Image preview - the first page of the document
>> Download CASIO_QV_10AC documenatation <<Text preview - extract from the document (without price)
QV-10A (C) (KX-723C)
(For PAL)
APR. 1996
R
CONTENTS
SPECIFICATIONS ......................................................................................... 1
BLOCK DIAGRAM ........................................................................................ 2
CIRCUIT OPERATIONS ................................................................................ 3
COLOR ADJUSTMENT ............................................................................... 13
ADJUSTMENT ............................................................................................. 15
TROUBLESHOOTING ................................................................................. 18
DISASSEMBLY ........................................................................................... 19
ASSEMBLY ................................................................................................. 20
PRINTED CIRCUIT BOARDS ..................................................................... 21
EXPLODED VIEW ....................................................................................... 23
PARTS LIST ................................................................................................ 24
SCHEMATIC DIAGRAMS ........................................................................... 31
WAVEFORMS.............................................................................................. 34
SPECIFICATIONS
Item Specification
1. Recording System Digital (JPEG based)/Field recording
2. Video Signal System PAL
3. Recording Medium Built-in 16-Mbit flash memory
4. Number of pages 96
5. Delete Functions Single page; All pages (with page protect feature)
6. Imaging Device 1/5-inch CCD (Total Number of Pixels: 250,000)
7. Lens Fixed focus with macro position; F2/f = 5.2 mm
8. Aperture F2.8/F8 manual switching
9. Focal Length F2.8/NORMAL : 60 cm to 310 cm;
F2.8/MACRO : 13 cm to 16 cm
F8/NORMAL : 30 cm to ;
F8/MACRO : 11 cm to 21 cm
(from lens protection filter)
10. Light Metering TTL center point by photographic element
11. Exposure Metering Aperture priority AE
12. Exposure Range EV +5 to 18
13. Exposure Adjustment -2 EV to +2 EV
14. Shutter System Electronic
15. Shutter Speed 1/8 to 1/4000 second
16. White Balance Automatic
17. Self-timer 10-second
18. Monitor 61,380-pixel 1.8-inch TFT low-glare color LCD
19. Terminals DIGITAL; VIDEO OUT; DC IN 6 V
20. Power Supply Batteries (AA-size Alkaline batteries
