Image preview - the first page of the document
>> Download CASIO_QV_10C documenatation <<
Text preview - extract from the document
(with price)
QV-10C(KX-720C)
JUL. 1995
R
CONTENTS
SPECIFICATIONS ......................................................................................... 1
BLOCK DIAGRAM ........................................................................................ 2
CIRCUIT OPERATIONS ................................................................................ 3
ADJUSTMENT ............................................................................................. 13
DISASSEMBLY AND ASSEMBLY .............................................................. 17
PRINTED CIRCUIT BOARDS ..................................................................... 18
ELECTRICAL PARTS LIST......................................................................... 20
MECHANICAL PARTS LIST ....................................................................... 30
EXPLODED VIEW ....................................................................................... 31
REPAIR METHOD ....................................................................................... 32
PARTS LIST FOR ACCESSORIES ............................................................. 33
SCHEMATIC DIAGRAMS ........................................................................... 35
WAVEFORMS.............................................................................................. 38
SPECIFICATIONS
Item Specification
1. Recording System Digital (JPEG based) / Field recording
2. Signal System PAL
3. Recording Medium Built-in 16-Mbit flash memory
4. Number of pages 96
5. Delete Functions Single page; All pages (with page protect feature)
6. Imaging Device 1/5-inch CCD (Total Number of Pixels: 250,000)
7. Lens Fixed focus with macro position; F2/f = 5.2 mm
8. Aperture F2/F8 manual switching
9. Focal Length F2/NORMAL : 60 cm to 310 cm;
F2/MACRO : 13 cm to 16 cm
F8/NORMAL : 28 cm to ;
F8/MACRO : 10 cm to 24 cm
(from lens protection filter)
10. Light Metering TTL center point by photographic element
11. Exposure Metering Aperture priority AE
12. Exposure Range EV +5 to 18
13. Exposure Adjustment -2EV to +2EV
14. Shutter System Electronic
15. Shutter Speed 1/8 to 1/4000 second
16. White Balance Automatic
17. Self-timer 10-second
18. Monitor 61,380-pixel 1.8-inch TFT low-glare color LCD; doubles as finder
19. Terminals DIGITAL; VIDEO OUT; DC IN 6 V
20. Power Supply Batteries (AA-size Alkaline batteries X 4) / AC Adaptor (AD-C60)
21. Battery Life Approximately 120 minutes
22. Dimensions 66(H) X 130(W) X 40(D)mm / 2.6" (H) X 9" (W) X 1.6" (D)
23. Weight Approximately 190g / 6.7oz (excluding batteries)
24. Accessories Wirst strap; soft case; special video cable; AC adaptor (AD-C60)
Alkaline batteries (LR6 X 4); cleaning cloth; owner's manual;
personal computer connection kit
--1--
BLOCK DIAGRAM
1 Camera PCB 2 Digital PCB 3 Linear PCB 4 LCD
V RAM IC300
