Image preview - the first page of the document
>> Download B100_003 documenatation <<
Text preview - extract from the document
SERVICE BULLETIN FAX
Issued by Canon Europa N.V.
MODEL: FAX-B100/MultiPASS 10 No.: B100-003
(HS-B0E-0028-01)
Date: 05.04.96
LOCATION: LOWER COVER UNIT
MODEL NO.: H12-0273 (EC) H12-0303 (EC)
SUBJECT: PARTS ADDED
New ink sheet set as part of ink leaking countermeasure.
The ink seat is stuck to the LOWER COVER UNIT (HG5-0108).
See diagram below.
No gap possible with rib at B.
Ride up less than 0.5 mm for the ribs A,B,C.
PARTS
MODEL NO. PARTS NAME PARTS NO. VER. IC LOCATION NO.
ALL OLD ---- ---- -- -- ---
NEW ABSORBER, WASTE INK HB1-2193-000 --
MACHINE
MODEL NO. H12-0273-210 H12-0273-214
M/C VERSION ---- ----
SERIAL NO. EJG-02385 ----
