Image preview - the first page of the document
>> Download B100_047 documenatation <<
Text preview - extract from the document
SERVICE BULLETIN FAX
Issued by Canon Europa N.V.
MODEL: MultiPASS 10 No.: B100-047
(HS-B0E-8020-01)
Date: 30.01.98
LOCATION: SCNT BOARD ASS'Y
MODEL NO.: H12-0303
SUBJECT: MAIN ROM UPGRADE
OUTLINE
The main ROM version has been upgraded from EC-09-04 to EC-15-02-A.
FAX -2- B100-047
PARTS
PARTS NAME PARTS NO. VER. IC LOCATION NO.
OLD IC, LH538B46, MASK-ROM HH4-2675-000 09 NY IC-2
NEW IC, LH538B4G, MASK-ROM HH4-2675-020 15
OLD SCNT BOARD ASS'Y HG5-0622-100 -- NY ---
NEW SCNT BOARD ASS'Y HG5-0622-100 --
MACHINE
MODEL NO. H12-0303-210 H12-0303-214
M/C VERSION 09 10 09 10
SERIAL NO. Suspended
