Image preview - the first page of the document
>> Download CASIO_QV_30B documenatation <<
Text preview - extract from the document
(without price)
QV-30 (B) (KX-724B)
(For NTSC)
APR. 1996
R
CONTENTS
SPECIFICATIONS ......................................................................................... 1
BLOCK DIAGRAM ........................................................................................ 2
CIRCUIT OPERATIONS ................................................................................ 3
COLOR ADJUSTMENT ............................................................................... 13
ADJUSTMENT ............................................................................................. 15
TROUBLESHOOTING ................................................................................. 18
DISASSEMBLY ........................................................................................... 19
ASSEMBLY ................................................................................................. 21
PRINTED CIRCUIT BOARDS ..................................................................... 23
EXPLODED VIEW ....................................................................................... 25
PARTS LIST ................................................................................................ 26
SCHEMATIC DIAGRAMS ........................................................................... 35
WAVEFORMS.............................................................................................. 39
SPECIFICATIONS
Item Specification
1. Recording System Digital (JPEG based)/Field recording
2. Video Signal System NTSC
3. Recording Medium Built-in 16-Mbit flash memory
4. Number of pages 96
5. Delete Functions Single page; All pages (with page protect feature)
6. Imaging Device 1/5-inch CCD (Total Number of Pixels: 250,000)
7. Lens 2 focal points with macro position: F2.8 f=4.0 mm/f=9.0 mm
8. Aperture F2.8/F8 manual switching
9. Focal Length f=4.0 mm F2.8/NORMAL : 50 cm ~
f=4.0 mm F2.8/MACRO : 10 cm ~ 13 cm
f=4.0 mm F8/NORMAL : 24 cm ~ ;
f=4.0 mm F8/MACRO : 8 cm ~ 19 cm
f=9.0 mm F2.8/NORMAL : 250 cm ~
f=9.0 mm F2.8/MACRO : 50 cm ~ 65 cm
f=9.0 mm F8/NORMAL : 120 cm ~ ;
f=9.0 mm F8/MACRO : 40 cm ~ 95 cm
10. Light Metering TTL center point by photographic element
11. Exposure Metering Aperture priority AE
12. Exposure Range EV +5 to 18
13. Exposure Adjustment -2 EV to +2 EV
14. Shutter System Electronic
15. Shutter Speed 1/8 to 1/4000 second
16. White Balance Automatic
17. Self-timer 10-second
18. Monitor 61,380-pixel 2.5-inch TFT low-glare color LCD
19. Terminals DIGITAL; VIDEO OUT; DC IN 6 V
20. Power Supply Batteries (AA-size Alkaline batteries ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
