Image preview - the first page of the document
>> Download B100_049 documenatation <<
Text preview - extract from the document
SERVICE BULLETIN FAX
Issued by Canon Europa N.V.
MODEL: FAX-B100 No.: B100-049
(HS-B0E-8033-01)
Date: 30.01.98
LOCATION: SCNT BOARD ASS'Y
MODEL NO.: H12-0273
SUBJECT: MAIN ROM UPGRADE
OUTLINE
The main ROM version has been upgraded from EC-16-01 to EC-16-02.
PARTS
PARTS NAME PARTS NO. VER. IC LOCATION NO.
OLD IC, LH538B4T, MASK-ROM HH4-2674-030 16 NY IC-2
NEW IC, LH538B5R, MASK-ROM HH4-2674-040 16
OLD SCNT BOARD ASS'Y HG5-0619-120 -- NY ---
NEW SCNT BOARD ASS'Y HG5-0619-120 --
MACHINE
MODEL NO. H12-0273-230 H12-0273-234
M/C VERSION 13 14 13 14
SERIAL NO. Suspended EXU-17801
