Image preview - the first page of the document



>> Download B100_005 documenatation <<

Text preview - extract from the document

                                 SERVICE BULLETIN                                              FAX
                                        Issued by Canon Europa N.V.


       MODEL:       FAX-B100, MultiPASS 10                              No.:  B100-005
                                                                              (HS-B0E-0049-01)
                                                                        Date: 03.05.96


LOCATION:              OUTER PACKAGING

MODEL NO.:             H12-0273 (EC)       H12-0303 (EC)

SUBJECT:               PACKAGING MODIFICATION


OUTLINE

In order to avoid a repeat of the situation where a machine arrived at a customers premises with the
logic board cover off, and was unable to feed the recording paper, the logic board cover will now be
fixed with four strips of tape, instead of two.




MACHINE

     MODEL NO.          H12-0273-214         H12-0303-210
    M/C VERSION              --                   --
     SERIAL NO.          EJK-03920            EJJ-08374
