Image preview - the first page of the document
>> Download candy_cdi3015s documenatation <<
Text preview - extract from the document
32900040 CDI3015 S
Service Manual
395
299
208
208a
122
296 313
209
127
200 126
217
272 295b
225
117
287 297
295a
333
495
IELS2521
Mod: 32900040 CDI3015 S 0435 (24/08/2004)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
8 Adjustable foot 92250901
8c Rear adjustable foot 91670150
14g ON-OFF push button 41012556
14y Schedule switch assy 41012426
21a Control panel 41012755
27 Closure regulator 91800770
28 Catch 92731090
29 Screw 41005335
44 Door lock 41013195
54a Innerdoor lower gasket 91620003
55 Front gasket 41010838
56 Special screw 92419530
58 L/H gasket holder 91617514
59 Cornet f.gasket 92605757
60 Upper gasket holder 91617530
64a Felt 41004750
66 R/H gasket holder 91617522
69 Insulating panel 91600504
85c R/H hinge assy 41007158
85d L/H hinge assy 41007159
92 Innerdoor 41010279
92a Innerdoor screw 91402402
93 Door 91800076
100 Electrodistributor 41010202
103 Gasket 49004681
117 Nozzle 92694801
122 Gasket 91620012
126 Seal gasket 91620014
127 Metal ring 91600586
135 Gasket 91620008
138 Drain hose 91670102
Copyright 2005 Gias S.r.L.
Mod: 32900040 CDI3015 S 0435 (24/08/2004)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
138a Drain house elbow 92689587
138b Hoseb clamp 91600328
148a Outer heater assy 41006831
150 Door micro switch 41009693
151a Electronic module 41008097
151b Electr.plate box 41012374
151f Program electronic module 41012533
151i Electronic plate cover 41012373
153 Level switch 41001361
155 Pilot lamp 91209510
156 Capacitor 92219435
157 Wiring harness 41012840
157k 8 Way connecton 41012762
161 Drain pump 91200173
161a Drain pump scroll 91600290
164 Anti jamming filter radio 91200489
171 Motor pump 41010872
172 Clip 91408000
173 Hose 91620007
174 Motor end 92736032
177 Motor Schoch absorber 92131762
178 Washer 92439835
179 Bearing 92440148
180 Fan 92141449
183 Motor securing bolt 92401397
184 Stator 41010876
185 Rotor 91750371
186 Fan 92141431
188 Motor end 92736040
190 Washer 91406200
192 Pump assembly 41001311
Copyright 2005 Gias S.r.L.
Mod: 32900040 CDI3015 S 0435 (24/08/2004)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
200 Drawer grasket 91406300
204a Upper spray arm 41009782
204b Lower spray arm 41009781
205 Spray arms tube 41006828
208 Filter 41005927
208a Microfilter 91670082
209 Filter plate 91800738
217 Filter bacin. 91670113
218 OR seal gasket 91406302
225a Thermostat Gasket 92445626
241 Lower basket wheel 91601039
243 Lower basket 41009338
243b Inclinable plates holder 41011331
244 Upper basket 41011413
244a Plates holder 41008446
244b Basket regulation assy L/H 41011423
244c Basket regulation assy R/H 41011424
244d Grip 41011412
245 Basket wheel pin 92608637
246 Basket wheel upper. 92655596
249a R/H front-L/H rear cups basket 41000749
249b L/H front-R/H rear cups basket 41000750
250 Wheel stopper 91619627
251 Runner 91800137
257 Cutlery basket 41011414
257b Cutlery holder 41011411
258a Basket rear handle 41011419
258b Basket front handle 41011418
272 Clip 92470350
275 Level hose 92053396
280 Clip 92470202
Copyright 2005 Gias S.r.L.
Mod: 32900040 CDI3015 S 0435 (24/08/2004)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
283a Hub 41009859
284 Tub assy 41006826
287m NTC probe 92743616
292b Dispenser drawer 91600548
293b Fill hose assy with electrovalve 41005471
294b Water-block sensor 91200528
295a Water softener 91200534
295b Water softener OR seal gasket 91941698
296 Water softener stopper 91670172
297 Hose 91620010
299 Water softener capacitor 41010398
305 Spring 92483809
305b Door balance assy 41008160
313 Funnel 91601457
314 Slider 91600272
315 Spring 92484021
316 Center square 91600271
318 Upper ramp tube 41009353
321a Deviator 41009202
321b Deviator valve 91600267
321c Deviator valve holder 41009257
321d Non return valve 91941700
322 Seal 91406301
323 Seal 41009258
330 Subseq.runner ass.support 91670988
333 Water softener reed 91941699
362 Wheel support reinforc. 91602344
364 Upper basket stopper 91601047
377 Center square 91621961
395 Air break ring nut 91600575
399 Built-in envelope assy 41012952
Copyright 2005 Gias S.r.L.
Mod: 32900040 CDI3015 S 0435 (24/08/2004)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
402 Harness protection 41006833
408a R/H later.panel 41007178
408b L/H later.panel 41007179
474 Safety switch 41009092
474a Gasket safety switch 41009096
491 Main cable 91200194
492 Socle 91600126
493 Upper cover 91800072
618c Unipolar NA+P.A. switch 90489683
797 Hook 92734912
798 Clutch body 91601427
799 Clutching band 92895838
824 Pin 91600493
824a Rod 91600495
834 Screw 92418151
839 Clip 92470277
999 Wiring diagram 41013019
Copyright 2005 Gias S.r.L.
ELETTRONICA ECO-EASY 17/02/2004
FASI DI LAVAGGIO 1 - PROGRAMMA PRELAVAGGIO Tempistica
