Image preview - the first page of the document
>> Download Схема 2 AVR-1709 & 689 documenatation <<
Text preview - extract from the document
downloaded from http://receiverfaq.ru/
BLOCK DIAGRAM
AUDIO BLOCK DIAGRAM (for AVR-1709/689 model)
35
AVR-1709/1609/1519/1509/689/589, AVC-1509
AUDIO BLOCK DIAGRAM (for AVR-1609/1519/1509/589, AVC-1509 model)
36
AVR-1709/1609/1519/1509/689/589, AVC-1509
VIDEO BLOCK DIAGRAM (for AVR-1709/689 model)
37
AVR-1709/1609/1519/1509/689/589, AVC-1509
VIDEO BLOCK DIAGRAM (for AVR-1609/1519/1509/589, AVC-1509 model)
38
AVR-1709/1609/1519/1509/689/589, AVC-1509
LEVEL DIAGRAMS (1/5)
FRONT LEVEL DIAGRAM
AVR-1709
LEVEL DIAGRAM
FRONT ch
R2A15215FP
ANALOG
H/POUT
ATT
SPEAKE
LINE IN
R OUT
GAIN
ADAU1328 ADJ.
D/A D/A OUT
A/D
MUTE
FROM SWch
TO
Surround Back DSP
(ZONE2 MODE)
RECOUT
EXT IN
+30dB
3.876V NON CLICP MAX SIGNAL LEVEL 4.0Vrms
SP OUT
3.17Vrms/8
+20dB +20dB
0dBFS Config1 DOLBY LIMIT LEVEL (ALLch-3dBFS)
ADAU1328 0.88Vrms
+26dB
0dBFS
0dBFS SUM FROM SWch
+10dB +10dB
-35dB
-10dBFS Config2 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
-10dBFS
-2dB RECOUT
LINE IN/EXT IN
200mV 0dB 0dB
-20dBFS(DIG.IN)
-8dB PCM or DD Config1 +7dB -2+2=0dB
-22dBFS(A/D IN)
-2+6.5=4.5dB
-20dBFS
-20dBFS
A/D IN
-10dB 79.4mVrms -10dB
H/POUT
-26.5dBFS(DIG.IN) 56.4mVrms
DD Config2
-30dBFS
-30dBFS
-20dB -20dB
-40dBFS
-40dBFS
-30dB -30dB
-40dB -40dB
39
AVR-1709/1609/1519/1509/689/589, AVC-1509
LEVEL DIAGRAMS (2/5)
CENTER LEVEL DIAGRAM
AVR-1709
LEVEL DIAGRAM
CENTER ch
R2A15215FP
SPEAKE
R OUT
GAIN
ADAU1328 ADJ.
D/A D/A OUT
A/D
MUTE
DSP
EXT IN
+30dB
NON CLICP MAX SIGNAL LEVEL 4.0Vrms
SP OUT
3.17Vrms/8
Config1 DOLBY LIMIT LEVEL (ALLch-3dBFS)
+20dB +20dB
0dBFS
0.88Vrms
+26dB
0dBFS
Config2 DOLBY LIMIT LEVEL (ALLch-3dBFS)
+10dB +10dB
-10dBFS
-2dB
LINE IN/EXT IN
200mV 0dB 0dB
-20dBFS(DIG.IN)
PCM or DD Config1 +7dB -2+2=0dB
-22dBFS(A/D IN)
-2+6.5=4.5dB
-20dBFS
-10dB -10dB
-26.5dBFS(DIG.IN) There is no regular revision of VOL
DD Config2
-30dBFS
-20dB -20dB
-40dBFS
-30dB -30dB
-40dB -40dB
40
AVR-1709/1609/1519/1509/689/589, AVC-1509
LEVEL DIAGRAMS (3/5)
SUB WOOFER LEVEL DIAGRAM
AVR-1709
LEVEL DIAGRAM
SUBWOOFER ch
R2A15215FP
MUTE PREOUT
GAIN
ADAU1328 ADJ.
D/A D/A OUT
A/D
MUTE
DSP
EXT IN
+30dB
NON CLICP MAX SIGNAL LEVEL 4.0Vrms
3.17V
SUM to FRONTch Config2 DOLBY LIMIT LEVEL (ALLch-3dBFS)
Config1 DOLBY LIMIT LEVEL (ALLch-3dBFS)
+20dB +20dB
0dBFS
0.88Vrms
0dBFS
+10dB +10dB
PREOUT
-10dBFS 317mVrms
-2dB
LINE IN/EXT IN
200mV 0dB 0dB
PREOUT
159mVrms
-20dBFS
-2+(18-6)=10dB
-10dB -10dB
+1dB SUM to FRONT-ch
PCM-20dBFS L/R Simultaneous input -34dBFS(PCM.IN)
or ANALOG L/R 200mVSimultaneous input -36dBFS(A/D IN)
-30dBFS +6dB
-20dB -20dB
+7dB
Playing at DD LFE-30dBFS -38dBFS(DIG.IN)
DD Config1/2
-40dBFS
-30dB -30dB
-50dBFS
-40dB -40dB
41
AVR-1709/1609/1519/1509/689/589, AVC-1509
LEVEL DIAGRAMS (4/5)
SURROUND LEVEL DIAGRAM
AVR-1709
LEVEL DIAGRAM
SURROUND ch
R2A15215FP
GAIN
ADAU1328 ADJ.
D/A D/A OUT
A/D
MUTE
DSP
EXT IN
+30dB
NON CLICP MAX SIGNAL LEVEL 4.0Vrms
Config1 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS) SP OUT
3.17Vrms/8
+20dB +20dB
0dBFS
0.88Vrms
Config2 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS) +26dB
0dBFS
+10dB +10dB
-10dBFS
-2dB
LINE IN/EXT IN
200mV 0dB 0dB
-23dBFS(DIG.IN) -2+2=0dB
PCM or DD Config1 +10dB
-25dBFS(A/D IN)
-2+6.5=4.5dB
-20dBFS
-10dB -10dB
-29.5dBFS(DIG.IN) There is no regular revision of VOL
DD Config2
-30dBFS
-20dB -20dB
-40dBFS
-30dB -30dB
-40dB -40dB
42
AVR-1709/1609/1519/1509/689/589, AVC-1509
LEVEL DIAGRAMS (5/5)
SURROUND BACK LEVEL DIAGRAM
AVR-1709
LEVEL DIAGRAM
SURR.BACK ch
R2A15215FP
SPEAKE
R OUT
GAIN
ADAU1328 ADJ.
D/A D/A OUT
A/D
MUTE
DSP
+30dB
NON CLICP MAX SIGNAL LEVEL 4.0Vrms SP OUT
3.17Vrms/8
SP OUT(D/A
Config1 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS) OUT)
+20dB +20dB
0dBFS
0.88Vrms
+26dB
0dBFS
+10dB +10dB
Config2 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
-10dBFS
-2dB
LINE IN/EXT IN
200mV 0dB 0dB
+7dB -2+3+2=+3dB
-20dBFS -2+3=1dB
-25dBFS(A/D IN) -2+6.5+3=7.5dB
-10dB -10dB
-26dBFS(DIG.IN)
DD EX Config1
-30dBFS
-32.5dBFS(DIG.IN)
-20dB DD EX Config2 -20dB
-40dBFS
-30dB -30dB
-40dB -40dB
43
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Analog Audio SIGNAL LINE
SCHEMATIC DIAGRAMS (1/20)
MAIN UNIT (1/2)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Analog Audio SIGNAL LINE
SCHEMATIC DIAGRAMS (2/20)
MAIN UNIT (2/2)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Analog Audio SIGNAL LINE
SCHEMATIC DIAGRAMS (3/20)
INPUT UNIT
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Video SIGNAL LINE
SCHEMATIC DIAGRAMS (4/20)
CPU UNIT (1/3)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (5/20)
CPU UNIT (2/3)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (6/20)
CPU UNIT (3/3)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (7/20)
FRONT UNIT
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Analog Audio SIGNAL LINE
SCHEMATIC DIAGRAMS (8/20)
SPK UNIT
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
HDMI/TMDS SIGNAL LINE
SCHEMATIC DIAGRAMS (9/20)
HDMI UNIT (1/3)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Analog Audio SIGNAL LINE
SCHEMATIC DIAGRAMS (10/20)
SIRIUS UNIT (1/2)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (11/20)
SIRIUS UNIT (2/2)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
HDMI/TMDS SIGNAL LINE
SCHEMATIC DIAGRAMS (12/20)
HDMI UNIT (2/3)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Analog Audio SIGNAL LINE
HDMI/TMDS SIGNAL LINE
SCHEMATIC DIAGRAMS (13/20)
HDMI UNIT (3/3)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (14/20)
SUPPLY UNIT
F
POWER UNIT
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (15/20)
2CH AMP UNIT
2CH AMP PARTS
DSP/HDMI_POWER PARTS F
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (16/20)
Video SIGNAL LINE VIDEO UNIT (1/4)
S- Video Y SIGNAL LINE F
C/S_VIDEO PARTS (AVR1709 ALL)
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Video SIGNAL LINE
SCHEMATIC DIAGRAMS (17/20)
S- Video Y SIGNAL LINE
VIDEO UNIT (2/4)
Component Y SIGNAL LINE F
COMPONENT VIDEO PARTS (AVR1709 ALL)
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Video SIGNAL LINE
S- Video Y SIGNAL LINE
Component Y SIGNAL LINE
SCHEMATIC DIAGRAMS (18/20)
VIDEO UNIT (3/4)
F
DSP/HDMI_POWER PARTS (AVR1509 ALL)
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
Component Y SIGNAL LINE
SCHEMATIC DIAGRAMS (19/20)
VIDEO UNIT (4/4)
F
D-VIDEO ONLY
AVR-1709/1609/1519/1509/689/589, AVC-1509
1 2 3 4 5 6 7 8
A
B
C
D
E
SCHEMATIC DIAGRAMS (20/20)
POWER UNIT (AVR589 model only)
F
AVR-1709/1609/1519/1509/689/589, AVC-1509
