Image preview - the first page of the document
>> Download compaq armada e500 e500s v300 documenatation <<
Text preview - extract from the document
Compaq Armada E500, Armada E500S, and
Armada V300 Series of Personal Computers
Maintenance and Service Guide
Notice
2000 Compaq Computer Corporation.
COMPAQ, the Compaq logo, ARMADA, and Compaq Insight Manager Registered in
U. S. Patent and Trademark Office
Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation.
Intel, Pentium, and Celeron are registered trademarks of Intel Corporation.
All other product names mentioned herein may be trademarks or registered
trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors or omissions contained
herein. The information in this document is subject to change without notice.
The information in this publication is provided "as is" without warranty of any
kind. The entire risk arising out of the use of this information remains with the
recipient. In no event shall Compaq be liable for any direct, consequential,
incidental, special, punitive or other damages whatsoever (including without
limitation, damages for loss of business profits, business interruption or loss of
business information), even if Compaq has been advised of the possibility of such
damages and whether in an action or contract or tort, including negligence.
The limited warranties for Compaq products are exclusively set forth in the
documentation accompanying such products. Nothing herein should be construed
as constituting a further or additional warranty.
MAINTENANCE AND SERVICE GUIDE
Compaq Armada E500, E500S, and Armada V300 Series of
Personal Computers
Sixth Edition (October 2000)
First Edition (November 1999)
Published in the U.S.A., U.K., Singapore, and Taiwan.
Documentation Part Number 128679-006
Spare Part Number 162812-001
CONTENTS
preface
USING THIS GUIDE
Symbols ........................................................................................ ix
Technician Notes ........................................................................... x
Serial Number................................................................................ x
Locating Additional Information................................................... x
chapter1
PRODUCT DESCRIPTION
1.1 Models and Features............................................................1-1
1.2 Intelligent Manageability ..................................................1-15
1.3 Computer External Components .......................................1-19
1.4 Design Overview ...............................................................1-30
chapter2
TROUBLESHOOTING
2.1 Preliminary Steps.................................................................2-2
2.2 Clearing Passwords .............................................................2-3
2.3 Power-On Self-Test (POST)................................................2-4
2.4 POST Error Messages .........................................................2-4
2.5 Compaq Utilities..................................................................2-9
2.6 Troubleshooting Without Diagnostics...............................2-17
chapter3
ILLUSTRATED PARTS CATALOG
3.1 Serial Number Location ......................................................3-1
3.2 Computer System Major Components ................................3-2
3.3 Miscellaneous Plastics Kit Components ...........................3-12
3.4 Mass Storage Devices........................................................3-13
3.5 Miscellaneous ....................................................................3-14
Contents v
chapter4
REMOVAL AND REPLACEMENT PRELIMINARIES
4.1 Tools Required.................................................................... 4-1
4.2 Service Considerations........................................................ 4-1
4.3 Preventing Damage to Removable Drives.......................... 4-2
4.4 Preventing Electrostatic Damage........................................ 4-3
4.5 Packaging and Transporting Precautions............................ 4-4
4.6 Workstation Precautions ..................................................... 4-4
4.7 Grounding Equipment and Methods ................................... 4-5
chapter5
REMOVAL AND REPLACEMENT PROCEDURES
5.1 Serial Number ..................................................................... 5-1
5.2 Disassembly Reference Chart ............................................. 5-2
5.3 Preparing the Computer for Disassembly ........................... 5-2
5.4 Computer Feet..................................................................... 5-3
5.5 Mini PCI Slot ...................................................................... 5-4
5.6 Touch Button....................................................................... 5-6
5.7 Keyboard ............................................................................. 5-8
5.8 Memory............................................................................. 5-12
5.9 Display Assembly ............................................................. 5-15
5.10 Real Time Clock (RTC) Battery ..................................... 5-21
5.11 LED Board ...................................................................... 5-22
5.12 Top Cover........................................................................ 5-23
5.13 Front Shield..................................................................... 5-27
5.14 Diskette Drive (Armada V300 only)............................... 5-29
5.15 System Board .................................................................. 5-30
5.16 Voltage Converter Board ................................................ 5-34
5.17 Fan................................................................................... 5-36
chapter 6
SPECIFICATIONS...................................................................................... 6-1
vi Contents
appendix A
CONNECTOR PIN ASSIGNMENTS ................................................................ A-1
appendix B
POWER CORD SET REQUIREMENTS
3-Conductor Power Cord Set..................................................... B-1
Country-Specific Requirements ................................................ B-2
Index .................................................................................................... I-1
Contents vii
preface
U SING T HIS G UIDE
This Maintenance and Service Guide is a troubleshooting reference that
can be used when servicing the Compaq Armada E500 and ArmadaV300
Series of Personal Computers.
Compaq Computer Corporation reserves the right to make changes to the
Compaq Armada E500 and Armada V300 Series of Personal Computers
without notice.
Symbols
The following words and symbols mark special messages throughout
this guide:
WARNING: Text set off in this manner indicates that failure to follow
! directions in the warning could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow
directions in the caution could result in damage to equipment or loss
of information.
IMPORTANT: Text set off in this manner presents clarifying information
or specific instructions.
NOTE: Text set off in this manner presents commentary, sidelights, or
interesting points of information.
Using This Guide ix
Technician Notes
WARNING: Only authorized technicians trained by Compaq should
! repair this equipment. All troubleshooting and repair procedures are
detailed to allow only subassembly/module level repair. Because of
the complexity of the individual boards and subassemblies, no one
should attempt to make repairs at the component level or to make
modifications to any printed wiring board. Improper repairs can
create a safety hazard. Any indication of component replacement or
printed wiring board modifications may void any warranty or
exchange allowances.
WARNING: The computer is designed to be electrically grounded. To
! ensure proper operation, plug the AC power cord into a properly
grounded electrical outlet only.
CAUTION: To properly ventilate the system, you must provide at
least 3 inches (7.62 cm) of clearance on the left and right sides of
the computer.
Serial Number
When requesting information or ordering spare parts, provide the
computer serial number. The serial number is located on the bottom of
the computer.
Locating Additional Information
The following documentation provides information for the computer:
s Compaq Armada E500 and Armada V300 Series of Personal
Computers documentation set
s Compaq Armada E500 and Armada V300 Series of Personal
Computers Technical Reference Guide
s Microsoft Operating System Manual
s Compaq Service Training Guides
s Compaq Service Advisories and Bulletins
s Compaq QuickFind
s Compaq Service Quick Reference Guide
s Compaq Website at:
http://www.compaq.com
x Using This Guide
chapter
1
P RODUCT D ESCRIPTION
1.1 Models and Features
The Compaq Armada E500, E500S, and Armada V300 Series of
Personal Computers offer advanced modularity, Intel Pentium II, III, and
Intel Celeron processors with 64-bit architecture, industry-leading
Accelerated Graphics Port (AGP) implementation, and extensive
multimedia support. The computers provide desktop functionality and
connectivity through the optional expansion base, convenience base, or
port replicator.
Figure 1-1. Compaq Armada E500, E500S, and Armada V300
Personal Computers
Product Description 1-1
Models
The Armada E500 and E500S model naming conventions are shown in
Table 1-1. The computer model designation is composed of a group of
characters that defines each model's features.
Table 1-1
Compaq Armada E500 and E500S
Model Naming Convention
Key
A E 5 P3 850 T5P 20 V M 64 58 N S F
1 2 3 4 5-6 7-9 10-12 13-14 15 16 17-19 20-21 22 23 24
Key Description Options
1 Brand designator A = Armada
2 Segment designator E = Expansion
3 Series 5 = 500
4 Blank
5-6 Processor type P3 = Intel P2 = Intel C1 = Intel
Pentium III Pentium II Celeron 1
7-9 Processor speed 850 = 850 MHz 600 = 600 MHz 450 = 450 MHz
800 = 800 MHz 550 = 550 MHz 400 = 400 MHz
700 = 700 MHz 500 = 500 MHz 366 = 366 MHz
650 = 650 MHz
10 Panel type T = TFT
11 Panel size 5 = 15.x" 3 = 13.x"
4 = 14.x" 2 = 12.x"
12 Panel resolution P = SXGA+ X = XGA S = SVGA
13-14Hard drive size 20 = 20.0 GB 10 = 10.0 GB
(in GB, 1-2 digits) 18 = 18.0 GB 6 = 6.0 GB
12 = 12.0 GB 4 = 4.3 GB
15 Optical drive D = 24X Max CD-ROM V = DVD-ROM drive
drive
16 Integrated M = Mini PCI C = NIC/modem 0 = none
communication V.90 modem combo
17-19RAM (in MB, 64 = 64 MB
2-3 digits)
20-21Operating system 98 = Windows 98 N4 = Windows NT 4.0
58 = Windows 95/98 N2 = Windows NT 4.0/
dual install* Windows 2000
dual install*
22 NAFTA N = NAFTA
23 Pointing device S = Pointing stick P = TouchPad
24 Security
* End user must make a selection between the two operating systems. If end user
desires rejected product after selection is made, end user must acquire and pay for
rejected product separately.
1-2 Product Description
Table 1-2
Compaq Armada E500
Computer Models
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
3 1
A E 5 P3 850 T 5 P 20 V 0 128 98 179856-XX1 JFC1
3 1
A E 5 P3 850 T 5 P 20 V 0 128 N2 179856-XX8 JFC2
3 1
A E 5 P3 850 T 5 P 20 V C 128 98 179858-XX1 JFC3
3 1
A E 5 P3 850 T 5 P 20 V C 128 98 179858-XX3 JFC5
3 1
A E 5 P3 850 T 5 P 20 V C 128 N2 179858-XX8 JFC4
3 1
A E 5 P3 850 T 5 P 20 V C 128 N2 179858-XX9 JFC6
1
A E 5 P3 800 T 4 X 10 D 0 64 98 179854-XX1 JFB1
1
A E 5 P3 800 T 4 X 10 D 0 64 N2 179854-XX8 JFB2
1
A E 5 P3 800 T 4 X 10 D C 64 98 179855-XX1 JFB3
1
A E 5 P3 800 T 4 X 10 D C 64 98 179855-XX3 JFB5
1
A E 5 P3 800 T 4 X 10 D C 64 N2 179855-XX8 JFB4
1
A E 5 P3 800 T 4 X 10 D C 64 N2 179855-XX9 JFB6
3 1
A E 5 P3 700 T 5 X 18 V M 128 58 174518-XX1 DX44
3 1
A E 5 P3 700 T 5 X 18 V M 128 58 N 174518-XX3 DX45
3 1
A E 5 P3 700 T 5 X 18 V M 128 N4 174518-XX6 DX46
3 1
A E 5 P3 700 T 5 X 18 V M 128 N4 N 174518-XX7 DX47
3 1
A E 5 P3 700 T 5 X 18 V M 128 N2 174518-XX8 FFH2
3 1
A E 5 P3 700 T 5 X 18 V M 128 N2 174518-XX9 FFH3
3 1
A E 5 P3 700 T 5 X 18 V 0 128 58 174517-XX1 DX41
3 1
A E 5 P3 700 T 5 X 18 V 0 128 N4 174517-XX6 DX43
3 1
A E 5 P3 700 T 5 X 18 V 0 128 N2 174517-XX8 FFH1
3 1
A E 5 P3 700 T 5 X 18 V C 128 58 174519-XX1 DX48
3 1
A E 5 P3 700 T 5 X 18 V C 128 N4 174519-XX6 DX49
3 1
A E 5 P3 700 T 5 X 18 V C 128 N2 174519-XX8 FFH4
1
A E 5 P3 700 T 4 X 12 D 0 64 58 179847-XX1 FMX1
1
A E 5 P3 700 T 4 X 12 D 0 64 N2 179847-XX8 FMX3
1
A E 5 P3 700 T 4 X 12 D M 64 58 179848-XX1 FMX4
1
A E 5 P3 700 T 4 X 12 D M 64 58 179848-XX3 FMX5
1
A E 5 P3 700 T 4 X 12 D M 64 N2 179848-XX8 FMX8
1
A E 5 P3 700 T 4 X 12 D M 64 N2 179848-XX9 FMX9
1
A E 5 P3 700 T 4 X 12 D C 64 58 179849-XX1 FMZ1
1
A E 5 P3 700 T 4 X 12 D C 64 N2 179849-XX3 FWZ1
1
A E 5 P3 700 T 4 X 12 D C 64 N2 179849-XX8 FMZ3
1
A E 5 P3 700 T 4 X 12 D C 64 N2 179849-XX9 FWZ2
1 3
9-cell Lithium Ion main battery pack 8X DVD-ROM drive
2 4
6-cell Lithium ion main battery pack 4X DVD-ROM drive
Continued
Product Description 1-3
Table 1-2 continued
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
1
A E 5 P3 700 T 3 X 5 D M 64 98 212281-XX1 JFF3
1
A E 5 P3 700 T 3 X 5 D M 64 98 212281-XX3 JFF5
1
A E 5 P3 700 T 3 X 5 D M 64 N2 212281-XX8 JFF4
1
A E 5 P3 700 T 3 X 5 D M 64 N2 212281-XX9 JFF6
1
A E 5 P3 700 T 3 X 5 D C 64 98 212282-XX1 JFF7
1
A E 5 P3 700 T 3 X 5 D C 64 98 212282-XX3 JFF9
1
A E 5 P3 700 T 3 X 5 D C 64 N2 212282-XX8 JFF8
1
A E 5 P3 700 T 3 X 5 D C 64 N2 212282-XX9 JFFA
1
A E 5 P3 700 T 3 X 5 D 0 64 98 212327-XX1 JFF1
1
A E 5 P3 700 T 3 X 5 D 0 64 N2 212327-XX8 JFF2
4 1
A E 5 P3 650 T 4 X 12 V 0 64 58 161608-XX1 DPB1
4 1
A E 5 P3 650 T 4 X 12 V 0 64 N4 161608-XX6 DPB3
4 1
A E 5 P3 650 T 4 X 12 V 0 64 N2 161608-XX8 FFD5
4 1
A E 5 P3 650 T 4 X 12 V M 64 58 161609-XX1 DPB4
4 1
A E 5 P3 650 T 4 X 12 V M 64 58 N 161609-XX3 DPB5
4 1
A E 5 P3 650 T 4 X 12 V M 64 N4 161609-XX6 DPB6
4 1
A E 5 P3 650 T 4 X 12 V M 64 N4 N 161609-XX7 DPB7
4 1
A E 5 P3 650 T 4 X 12 V M 64 N2 161609-XX8 FFD6
4 1
A E 5 P3 650 T 4 X 12 V M 64 N2 N 161609-XX9 FFD7
4 1
A E 5 P3 650 T 4 X 12 V C 64 58 164764-XX1 DPB8
4 1
A E 5 P3 650 T 4 X 12 V C 64 N4 164764-XX6 DPB9
4 1
A E 5 P3 650 T 4 X 12 V C 64 N2 164764-XX8 FFD8
1
A E 5 P3 600 T 4 X 12 D 0 64 58 161606-XX1 DN91
1
A E 5 P3 600 T 4 X 12 D 0 64 N4 161606-XX6 DN93
1
A E 5 P3 600 T 4 X 12 D 0 64 N2 161606-XX8 FFD1
1
A E 5 P3 600 T 4 X 12 D M 64 58 161607-XX1 DN94
1
A E 5 P3 600 T 4 X 12 D M 64 58 N 161607-XX3 DN95
1
A E 5 P3 600 T 4 X 12 D M 64 N4 161607-XX6 DN96
1
A E 5 P3 600 T 4 X 12 D M 64 58 N 161607-XX7 DN97
1
A E 5 P3 600 T 4 X 12 D M 64 N2 161607-XX8 FFD2
1
A E 5 P3 600 T 4 X 12 D M 64 N2 N 161607-XX9 FFD3
1
A E 5 P3 600 T 4 X 12 D C 64 58 164763-XX1 DN98
1
A E 5 P3 600 T 4 X 12 D C 64 N4 164763-XX6 DN99
1
A E 5 P3 600 T 4 X 12 D C 64 N2 164763-XX8 FFD4
1 3
9-cell Lithium Ion main battery pack 8X DVD-ROM drive
2 4
6-cell Lithium ion main battery pack 4X DVD-ROM drive
Continued
1-4 Product Description
Table 1-2 continued
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
1
A E 5 P3 600 T 3 X 6 D 0 64 58 179844-XX1 FL51
1
A E 5 P3 600 T 3 X 6 D 0 64 N2 179844-XX8 FL53
1
A E 5 P3 600 T 3 X 6 D M 64 58 179845-XX1 FL54
1
A E 5 P3 600 T 3 X 6 D M 64 N2 179845-XX3 FL55
1
A E 5 P3 600 T 3 X 6 D M 64 58 179845-XX8 FL58
1
A E 5 P3 600 T 3 X 6 D M 64 N2 179845-XX9 FL59
1
A E 5 P3 600 T 3 X 6 D C 64 58 179846-XX1 FL61
1
A E 5 P3 600 T 3 X 6 D C 64 N2 179846-XX8 FL63
1
A E 5 P3 600 T 2 S 5 D M 64 58 207063-XX1 FVY1
1
A E 5 P3 600 T 2 S 5 D M 64 58 207063-XX3 FVY4
1
A E 5 P3 600 T 2 S 5 D M 64 N2 207063-XX8 FVY2
1
A E 5 P3 600 T 2 S 5 D M 64 N2 207063-XX9 FVY3
1
A E 5 P3 500 T 4 X 12 D 0 64 58 187427-XX1 FLC1
1
A E 5 P3 500 T 4 X 12 D 0 64 N4 187427-XX6 FLC2
1
A E 5 P3 500 T 4 X 12 D 0 64 N2 187427-XX8 FLC3
1
A E 5 P3 500 T 4 X 12 D M 64 58 187428-XX1 FLC4
1
A E 5 P3 500 T 4 X 12 D M 64 N4 187428-XX6 FLC5
1
A E 5 P3 500 T 4 X 12 D M 64 N2 187428-XX8 FLC6
1
A E 5 P3 500 T 4 X 12 D C 64 58 187429-XX1 FLC7
1
A E 5 P3 500 T 4 X 12 D C 64 N4 187429-XX6 FLC8
1
A E 5 P3 500 T 4 X 12 D C 64 N2 187429-XX8 FLC9
1
A E 5 P3 500 T 3 X 6 D O 64 58 161604-XX1 DNN1
1
A E 5 P3 500 T 3 X 6 D O 64 98 161604-XX4 DNN2
1
A E 5 P3 500 T 3 X 6 D O 64 N4 161604-XX6 DNN3
1
A E 5 P3 500 T 3 X 6 D M 64 58 161605-XX1 DNN4
1
A E 5 P3 500 T 3 X 6 D M 64 58 N 161605-XX3 DNN5
1
A E 5 P3 500 T 3 X 6 D M 64 N4 161605-XX6 DNN6
1
A E 5 P3 500 T 3 X 6 D M 64 N4 N 161605-XX7 DNN7
1
A E 5 P3 500 T 3 X 6 D C 64 58 164749-XX1 DNN8
1
A E 5 P3 500 T 3 X 6 D C 64 N4 164749-XX6 DN83
1 2
9-cell Lithium Ion main battery pack 6-cell Lithium ion main battery pack
Continued
Product Description 1-5
Table 1-2 continued
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
1
A E 5 P3 500 T 2 S 6 D 0 64 58 161602-XX1 DNM1
1
A E 5 P3 500 T 2 S 6 D 0 64 98 161602-XX4 DNM2
1
A E 5 P3 500 T 2 S 6 D 0 64 N4 161602-XX6 DNM3
1
A E 5 P3 500 T 2 S 6 D M 64 58 161603-XX1 DNM4
1
A E 5 P3 500 T 2 S 6 D M 64 58 N 161603-XX3 DNM5
1
A E 5 P3 500 T 2 S 6 D M 64 N4 161603-XX6 DNM6
1
A E 5 P3 500 T 2 S 6 D M 64 N4 N 161603-XX7 DNM7
1
A E 5 P3 500 T 2 S 6 D C 64 58 166761-XX1 DVM1
1
A E 5 P3 500 T 2 S 6 D C 64 N4 166761-XX6 DVM2
1
A E 5 P3 450 T 4 X 12 D 0 64 58 127669-XX1 CZQ1
1
A E 5 P3 450 T 4 X 12 D 0 64 98 127669-XX4 CZQ2
1
A E 5 P3 450 T 4 X 12 D 0 64 N4 127669-XX6 CZQ3
1
A E 5 P3 450 T 4 X 12 D M 64 58 127670-XX1 CZQ4
1
A E 5 P3 450 T 4 X 12 D M 64 58 N 127670-XX3 CZQ5
1
A E 5 P3 450 T 4 X 12 D M 64 N4 127670-XX6 CZQ6
1
A E 5 P3 450 T 4 X 12 D M 64 N4 N 127670-XX7 CZQ7
1
A E 5 P3 450 T 4 X 12 D C 64 58 164751-XX1 DN84
1
A E 5 P3 450 T 4 X 12 D C 64 N4 164751-XX6 DN85
1
A E 5 P2 400 T 4 X 6 D 0 64 58 152675-XX1 DC41
1
A E 5 P2 400 T 4 X 6 D 0 64 98 152675-XX4 DC42
1
A E 5 P2 400 T 4 X 6 D 0 64 N4 152675-XX6 DC43
1
A E 5 P2 400 T 4 X 6 D M 64 58 152676-XX1 DC44
1
A E 5 P2 400 T 4 X 6 D M 64 58 N 152676-XX3 DC45
1
A E 5 P2 400 T 4 X 6 D M 64 N4 152676-XX6 DC46
1
A E 5 P2 400 T 4 X 6 D M 64 N4 N 152676-XX7 DC47
1
A E 5 P2 400 T 4 X 6 D C 64 58 164748-XX1 DN81
1
A E 5 P2 400 T 4 X 6 D C 64 N4 164748-XX6 DN82
1 2
9-cell Lithium Ion main battery pack 6-cell Lithium ion main battery pack
Continued
1-6 Product Description
Table 1-2 continued
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
1
A E 5 P2 366 T 2 S 4 D 0 64 58 155058-XX1 DJC1
1
A E 5 P2 366 T 2 S 4 D 0 64 98 155058-XX4 DJC2
1
A E 5 P2 366 T 2 S 4 D 0 64 N4 155058-XX6 DJC3
1
A E 5 P2 366 T 2 S 4 D M 64 58 155059-XX1 DJC4
1
A E 5 P2 366 T 2 S 4 D M 64 58 N 155059-XX3 DJC5
1
A E 5 P2 366 T 2 S 4 D M 64 N4 155059-XX6 DJC6
1
A E 5 P2 366 T 2 S 4 D M 64 N4 N 155059-XX7 DJC7
1
A E 5 C1 600 T 4 X 5 D C 64 98 202805-XX1 JFD7
1
A E 5 C1 600 T 4 X 5 D C 64 98 202805-XX3 JFD9
1
A E 5 C1 600 T 4 X 5 D C 64 N2 202805-XX8 JFD8
1
A E 5 C1 600 T 4 X 5 D C 64 N2 202805-XX9 JFDA
1
A E 5 C1 600 T 4 X 5 D 0 64 98 202850-XX1 JFD1
1
A E 5 C1 600 T 4 X 5 D 0 64 N2 202850-XX8 JFD2
1
A E 5 C1 600 T 4 X 5 D M 64 98 202852-XX1 JFD3
1
A E 5 C1 600 T 4 X 5 D M 64 98 202852-XX3 JFD5
1
A E 5 C1 600 T 4 X 5 D M 64 N2 202852-XX8 JFD4
1
A E 5 C1 600 T 4 X 5 D M 64 N2 202852-XX9 JFD6
2
A E 5 C1 600 T 3 X 5 D M 64 98 202802-XX1 JFH3
2
A E 5 C1 600 T 3 X 5 D M 64 98 202802-XX3 JFH5
2
A E 5 C1 600 T 3 X 5 D M 64 N2 202802-XX8 JFH4
2
A E 5 C1 600 T 3 X 5 D M 64 N2 202802-XX9 JFH6
2
A E 5 C1 600 T 3 X 5 D 0 64 98 202803-XX1 JFH1
2
A E 5 C1 600 T 3 X 5 D 0 64 N2 202803-XX8 JFH2
2
A E 5 C1 600 T 3 X 5 D C 64 98 202804-XX1 JFH7
2
A E 5 C1 600 T 3 X 5 D C 64 98 202804-XX3 JFH9
2
A E 5 C1 600 T 3 X 5 D C 64 N2 202804-XX8 JFH8
2
A E 5 C1 600 T 3 X 5 D C 64 N2 202804-XX9 JFHA
1 2
9-cell Lithium Ion main battery pack 6-cell Lithium ion main battery pack
Continued
Product Description 1-7
Table 1-2 continued
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
2
A E 5 C1 550 T 4 X 6 D C 64 58 207057-XX1 FVX1
2
A E 5 C1 550 T 4 X 6 D C 64 N2 207057-XX8 FVX2
2
A E 5 C1 550 T 3 X 5 D 0 64 58 196659-XX1 FWB1
2
A E 5 C1 550 T 3 X 5 D 0 64 N2 196659-XX8 FWB2
2
A E 5 C1 550 T 3 X 5 D M 64 58 196665-XX1 FWB3
2
A E 5 C1 550 T 3 X 5 D M 64 58 196665-XX3 FWB5
2
A E 5 C1 550 T 3 X 5 D M 64 N2 196665-XX8 FWB4
2
A E 5 C1 550 T 3 X 5 D M 64 N2 196665-XX9 FWB6
2
A E 5 C1 550 T 3 X 5 D C 64 58 196661-XX1 FWB7
2
A E 5 C1 550 T 3 X 5 D C 64 N2 196661-XX8 FWB8
2
A E 5 C1 550 T 2 S 5 D 0 64 58 196657-XX1 FVZ1
2
A E 5 C1 550 T 2 S 5 D 0 64 N2 196657-XX8 FVZ2
2
A E 5 C1 550 T 2 S 5 D M 64 58 196664-XX1 FVZ3
2
A E 5 C1 550 T 2 S 5 D M 64 58 196664-XX3 FVZ5
2
A E 5 C1 550 T 2 S 5 D M 64 N2 196664-XX8 FVZ4
2
A E 5 C1 550 T 2 S 5 D M 64 N2 196664-XX9 FVZ6
2
A E 5 C1 550 T 2 S 5 D C 64 58 196658-XX1 FVZ7
2
A E 5 C1 550 T 2 S 5 D C 64 N2 196658-XX8 FVZ8
1 2
9-cell Lithium Ion main battery pack 6-cell Lithium ion main battery pack
1-8 Product Description
The Armada V300 model naming conventions are shown in Table 1-3.
The computer model designation is composed of a group of characters
that define each model's features.
Table 1-3
Compaq Armada V300
Model Naming Convention
Key
A V 3 C1 500 T4X 6 D M 64 58 N S F
1 2 3 4 5-6 7-9 10-12 13-14 15 16 17-19 20-21 22 23 24
Key Description Options
1 Brand designator A = Armada
2 Segment designator V = Versatility
3 Series 3 = 300
4 Blank
5-6 Processor type C1 = Intel Celeron 1
7-9 Processor speed 500 = 500 MHz 466 = 466 MHz 400 = 400 MHz
10 Panel type T = TFT H=HPA
11 Panel size 4 = 14.x" 3 = 13.x" 2 = 12.x"
12 Panel resolution X = XGA S= SVGA
13-14Hard drive size 6 = 6.0 GB 4 = 4.3 GB
(in GB, 1-2 digits)
15 Optical drive D = 24X Max CD-ROM drive
16 Integrated M = Mini PCI C = NIC/modem 0 = none
communication V.90 modem combo
17-19RAM (in MB, 64 = 64 MB 32 = 32 MB
2-3 digits)
20-21Operating system 98 = Windows 98 N4 = Windows NT 4.0
58 = Windows 95/98 dual N2 = Windows NT
install* 4.0/2000 dual install
22 NAFTA N = NAFTA
23 Pointing device P = TouchPad
24 Security
* End user must make a one-time selection between Windows 95 and Windows 98. If
end user desires rejected product(s) after selection is made, end user must acquire
and pay for rejected product(s) separately.
Product Description 1-9
Table 1-4
Compaq Armada V300
Computer Models
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
1
AV3 C1 500 T 4 X 6 D 0 58 64 P 163308-XX2 DVR1
1
AV3 C1 500 T 4 X 6 D 0 N4 64 P 163308-XX6 DVR3
1
AV3 C1 500 T 4 X 6 D M 58 64 P 163309-XX2 DVR4
1
AV3 C1 500 T 4 X 6 D M 58 64 N P 163309-XX3 DVR5
1
AV3 C1 500 T 4 X 6 D M N4 64 P 163309-XX6 DVR6
1
AV3 C1 500 T 4 X 6 D M N4 64 N P 163309-XX7 DVR7
1
AV3 C1 500 T 4 X 6 D C 58 64 P 163310-XX2 DVR8
1
AV3 C1 500 T 4 X 6 D C N4 64 P 163310-XX6 DVR9
1
A V 3 C1 466 T 4 X 4 D C 58 64 P 158984-XX2 DJD3
1
A V 3 C1 466 T 4 X 4 D C N4 64 P 158984-XX6 DJD4
1
A V 3 C1 466 T 4 X 4 D 0 58 64 P 117734-XX2 CXX1
1
A V 3 C1 466 T 4 X 4 D 0 98 64 P 117734-XX4 CXX2
1
A V 3 C1 466 T 4 X 4 D 0 N4 64 P 117734-XX6 CXX3
1
A V 3 C1 466 T 4 X 4 D M 58 64 P 117735-XX2 CXX4
1
A V 3 C1 466 T 4 X 4 D M 58 64 N P 117735-XX3 CXX5
1
A V 3 C1 466 T 4 X 4 D M N4 64 P 117735-XX6 CXX8
1
A V 3 C1 466 T 4 X 4 D M N4 64 N P 117735-XX7 CXX9
2
A V 3 C1 466 H 3 S 6 D 0 58 32 P 163199-XX2 DVP1
2
AV3 C1 466 H 3 S 6 D 0 N4 32 P 163199-XX6 DVP3
2
AV3 C1 466 H 3 S 6 D M 58 32 P 163229-XX2 DVP4
2
AV3 C1 466 H 3 S 6 D M 58 32 N P 163229-XX3 DVP5
2
AV3 C1 466 H 3 S 6 D M N4 32 P 163229-XX6 DVP6
2
AV3 C1 466 H 3 S 6 D M N4 32 N P 163229-XX7 DVP7
2
AV3 C1 466 H 3 S 6 D C 58 32 P 163304-XX2 DVP8
2
AV3 C1 466 H 3 S 6 D C N4 32 P 163304-XX6 DVP9
1
9-cell Lithium Ion main battery pack
2
6-cell Lithium ion main battery pack
Continued
1-10 Product Description
Table 1-4 continued
1 2 3 4 5-6 7-9 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# Config.
Code
2
AV3 C1 466 T 2 S 6 D 0 58 64 P 163305-XX2 DVQ1
2
AV3 C1 466 T 2 S 6 D 0 N4 64 P 163305-XX6 DVQ3
2
AV3 C1 466 T 2 S 6 D M 58 64 P 163306-XX2 DVQ4
2
AV3 C1 466 T 2 S 6 D M 58 64 N P 163306-XX3 DVQ5
2
AV3 C1 466 T 2 S 6 D M N4 64 P 163306-XX6 DVQ6
2
AV3 C1 466 T 2 S 6 D M N4 64 N P 163306-XX7 DVQ7
2
AV3 C1 466 T 2 S 6 D C 58 64 P 163307-XX2 DVQ8
2
AV3 C1 466 T 2 S 6 D C N4 64 P 163307-XX6 DVQ9
2
AV3 C1 400 T 2 S 4 D C 58 64 P 158983-XX2 DJD3
2
AV3 C1 400 T 2 S 4 D C N4 64 P 158983-XX6 DJD4
2
AV3 C1 400 T 2 S 4 D 0 58 64 P 117732-XX2 CXW1
2
AV3 C1 400 T 2 S 4 D 0 98 64 P 117732-XX4 CXW2
2
AV3 C1 400 T 2 S 4 D 0 N4 64 P 117732-XX6 CXW3
2
AV3 C1 400 T 2 S 4 D M 58 64 P 117733-XX2 CXW4
2
AV3 C1 400 T 2 S 4 D M 58 64 N P 117733-XX3 CXW5
2
AV3 C1 400 T 2 S 4 D M N4 64 P 117733-XX6 CXW8
2
AV3 C1 400 T 2 S 4 D M N4 64 N P 117733-XX7 CXW9
2
AV3 C1 400 H 2 S 4 D 0 58 32 P 117730-XX2 CXV1
2
AV3 C1 400 H 2 S 4 D 0 98 32 P 117730-XX4 CXV2
2
AV3 C1 400 H 2 S 4 D 0 N4 32 P 117730-XX6 CXV3
2
AV3 C1 400 H 2 S 4 D M 58 32 P 117731-XX2 CXV4
2
AV3 C1 400 H 2 S 4 D M 58 32 N P 117731-XX3 CXV5
2
AV3 C1 400 H 2 S 4 D M N4 32 P 117731-XX6 CXV8
2
AV3 C1 400 H 2 S 4 D M N4 32 N P 117731-XX7 CXV9
1
9-cell Lithium Ion main battery pack
2
6-cell Lithium ion main battery pack
Product Description 1-11
Features
The computer has the following features:
s The Armada E500 and E500S feature the following processors,
varying by computer model:
s Intel Pentium III 850-, 800-, 700-, 650-, 600-, 500- or 450-MHz
processor, with 256-KB integrated cache
s Intel Pentium II 400- or 366-MHz, with 256-KB integrated
cache
s Intel Celeron 550-MHz, with 128-KB integrated cache
s The Armada V300 features an Intel Celeron 500-, 466- or 400-MHz
processor, with 128-KB integrated L2 cache, varying by computer
model.
s ATI RAGE LT Pro, 4-MB SGRAM (synchronous graphics)
s The following standard memory is available, varying by computer
model:
s The Armada E500 and E500S are equipped with 64-MB high-
performance Synchronous DRAM (SDRAM), expandable to
512 MB.
s The Armada V300 is equipped with 64- or 32-MB
high-performance SDRAM, expandable to 512 MB.
s Microsoft Windows 95, Windows 98, Windows NT
Workstation 4.0, or Windows 2000 preinstalled
s The following displays are available, varying by computer model:
s The Armada E500 and E500S feature a 15.0-inch, SXGA, TFT
(1400 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
