEAD,M4X8
505 XD1-4200-302 1 WASHER,TOOTHED LOCK
506 XB1-2300-606 1 SCREW,MACH.,TRUSS HEAD,M3X6
507 XB4-7400-809 AR SCREW,TAPPING,TRUSS HEAD,M4X8
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P10-2
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P10 - 508 XB4-7400-806 AR SCREW,TAPPING,TRUSS HEAD,M4X8
509 XB4-7300-806 2 SCREW,TAPPING,TRUSS HEAD,M3X8
510 XB4-7300-809 1 SCREW,TAPPING,TRUSS HEAD,M3X8
P10-3 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
DOCUMENT TRAY ASSEMBLY
FIGURE P11
14
10
10A
4
503
2
7
12A
12
9
Z
TO FIGURE P30
5
5
6 501 501
13
8
1
501
502 501
(J1801) 501
11 (J801) 502 3
(J401) 11A
NOTE : This assembly does not include the part shown with key No. 503.
P11-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P11 - FG6-3961-000 1 DOCUMENT TRAY ASSEMBLY AB SIZE
FG6-3958-000 1 DOCUMENT TRAY ASSEMBLY A/INCH SIZE
FG6-3959-000 1 DOCUMENT TRAY ASSEMBLY A SIZE
FG6-3960-000 1 DOCUMENT TRAY ASSEMBLY AB/INCH SIZE
1 FG6-4562-000 1 ROTARY VR ASSEMBLY
2 FB5-0504-000 1 TRAY, SUPPORT
3 FB5-0505-000 1 COVER, TRAY, LOWER
4 FB5-0506-000 1 GUIDE, SIDE, FRONT
5 FB5-0508-000 2 RACK
6 FB5-0510-000 1 PLATE, GROUNDING
7 FB5-0511-000 1 BLOCK, LIMIT
8 FG6-4563-000 1 PRE-LAST SENSOR PCB ASSEMBLY
9 FS6-0509-000 1 GEAR, 26T
10 FF5-9485-000 1 GUIDE, SIDE, RIGHT AB,A SIZE
FF5-9492-000 1 GUIDE, SIDE, RIGHT A/INCH,AB/INCH SIZE
10 A FS6-8851-000 1 LABEL, PAPER LOAD AB,A SIZE
FS6-8956-000 1 LABEL, PAPER LOAD A/INCH,AB/INCH SIZE
11 FG3-0491-000 1 TRAY CABLE J401,801,1801
11 A VS1-6198-003 1 CONNECTOR, SNAP TIGHT J801
12 FF5-9484-000 1 TRAY, DOCUMENT AB SIZE
FF5-9489-000 1 TRAY, DOCUMENT A/INCH SIZE
FF5-9490-000 1 TRAY, DOCUMENT A SIZE
FF5-9491-000 1 TRAY, DOCUMENT AB/INCH SIZE
12 A FS6-8850-000 1 LABEL, DOCUMENT SIZE AB SIZE
FS6-8852-000 1 LABEL, DOCUMENT SIZE A/INCH SIZE
FS6-8853-000 1 LABEL, DOCUMENT SIZE A SIZE
FS6-8854-000 1 LABEL, DOCUMENT SIZE AB/INCH SIZE
13 FB5-0418-000 1 WEIGHT, DELIVERY
14 FS6-8958-000 1 LABEL, DOCUMENT SET
501 XB4-7300-809 9 SCREW,TAPPING,TRUSS HEAD,M3X8
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P11-2
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P11 - 502 XB4-7300-609 2 SCREW,TAPPING,TRUSS HEAD,M3X6
503 XB6-7400-806 2 SCREW,TP,M4X8 SEE NOTE
P11-3 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
FEEDER DRIVE ASSEMBLY
FIGURE P20
(M2) (J106)
9
4
8A
(BK1) (J1101)
3
(J105) 8
(J101)
6
(SR1)
501
7
5
1
NOTE : This assembly is included in the assembly shown in Figure P30.
2
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P20 - FG6-3962-000 1 FEEDER DRIVE ASSEMBLY SEE NOTE
1 FB5-0491-000 1 PLATE, CLOCK
2 FS5-3760-000 1 PULLEY, 16T/63T/GEAR, 24T
3 XA9-0892-000 1 SCREW,MACH.,TRUSS HEAD,M4X6
4 FH6-1672-000 1 MOTOR, DC M2 J105
5 XF2-1106-080 1 BELT, TIMING
6 XF2-1107-660 1 BELT, TIMING
7 WG8-5426-000 1 IC,GP1AQ73A,PHOTO-INTERRUPTER SR1 J101
8 FG3-0545-000 1 FEEDER CLOCK CABLE J101,1101
8A VS1-6198-003 1 CONNECTOR, SNAP TIGHT J1101
9 FG6-3964-000 1 BRAKE UNIT BK1 J106
501 XB1-2400-609 4 SCREW,MACH.,TRUSS HEAD,M4X6
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P20-1
SEPARATION DRIVE ASSEMBLY
FIGURE P21
501
11
502
501 501
12
7 501
(J104) 504 20
22
501
5
(M1)
21
5
501
504
16 18
505
503
17
15 6
1
2
4 3
9
10 13
8 501
501
19
14
NOTE : This assembly is included in the assembly shown in Figure P30.
P21-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P21 - FG6-3963-000 1 SEPARATION DRIVE ASSEMBLY SEE NOTE
1 FA3-8727-000 1 RING, RETAINING
2 FB5-0483-000 1 JOINT, ROLLER, PICK-UP
3 FB5-0484-000 1 COUPLING, SEPARATION ROLLER
4 FF5-9165-000 1 PLATE, SWING
5 FS1-1346-000 2 BUSHING
6 FS5-9586-000 1 SCREW,STEPPED,M4
7 FS6-0617-000 1 GEAR, PICK-UP, 44T
8 FS7-0473-000 1 GEAR, 16T/64T/16T
9 FS7-0474-000 1 GEAR, 38T
10 FS7-0475-000 1 GEAR, 50T
11 FS7-0478-000 1 GEAR, 14T
12 FS7-0479-000 1 GEAR, 21T
13 FB5-2225-000 1 CLIP, COUPLING
14 XF2-1206-032 1 BELT, TIMING
15 FS1-1213-000 1 BUSHING
16 FF5-9153-000 1 PLATE, SEPARATION MOTOR
17 FB5-0495-000 1 LINK, CAM, A
18 FB5-0496-000 1 LINK, CAM, B
19 FS5-3757-000 1 GEAR, 14T/PULLEY, 44T
20 FS7-0481-000 1 GEAR, 44T
21 FH6-1671-000 1 MOTOR, DC M1 J104
22 FB5-2208-000 1 SPRING, LEAF
501 XD2-1100-502 8 RING,E
502 XD3-2200-102 1 PIN,DOWEL
503 XB1-2260-409 2 SCREW,MACH.,TRUSS HEAD,M2.6X4
504 XB1-2300-609 3 SCREW,MACH.,TRUSS HEAD,M3X6
505 XD2-1100-402 1 RING,E
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P21-2
DOCUMENT PICK-UP ASSEMBLY (1/2)
FIGURE P30
17A
(J5)
(J1801) (J6)
33
(J106)
(J1101) (J701)
SEE FIGURE P21
(J104) (J1102)
(J105)
(J201)
34
17
33
504
12
501
504
21
505 31
9
15
1
31
8
509
18
14
2
36
19
14 21
7 503
15 31
9
505
3
507
NOTE 1 : This assembly includes the assemblies shown in Figure P20,P21,P31,P32 and P33.
NOTE 2 : This assembly does not include the parts shown with key No. 37 and 510.
P30-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
DOCUMENT PICK-UP ASSEMBLY (2/2)
FIGURE P30
33
33
SEE FIGURE P33
35 13
20 4 33
6 33
10
16
506
25
Y 502
FROM FIGURE P35 28
30
27
11 31 22 501
29
34 23
SEE FIGURE P20 FROM FIGURE P11 24 26
Z
31 34
8 5 34
5
37
510
31
SEE FIGURE P32
SEE FIGURE P31
32
508
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P30-2
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P30 - FG6-3950-000 1 DOCUMENT PICK-UP ASSEMBLY SEE NOTE 1
1 FB5-0430-000 1 ROLLER, REGISTRATION, 1
2 FB5-0431-000 1 ROLLER, REGISTRATION, 2
3 FB5-0437-000 1 GUIDE, DOCUMENT PICK-UP, LOWER
4 FB5-0440-000 1 COVER, SEPARATION ROLLER
5 FB5-0475-000 2 SUPPORT, TRAY
6 FF5-9156-000 1 ROLLER, TENSION
7 FF5-9158-000 1 GUIDE, DOCUMENT, CENTER
8 FF5-9159-000 2 PLATE, COVER MOUNT
9 FS5-1902-000 2 BUSHING
10 FS5-3758-000 1 PULLEY, 14T/25T
11 FS7-0467-000 1 GEAR, 20T
12 FS7-0468-000 1 GEAR, 34T
13 FS7-2231-000 1 SPRING, TENSION
14 FS7-2232-000 2 SPRING, TENSION
15 FS7-2233-000 2 SPRING, TENSION
16 XF2-1303-495 1 BELT, TIMING
17 FG3-0488-000 1 PICK-UP CABLE J5,6,104-106,201,701
J1101,1102,1801
17 A VS1-5057-008 1 CONNECTOR, SNAP TIGHT J1801
18 FB5-0500-000 1 PLATE, GROUNDING
19 FF5-9157-000 1 GUIDE, INTERNAL, PICK-UP
20 FS2-9394-000 1 SCREW,STEPPED,M3X1.4
21 FS1-1510-000 2 BUSHING
22 FG6-3954-000 1 SEPARATION ROLLER ASSEMBLY
23 FA3-8727-000 1 RING, RETAINING
24 FB5-0466-000 1 ROLLER, SEPARATION
25 FB5-0486-000 1 ROLLER, PICK-UP
26 FS1-1528-000 1 BUSHING
27 FS2-1357-000 1 BUSHING
28 FS5-1903-000 1 BUSHING
P30-3 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P30 - 29 FS7-0469-000 1 GEAR, 30T
30 FS7-0470-000 1 GEAR, 35T
31 FS5-9439-000 AR SCREW,MACH.,TRUSS HEAD,M3X4
32 FB5-2233-000 1 PLATE, SUPPORT
33 XA9-0894-000 AR SCREW,M3X6
34 XA9-0892-000 AR SCREW,MACH.,TRUSS HEAD,M4X6
35 RS5-9061-000 1 SCREW,STEPPED,M3
36 FS5-9563-000 2 SCREW,STEPPED,M3X1.4
37 FB5-0501-000 1 COVER, BELT SEE NOTE 2
501 XD3-2200-122 2 PIN,DOWEL
502 XD3-1200-082 1 PIN,SPRING
503 XD2-2100-802 1 RING,GRIP
504 XD2-1100-642 2 RING,E
505 XD2-1100-502 2 RING,E
506 XD2-1100-322 1 RING,E
507 XB1-2300-607 2 SCREW,MACH.,TRUSS HEAD,M3X6
508 XB1-2300-409 3 SCREW,MACH.,TRUSS HEAD,M3X4
509 XB1-2300-406 1 SCREW,MACH.,TRUSS HEAD,M3X4
510 XB6-7300-609 1 SCREW,TP,M3X6 SEE NOTE 2
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P30-4
DOCUMENT PICK-UP COVER ASSEMBLY
FIGURE P31
1
2
4
3 2
NOTE : This assembly is included in the assembly shown in Figure P30.
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P31 - FG6-3956-000 1 DOCUMENT PICK-UP COVER ASS'Y SEE NOTE
1 FB5-0470-000 1 GUIDE, REGISTRATION, OUTER
2 FB5-0472-000 2 ARM, RELEASE, REGISTRATION
3 FF5-9162-000 1 COVER, DOCUMENT PICK-UP
4 FF5-9163-000 1 PRISM, REGISTRATION
P31-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
SEPARATION LOWER GUIDE ASSEMBLY
FIGURE P32
6A
6
501
8
502 13
1 11
15
501
12 502
14
501
9
9 4
5
7
3
501
10A
501
2
501
10
NOTE : This assembly is included in the assembly shown in Figure P30.
P32-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P32 - FG6-3952-000 1 SEPARATION LOWER GUIDE ASS'Y SEE NOTE
1 FB5-0451-000 1 GUIDE, SEPARATION LOWER, REAR
2 FB5-0457-000 1 MOUNT, SEPARATION PAD
3 FB5-0490-000 1 ROLLER, GUIDE
4 FF5-9154-000 1 PRISM, DOCUMENT DETECTION
5 FF5-9160-000 1 PAD, SEPARATION
6 FF5-9161-000 1 LIFTER
6A FB5-0494-000 1 SHEET
7 FS6-2370-000 1 SPRING, COMPRESSION
8 FS7-2234-000 1 SPRING, COMPRESSION
9 FS5-6703-000 2 ROLLER, PAD
10 FG6-3953-000 1 PRE-REGISTRATION SENSOR ASS'Y
10 A FB5-0474-000 1 CAP, LED
11 FG6-3957-000 1 PAD RELEASE LEVER ASSEMBLY
12 FB5-0452-000 1 SPRING, TORSION
13 FB5-0454-000 1 LEVER, PAD RELEASE, 1
14 FB5-0455-000 1 LEVER, PAD RELEASE, 2
15 FB5-0456-000 1 LEVER, PAD RELEASE, 3
501 XB1-2300-609 13 SCREW,MACH.,TRUSS HEAD,M3X6
502 XB1-2300-409 2 SCREW,MACH.,TRUSS HEAD,M3X4
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P32-2
SEPARATION UPPER GUIDE ASSEMBLY
FIGURE P33
501
6
7
501
(SR3)
(J103)
(SR2)
(J102)
3
502 501 3
8
1
4A
2 (J301)
(J1102)
4
5
(J103)
(J102)
NOTE : This assembly is included in the assembly shown in Figure P30.
P33-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P33 - FG6-3951-000 1 SEPARATION UPPER GUIDE ASS'Y SEE NOTE
1 FB5-0447-000 1 FLAG, SEPARATION SENSOR
2 FB5-0498-000 1 SPRING, TORSION
3 WG8-5362-000 2 IC, TLP1241, PHOTO-INTERRUPTER SR2,3 J102,103
4 FG3-0490-000 1 PICK-UP CENTER CABLE J102,103,301,1102
4A VS1-5057-011 1 CONNECTOR, SNAP TIGHT J1102
5 FF5-9483-000 1 GUIDE, SEPARATION UPPER
6 FB5-0382-000 1 SHEET, PICK-UP CABLE
7 FG3-0235-000 1 DOCUMENT SENSOR PCB ASSEMBLY
8 FG3-0485-000 1 DISPLAY LED PCB ASSEMBLY
501 XB1-2300-609 5 SCREW,MACH.,TRUSS HEAD,M3X6
502 XB4-7400-809 4 SCREW,TAPPING,TRUSS HEAD,M4X8
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P33-2
FEEDER ASSEMBLY
FIGURE P35
6 1
10
12
10 502
4
7 8
3 10
7
5 6
9
TO FIGURE P30 501
2 10
Y 502
4
8 8
4
503
11A
3
8
11 4
503
P35-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P35 - FG6-3965-000 1 FEEDER ASSEMBLY
1 FB4-6934-000 1 BELT, FEEDER
2 FB5-0521-000 1 PULLEY, 14T
3 FS7-2239-000 2 SPRING, TENSION
4 XD9-0151-000 4 WASHER
5 FG6-3966-000 1 ROLLER, IDLER, FEEDER BELT
6 FB5-0419-000 2 FLANGE
7 FS7-2229-000 4 SPRING, TENSION
8 XG9-0403-000 4 BEARING, BALL
9 FS7-2230-000 8 SPRING, TENSION
10 FB5-2215-000 14 ROLLER, BELT PRESSURE
11 FG6-3967-000 1 ROLLER, DRIVE, FEEDER BELT
11 A FB4-6918-000 8 RUBBER, ROLLER
12 FS7-2364-000 2 SPRING, TENSION
501 XB6-2400-409 1 SETSCREW,M4X4
502 XD2-1100-642 2 RING,E
503 XD2-2100-802 2 RING,GRIP
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P35-2
REVERSE DELIVERY ASSEMBLY (1/2)
FIGURE P40
A
33
506
511 36
31
35
34
32
508
502
11 14
501
502 30
8
C
508
B
32
17 SEE FIGURE P41 29
507
9
A
37
510
37
(J110) B 18
(SR7)
22
SEE FIGURE P42
8
10
509
37
12 2
(J112)
(M3)
27
28
37 C
19
512
43 37
516
NOTE 1 : This assembly includes the assemblies shown in Figure P41, P42.
NOTE 2 : This assembly does not include the parts shown with key No. 43 and 516.
P40-1 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
REVERSE DELIVERY ASSEMBLY (2/2)
FIGURE P40
21
20B 505
6
(J1107) (J108) 15
(J112) 515
20
505
(J109) (J107)
(J9) (J7) (J110) 37
(J111) (J502) (J107)
20A (SR4)
16
D
40 37
38
42
39 25
41
513
16
(J111)
37 (SR8) 503
7 504 16
(J108) 37
(SR5) 514
3
37
1 26
13
7
24
D 503
7
503
37 23
503
5 4
508 508
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P40-2
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P40 - FG6-3938-000 1 REVERSE DELIVERY ASSEMBLY SEE NOTE 1
1 FB5-0351-000 1 FLAPPER
2 FB5-0358-000 1 PLATE, FLAPPER ADJUSTMENT
3 FB5-0363-000 1 FLAG, SENSOR, DELIVERY
4 FB5-0364-000 1 LIMITTER, TORQUE, DELIVERY
5 FB5-0365-000 1 GEAR, 34T
6 FB5-0375-000 1 FLAG, SENSOR, INLET
7 FS5-1897-000 3 BUSHING
8 FS5-1898-000 2 BUSHING
9 FS5-3754-000 1 PULLEY, 64T/GEAR, 12T
10 FS7-0462-000 1 GEAR, 16T
11 FS7-0463-000 1 GEAR, 60T
12 FS7-2222-000 1 SPRING, TENSION
13 FS7-2223-000 1 SPRING, TENSION
14 FS7-2225-000 1 SPRING, TENSION
15 FS7-2226-000 1 SPRING, TORSION
16 WG8-5362-000 3 IC, TLP1241, PHOTO-INTERRUPTER SR4,5,8 J107,108,111
17 XF2-1108-740 1 BELT, TIMING
18 FS7-2228-000 1 SPRING, TENSION
19 FH6-1673-000 1 MOTOR, DC M3 J112
20 FG3-0489-000 1 DELIVERY CABLE J7,9,109-112,502
J1107
20 A VS1-6198-005 1 CONNECTOR, SNAP TIGHT J502
20 B VS1-6198-006 1 CONNECTOR, SNAP TIGHT J1107
21 FG3-0492-000 1 DELIVERY INLET CABLE J107,108,1107
22 WG8-5426-000 1 IC,GP1AQ73A,PHOTO-INTERRUPTER SR7 J110
23 FB5-0367-000 1 GEAR, 12T
24 FB5-2218-000 1 STATIC CHARGE ELIMINATOR
25 FF5-9150-000 1 FLAPPER, INLET, 2
26 FB5-0360-000 1 ARM, FLAPPER
27 FB5-0414-000 1 ARM, FLAPPER, OUTLET
P40-3 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P40 - 28 FB5-0415-000 1 SPRING, TORSION
29 FG6-3940-000 1 CENTER GUIDE ASSEMBLY
30 FB5-0394-000 1 ROLLER, FEEDER
31 FB5-0398-000 1 COVER, GEAR, FEEDER
32 FS5-1899-000 2 BUSHING
33 FS7-0464-000 1 GEAR, 50T
34 FS7-0465-000 1 GEAR, 15T
35 FS7-0466-000 1 GEAR, 58T
36 FB5-0352-000 1 ROLLER, REVERSE
37 XA9-0894-000 AR SCREW,M3X6
38 FG6-3941-000 1 INLET FLAPPER ASSEMBLY
39 FB5-0403-000 1 SHAFT, FLAPPER COMPRESSION
40 FB5-0405-000 1 SCREW,MACH.,PAN HEAD,M2X6
41 FS7-2221-000 1 SPRING, COMPRESSION
42 FS7-2227-000 1 SPRING, COMPRESSION
43 FB5-0499-000 1 SPRING, LEAF SEE NOTE 2
501 XD3-2200-182 1 PIN,DOWEL
502 XD2-1100-642 3 RING,E
503 XD2-1100-322 5 RING,E
504 XD2-2100-502 2 RING,GRIP
505 XD2-2300-202 2 RING,TOOTHED LOCK
506 XD3-2200-142 1 PIN,DOWEL
507 XD2-1100-402 1 RING,E
508 XD2-1100-502 4 RING,E
509 XD2-2100-402 1 RING,GRIP
510 XB1-2400-609 1 SCREW,MACH.,TRUSS HEAD,M4X6
511 XB4-7300-809 3 SCREW,TAPPING,TRUSS HEAD,M3X8
512 XB6-7301-009 1 SCREW,TP,M3X10
513 XD2-1100-242 1 RING,E
514 XD3-1200-082 1 PIN,SPRING
COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON] P40-4
R Q
/
FIGURE
PART NUMBER A DESCRIPTION SERIAL NUMBER / REMARKS
& N T
KEY NO. K Y
P40 - 515 XD3-2200-182 1 PIN,DOWEL
516 XB6-7300-606 1 SCREW,TP,M3X6 SEE NOTE 2
P40-5 COPYRIGHT C 1999 CANON INC. CANON DADF-B1 REV.0 MAR. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
