Image preview - the first page of the document



>> Download Service Bulletin OST-C1175 documenatation <<

Text preview - extract from the document

                                  100 Corporate Drive Mahwah, NJ 07430



                                                                                       Service Bulletin
                                         No. : OST-C1175
                                         Date: June 15, 2007
_____________________________________________________________

Model:               DRA-F101


Subject:             Change of the Tuner Pack.


Symptom: Regarding the subject model, we will use the following substitute
Tuner Packs due to the discontinuation of the production of the present Tuner
Pack by the original manufacturer.


Solution:
1) We will replace the original Tuner Pack with the following Pack due to the
discontinued production of the Original Tuner Pack.




2) After the above, the 1st substitute Tuner Pack made by Mitsumi will be
replaced with the following 2nd substitute Tuner Pack made by the Alps due to
the discontinued production of the 1st substitute Tuner Pack by Mitsumi.




______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
UPON MAINTENANCE SERVICE:
1) After replacement, the Tuner Packs (00D 216 0113 000 and 00D 216 0117
006) made by Mitsumi can be similarly used without paying special care.
2) The shape of the FM Antenna terminal of the Alps's Tuner Pack (00D 216
0109 001) differs from the Mitsumi's FM Antenna terminal. Therefore, please
replace the Tuner Pack according to the followings when the replacement is
needed upon service.

(The FM Antenna terminal of the Mitsumi's Tuner Pack is equipped with the
screw type F terminal. However, the FM terminal of the Alps's Tuner Pack is
equipped with the PAL/F terminal (without screw) that is compatible with the
European PAL terminal. (Please refer to the following photos.)




______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
Serial Number Range:
