Image preview - the first page of the document
>> Download compaq_p700_sony_d99_chassis documenatation <<
Text preview - extract from the document
SERVICE MANUAL P700
P700
UK Model
Chassis No. SCC-L29P-A
D99 CHASSIS
SPECIFICATIONS
Picture tube 0.24-0.25 mm aperture grill pitch Power Consumption
17 inches measured diagonally Maximum 130 W
90-degree deflection Nominal 95 W
Video image area (16" maximum viewing image) Deflection frequency Horizontal: 30 to 92 KHz
Approx. 327 X 243 mm (w/h) Vertical: 48 to 120 Hz
(127/8 x 95/8 inches)
AC input voltage / current 100 to 120 V, 50/60 Hz, 1.7A
Resolution Horizontal: Max. 1600 dots 220 to 240V, 50/60Hz, 0.9A
Vertical: Max. 1200 lines
Dimensions 404 x 428 x 424 mm (w/h/d)
Standard image area Approx. 312 x 234 mm (w/h) (159/10 x 167/8 x 167/10 inches)
(121/4 x 91/4 inches)
Mass Approx. 19.2 kg (42 lb 11 oz.)
Input signal
Video Analog RGB (75 ohms typical)
0.7 Vp-p, ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
