Image preview - the first page of the document
>> Download B100_050 documenatation <<
Text preview - extract from the document
SERVICE BULLETIN FAX
Issued by Canon Europa N.V.
MODEL: MultiPASS 10 No.: B100-050
(HS-B0E-8034-01)
Date: 30.01.98
LOCATION: SCNT BOARD ASS'Y
MODEL NO.: H12-0303
SUBJECT: MAIN ROM UPGRADE
OUTLINE
The main ROM version has been upgraded from EC-16-01-A to EC-16-02-A.
PARTS
PARTS NAME PARTS NO. VER. IC LOCATION NO.
OLD IC, LH538B4U, MASK-ROM HH4-2675-030 16 NY IC-2
NEW IC, LH538B5S, MASK-ROM HH4-2675-040 16
OLD SCNT BOARD ASS'Y HG5-0622-100 -- NY ---
NEW SCNT BOARD ASS'Y HG5-0622-100 --
MACHINE
MODEL NO. H12-0303-214 H12-0303-220 H12-0303-224
M/C VERSION 13 14 13 14 13 14
SERIAL NO. Suspended Suspended EXU-03486
