Image preview - the first page of the document



>> Download CASIO_QV_10AB documenatation <<

Text preview - extract from the document

                      (without price)




QV-10A B(KX-723B)
(For NTSC)

      APR. 1996




                  R
                                         CONTENTS



SPECIFICATIONS ......................................................................................... 1
BLOCK DIAGRAM ........................................................................................ 2
CIRCUIT OPERATIONS ................................................................................ 3
COLOR ADJUSTMENT ............................................................................... 13
ADJUSTMENT ............................................................................................. 15
TROUBLESHOOTING ................................................................................. 18
DISASSEMBLY ........................................................................................... 19
ASSEMBLY ................................................................................................. 20
PRINTED CIRCUIT BOARDS ..................................................................... 21
EXPLODED VIEW ....................................................................................... 23
PARTS LIST ................................................................................................ 24
SCHEMATIC DIAGRAMS ........................................................................... 31
WAVEFORMS.............................................................................................. 34
                            SPECIFICATIONS

                     Item                            Specification
1. Recording System             Digital (JPEG based)/Field recording
2. Video Signal System          NTSC
3. Recording Medium             Built-in 16-Mbit flash memory
4. Number of pages              96
5. Delete Functions             Single page; All pages (with page protect feature)
6. Imaging Device               1/5-inch CCD (Total Number of Pixels: 250,000)
7. Lens                         Fixed focus with macro position; F2/f = 5.2mm
8. Aperture                     F2.8/F8 manual switching
9. Focal Length                 F2.8/NORMAL : 60cm to 310cm;
                                F2.8/MACRO       : 13cm to 16cm
                                F8/NORMAL        : 30cm to      ;
                                F8/MACRO         : 11cm to 21cm
                                (from lens protection filter)
10. Light Metering              TTL center point by photographic element
11. Exposure Metering           Aperture priority AE
12. Exposure Range              EV +5 to 18
13. Exposure Adjustment         -2EV to +2EV
14. Shutter System              Electronic
15. Shutter Speed               1/8 to 1/4000 second
16. White Balance               Automatic
17. Self-timer                  10-second
18. Monitor                     61,380-pixel 1.8-inch TFT low-glare color LCD
19. Terminals                   DIGITAL; VIDEO OUT; DC IN 6V
20. Power Supply                Batteries (AA-size Alkaline batteries
