Image preview - the first page of the document
>> Download compaq 7710 documenatation <<Text preview - extract from the document Armada 7700
Processor/System Boards Assembly Spare Part System
Processor Board (586/150L2 MHz) 005009-006 220707-005 7710
Processor Board (586/166L2 MHz) 005009-005 220707-006 7730, 50
Processor Board, (586/233L2 MHz) 007394-001 291758-001 7770, 90
Processor Board, (586/266L2 MHz) 007394-002 291758-002 7792
System Board, 16/2 MB 005006-001 220694-001 7710, 30,
50
System Board,16/2 MB 007747-001 291736-001 7770
System Board,16/2 MB 007653-001 315764-001 7790, 92
Configuration System Board System Board
Code/Model * Assembly Spare Part Display
BB22 005006-001 220694-001 12.1" SVGA CTFT
7710T*
BB32 005006-001 220694-001 12.1" SVGA CTFT
7710MT*
BB63 005006-001 220694-001 12.1" SVGA CTFT
7730T
BB73 005006-001 220694-001 12.1" SVGA CTFT
7730MT
BCB3 005006-001 220694-001 12.1" XGA CTFT
7750T
BCN3 005006-001 220694-001 12.1" XGA CTFT
7750MT
BRT1 007747-001 291736-001 12.1" SVGA CTFT
7770DMT
